2005 MITSUBISHI 380 Workshop Manual

SUNROOF ASSEMBLY
BODY42-78
Basic operation
NO. SUNROOF
FUNCTIONREQUIREMENTS FOR THE SUNROOF TO
FUNCTIONNORMAL OPERATION
01 OPEN
1. Ignition switch: ON
2. Sunroof switch: OPENThe sunroof opens fully and
automatically and stops
several centimeters forward
of the fully open position
(position for less wind
noise).
Then, when the sunroof
switch is operated again,
the sunroof opens further to
fully open position.
02 CLOSE
1. Ignition switch: ON
2. Sunroof switch: CLOSE/TILT-DOWN The sunroof closes while
the sunroof switch is
pushed to the
CLOSE/TILT-DOWN
position.
03 TILT-UP
1. Ignition switch: ON
2. Sunroof switch: TILT-UPThe sunroof tilts up fully and
automatically.
04 TILT-DOWN
1. Ignition switch: ON
2. Sunroof switch: CLOSE/TILT-DOWNThe sunroof closes while
the sunroof switch is
pushed to the
CLOSE/TILT-DOWN
position.

SUNROOF ASSEMBLY
BODY42-79
Sunroof timer mechanism
In cases except the following, the basic operation
and jam preventing mechanism will be maintained
for thirty seconds after the ignition switch is turned to
the LOCK (OFF) position. (Sunroof timer function)
If you open a door within that period (i.e. a door
switch is on), the sunroof timer function will be
cancelled immediately.
If you turn the ignition switch to the LOCK (OFF)
position while the timer is working, the sunroof
will continue moving until it closes fully, regard-
less of the time-out period. 05 AUTOMATIC
OPERATION
INTERRUPTION
(OPEN)A
1. Ignition switch: ON
2. Sunroof switch: OPEN or TILT-UPThe sunroof stops the
automatic opening
operation.
B
1. Ignition switch: ON
2. Sunroof switch: CLOSE/TILT DOWN (Push
the sunroof switch to the
CLOSE/TILT-DOWN position while the
sunroof is automatically opening and
release the switch within two seconds)The sunroof stops the
automatic opening
operation.
C
1. Ignition switch: ON
2. Sunroof switch: CLOSE/TILT DOWN (Push
the sunroof switch to the
CLOSE/TILT-DOWN position more than
two seconds while the sunroof is
automatically opening)The sunroof stops the
automatic opening
operation, and the sunroof
closes while the sunroof
switch is pushed to the
CLOSE/TILT-DOWN
position.
06 AUTOMATIC
OPERATION
INTERRUPTION
(TILT-UP)1. Ignition switch: ON
2. Sunroof switch: OPEN or TILT-UP, CLOSE/TILT
DOWNThe sunroof stops the
automatic opening
operation. NO. SUNROOF
FUNCTIONREQUIREMENTS FOR THE SUNROOF TO
FUNCTIONNORMAL OPERATION

SUNROOF ASSEMBLY
BODY42-80
SUNROOF ASSEMBLY
REMOVAL AND INSTALLATIONM1426001200308
Post-installation Operation Sunroof assembly>
Sunroof Water Test (Refer to P.42-75).
Sunroof Fit Adjustment (Refer to P.42-76).
Post-installation Operation Sunroof motor assembly>
Sunroof Initializing Adjustment (Refer to P.42-77).
REMOVAL
1. ROOF LID GLASS ASSEMBLY
2. OVERHEAD CONSOLE ASSEMBLY
DRAIN PIPE REMOVAL STEPS
FRONT HEADLINING PAD (REFER
TO GROUP 52A, HEADLINING
P.52A-19).
FRONT SPLASH SHIELD (REFER
TO P.42-10).
UPPER FRAME TO FRONT PILLAR
BRACE (FRONT DRAIN PIPE )
(REFER TO P.42-84).
INSTRUMENT PANEL PARCEL BOX
(FRONT DRAIN PIPE )
(REFER TO GROUP 52A,
INSTRUMENT PANEL P.52A-4).
>>A<<3. FRONT DRAIN PIPE
REAR HEADLINING PAD (REFER
TO GROUP 52A, HEADLINING
P.52A-19).
TRUNK TRIM ASSEMBLY (REFER
TO GROUP 52A, TRIMS P.52A-11).
REAR SPLASH SHIELD (REFER TO
GROUP 51, REAR BUMPER P.51-5).
>>A<<4. REAR DRAIN PIPE
SUNROOF MOTOR ASSEMBLY
REMOVAL STEPS
HEADLINING (REFER TO GROUP
52A, HEADLINING P.52A-19).
5. SUNROOF MOTOR ASSEMBLYDRAIN PIPE REMOVAL STEPS

SUNROOF ASSEMBLY
BODY42-81
Required Special Tool:
MB991223: Harness set
INSTALLATION SERVICE POINT
.
>>A<< REAR DRAIN PIPE/FRONT DRAIN PIPE
INSTALLATION
Install the grommet, and then position the drain pipe so that it
protrudes from the grommet as shown in the illustration.
SUNROOF ASSEMBLY REMOVAL
STEPS
1. ROOF LID GLASS ASSEMBLY
HEADLINING (REFER TO GROUP
52A, HEADLINING P.52A-19).
DRAIN PIPE CONNECTION
5. SUNROOF MOTOR ASSEMBLY6. OVERHEAD CONSOLE BRACKET
7. SUNROOF ASSEMBLY SUNROOF ASSEMBLY REMOVAL
STEPS (Continued)

SUNROOF ASSEMBLY
BODY42-82
INSPECTIONM1421007600440
SUNROOF SWITCH CONTINUITY CHECK
SWITCH
POSITIONTESTER
CONNECTIONSPECIFIED
CONDITION
Open 4
5 Less than 2 ohms
Off 3
4, 3 5, 3 6,
4
5, 4 6, 5 6Open circuit
Tilt-up 3
4 Less than 2 ohms
Close/Tilt-down 4
6 Less than 2 ohms

SUNROOF ASSEMBLY
BODY42-83
DISASSEMBLY AND ASSEMBLYM1426001400294
DISASSEMBLY STEPS
1. SUNROOF DRIP PLATE
2. SUNROOF SUNSHADE STOPPER
3. SUNROOF SUNSHADE
<>4. SUNROOF DEFLECTOR
ASSEMBLY
5. SUNROOF DEFLECTOR6. SUNROOF GUIDE RAIL ROD
HOLDER
7. SUNROOF DRIP RAIL
8. ROOF LID SLIDER
9. SLIDING ROOF OPERATING UNIT
10. ROOF BLIND STOPPER
11. SUNROOF HOUSINGDISASSEMBLY STEPS

LOOSE PANEL
BODY42-84
DISASSEMBLY SERVICE POINT
.
<> SUNROOF DEFLECTOR ASSEMBLY
REMOVAL
Slide the sunroof deflector assembly to the front of the vehicle
by holding the arrow area shown in the illustration with a
flat-tipped screwdriver, and remove it.
LOOSE PANEL
REMOVAL AND INSTALLATIONM1421003100056
REMOVAL
1. FRONT FLOOR BACKBONE BRACE

LOOSE PANEL
BODY42-85
COWL TOP COVER OUTER
REMOVAL STEPS
FRONT DECK GARNISH (REFER
TO GROUP 51, WINDSHIELD
WIPER P.51-17.)
2. COWL TOP COVER OUTER
UPPER FRAME TO FRONT PILLAR
BRACE REMOVAL STEPS
SPLASH SHIELD (REFER TO
P.42-10.)
3. UPPER FRAME TO FRONT PILLAR
BRACE
AIR GUIDE PANEL REMOVAL
STEPS
FRONT BUMPER ASSEMBLY
(REFER TO GROUP 51, FRONT
BUMPER P.51-2.)
4. AIR GUIDE PANEL CENTER
FRONT BUMPER
REINFORCEMENT ASSEMBLY
(REFER TO GROUP 51, FRONT
BUMPER P.51-2.)
5. AIR GUIDE PANEL SIDEFRONT BUMPER
REINFORCEMENT BRACKET
REMOVAL STEPS
FRONT BUMPER
REINFORCEMENT ASSEMBLY
(REFER TO GROUP 51, FRONT
BUMPER P.51-2.)
5. AIR GUIDE PANEL SIDE
6. FRONT BUMPER
REINFORCEMENT BRACKET
FRONT END STRUCTURE BAR
REMOVAL STEPS
RADIATOR GRILLE (REFER TO
GROUP 51, RADIATOR GRILLE
P.51-6.)
FRONT BUMPER MOUNTING
CLIPS UPPER (REFER TO GROUP
51, FRONT BUMPER P.51-2.)
HOOD DAMPER AND HOOD LATCH
(REFER TO P.42-8.)
7. COOLER TUBE ASSEMBLY
MOUNTING BOLT
8. FRONT END STRUCTURE BAR
