DOOR
BODY42-38
INSTALLATION SERVICE POINTS
.
>>A<< STRIKER INSTALLATION
Align the center of the striker and latch within 1.5 mm (0.06
inch), and install.
.
>>B<< REAR DOOR PROTECTOR FILM
INSTALLATION
Install the rear door protector film as shown.
INSPECTIONM1423006000333
DOOR SWITCH CHECK
Check continuity between the switch terminals and body
ground.
SWITCH
POSITIONTESTER
CONNECTIONSPECIFIED
CONDITION
Released (ON) 1
body ground Less than 2 ohms
Depressed (OFF) 1
body ground Open circuit
Page 1106 of 1500
DOOR
BODY42-39
DOOR GLASS AND REGULATOR
REMOVAL AND INSTALLATIONM1429001300326
Pre-removal Operation
Door Trim Assembly Removal (Refer to GROUP 52A
Door Trim P.52A-14).
Waterproof Film Removal (Refer to P.42-52).Post-installation Operation
Door Window Glass Adjustment (Refer to P.42-31).
Waterproof Film Installation (Refer to P.42-52).
Door Trim Assembly Installation (Refer to GROUP 52A,
Door Trim P.52A-14).
DOOR WINDOW REGULATOR
ASSEMBLY REMOVAL STEPS
DOOR BELTLINE MOLDING
(REFER TO P.42-52).1. DOOR WINDOW GLASS
2. WINDOW REGULATOR ASSEMBLYDOOR WINDOW REGULATOR
ASSEMBLY REMOVAL STEPS
Page 1107 of 1500
DOOR
BODY42-40
Required Special Tool:
MB990784: Ornament Remover
POWER WINDOW SWITCH
REMOVAL STEPS
<>3. POWER WINDOW SWITCH PANEL
ASSEMBLY
4. POWER WINDOW SWITCH PANEL
5. POWER WINDOW MAIN SWITCH
(LH), POWER WINDOW SUB
SWITCH (RH)
Page 1108 of 1500
Page 1109 of 1500
Page 1110 of 1500
DOOR
BODY42-43
<> REAR DOOR STATIONARY WINDOW
GLASS ASSEMBLY REMOVAL
Remove the mounting screw of the top of the rear door station-
ary window glass assembly (the screw is hidden by the mold-
ing).
.
<> POWER WINDOW SWITCH PANEL
ASSEMBLY REMOVAL
Insert special tool MB990784 as shown to remove the power
window switch panel assembly.
INSPECTIONM1429001400293
POWER WINDOW SWITCH CONTINUITY CHECK
Remove the power window switch. (Refer to P.42-39.).
Power window main switch's front switch
check
Connect terminal number 13 to the battery positive (+) post,
and connect terminal number 12 to the battery negative (
)
post.
Main switch
SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
FRONT
(RH)UP 12
10, 14 2, Less than 2 ohms
OFF 12
2, 14 2 Less than 2 ohms
DOWN 14
10, 12 2 Less than 2 ohms
FRONT
(LH)UP 7
10, 9 2* Less than 2 ohms
OFF 7
9, 7 2*, 14
2*Less than 2 ohms
DOWN 9
10, 7 2* Less than 2 ohms
Page 1111 of 1500
DOOR
BODY42-44
NOTE: *: Set the window lock switch to UNLOCK position.
.Sub switch
Sub switch REAR (RH) UP 4
10, 6 2* Less than 2 ohms
OFF 4
6, 4 2*, 6 2* Less than 2 ohms
DOWN 6
10, 4 2* Less than 2 ohms
REAR (RH) UP 1
10, 3 2* Less than 2 ohms
OFF 3
1, 3 2*, 2* 1 Less than 2 ohms
DOWN 3
10, 2* 1 Less than 2 ohms
SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
UP 4
5, 6 7 Less than 2 ohms
OFF 4
5, 7 8 Less than 2 ohms
DOWN 4
6, 7 8 Less than 2 ohms
SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
UP 4
5, 6 7 Less than 2 ohms
OFF 4
5, 7 8 Less than 2 ohms
DOWN 4
6, 7 8 Less than 2 ohms SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
Page 1112 of 1500
DOOR
BODY42-45
DOOR WINDOW REGULATOR CHECK
.
1. Connect a battery directly to the motor terminals and check
that the motor runs smoothly.
2. Check that the motor runs in the opposite direction when the
battery is connected with the polarity reversed.
3. If a defect is found, replace the window regulator as an
assembly.
.
.BATTERY CONNECTION SLIDER POSITION
Connect terminal No. 1
and the negative battery
terminal.
Connect terminal No. 2
and the positive battery
terminal.UP
Connect terminal No. 2
and the negative battery
terminal.
Connect terminal No. 1
and the positive battery
terminal.DOWN
BATTERY CONNECTION SLIDER POSITION
Connect terminal No. 1
and the negative battery
terminal.
Connect terminal No. 2
and the positive battery
terminal.UP
Connect terminal No. 2
and the negative battery
terminal.
Connect terminal No. 1
and the positive battery
terminal.DOWN
