2005 MITSUBISHI 380 Workshop Manual

WINDSHIELD WIPER AND WASHER
EXTERIOR51-24
NOTE: For removal and installation of the wiper and
washer switch, refer to GROUP 54A, Column switch
P.54A-170.
INSPECTIONM1511008300147
WINDSHIELD WASHER MOTOR CHECK
1. Remove the washer tank assembly with the washer hose
attached. Then fill the washer tank with water.
2. Check to see that the water is vigorously sprayed when
connecting the positive battery terminal to terminal number
2 and terminal number 1 to ground.
WINDSHIELD WASHER SWITCH CHECK
4. WINDSHIELD WASHER MOTOR
5. WASHER TANK
WASHER MOTOR REMOVAL STEPS
FRONT UNDER COVER RH (REFER
TO P.51-2).
FRONT WASHER HOSE
CONNECTIONS
4. WINDSHIELD WASHER MOTOR WASHER TANK REMOVAL STEPS
SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
OFF 22
23 Open circuit
Windshield washer
switch ON22
23 Less than 2 ohms

MARK
EXTERIOR51-25
MARK
REMOVAL AND INSTALLATIONM1511011800454
1. FRONT THREE-DIAMOND MARK 2. REAR THREE-DIAMOND MARK>>A<<3. GRADE MARK

MARK
EXTERIOR51-26
INSTALLATION SERVICE POINT
.
>>A<< MARK INSTALLATION
1. Installation position
Attach the correct grade mark to the position shown in the
illustration. ie (380/380LS/380VRX/380GT).
2. Installation procedure
(1) Use 3M
AAD Part number 8906 or equivalent to clean
the mark installation surfaces on the body.
When attaching the mark, the ambient temperature should
be 20
38C (60 100F) and the air should be completely
free of dust. If the ambient temperature is lower than 20
C
(60
F), the mark and the place on the vehicle body where
the mark is to be attached should be heated to 20
38C
(60
100F).
(2) Peel off the protection sheet on the back of the mark to
affix it in position.

DOOR MIRROR
EXTERIOR51-27
DOOR MIRROR
GENERAL DESCRIPTIONM1511000100570
OPERATION DOOR MIRROR
Remote Controlled Mirror Operation
The mirror on the door mirror moves up/down
and left/right by operating the remote controlled
door mirror switch when the ignition switch is in
the "ON" or "ACC" position.

DOOR MIRROR
EXTERIOR51-28
DOOR MIRROR
REMOVAL AND INSTALLATIONM1511006400331

DOOR MIRROR
EXTERIOR51-29
REMOVAL SERVICE POINT
.
<> POWER WINDOW SWITCH PANEL
ASSEMBLY REMOVAL
Insert special tool MB990874 as shown to remove the power
window switch panel assembly.
INSPECTIONM1511006500305
ELECTRIC REMOTE CONTROL MIRROR
OPERATION CHECK
Check that the mirror moves as described in the table when
each terminal is connected to the battery.
REMOTE CONTROLLED MIRROR
REMOVAL STEPS
FRONT DOOR TRIM (REFER TO
GROUP 52A, DOOR TRIMS
P.52A-14).
1. DOOR MIRROR COVER
2. REMOTE CONTROLLED MIRROR
ASSEMBLYREMOTE CONTROLLED MIRROR
SWITCH REMOVAL STEPS<>3. POWER WINDOW SWITCH PANEL
ASSEMBLY
4. REMOTE CONTROLLED MIRROR
SWITCH
BATTERY CONNECTION DIRECTION
OPERATION
Connect terminal 6 to the negative
battery terminal.
Connect terminal 4 to the positive battery
terminal.Up
Connect terminal 6 to the positive battery
terminal.
Connect terminal 4 to the negative
battery terminal.Down
Connect terminal 6 to the negative
battery terminal.
Connect terminal 5 to the positive battery
terminal.Right
Connect terminal 6 to the positive battery
terminal.
Connect terminal 5 to the negative
battery terminal.Left

DOOR MIRROR
EXTERIOR51-30
DOOR MIRROR CONTROL SWITCH CONTINUITY
CHECK
SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
OFF 9
2, 9 3, 9 6,
9
10, 9 11, 1 2,
1
3, 1 6, 1 10,
1
11Open circuit
Left side OFF 9
6, 9 10, 9 11,
1
6, 1 10, 1 11Open circuit
Up 1
6, 9 11 Less than 2
ohms
Down 1
11, 6 9
Right 1
6, 9 10
Left 1
10, 6 9
Right side OFF 9
2, 9 3, 9 6,
1
2, 1 3, 1 6Open circuit
Up 1
6, 3 9 Less than 2
ohms
Down 1
3, 6 9
Right 1
6, 2 9
Left 1
2, 6 9

SPECIFICATIONS
EXTERIOR51-31
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONSM1511015300279
SERVICE SPECIFICATIONSM1511000300358
ADHESIVEM1511000500448
ITEM SPECIFICATION
Front bumper
License plate screw 0.9
0.1 Nm (8 1 in-lb)
Windshield wiper and washer
Wiper arm and blade assembly nut 37
3.0 Nm (27 1 ft-lb)
Wiper link assembly to Body bolt 8.0
2.0 Nm
Wiper motor to link assembly screw 7.5
1.0 Nm (66 13 in-lb)
Washer tank bolt 12
1.0 Nm (102 15 in-lb)
Door mirror
Remote controlled mirror assembly bolt 5.0
1.0 Nm (44 9 in-lb)
ITEM STANDARD VALUE
Windshield wiper blade (RH) park position 38
5 mm (1.50 0.20 inches)
Windshield wiper blade (LH) park position 38
5 mm (1.50 0.20 inches)
ITEM SPECIFICATION
Door side protector molding Adhesive tape: Double-sided tape
8.0 mm (0.32 inch) width and 1.2 mm (0.05 inch)
thickness
Roof drip molding Adhesive tape: Double-sided tape
10.0 mm (0.39 inch) width and 1.52 mm (0.06 inch)
thickness
