2005 MITSUBISHI 380 Workshop Manual

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-26
COMMENT
This may be caused by faults in the CAN bus line,
the combination meter or the ABS/TCL-ECU.
.
TROUBLESHOOTING HINTS
Malfunction of the combination meter.
Damaged harness or connector.
Malfunction of the ABS/TCL-ECU.
DIAGNOSIS
Required Special Tools:
MB991958: Diagnostic Tool (MUT-III Sub Assembly)
MB991824: V.C.I.
MB991827: MUT-III USB Cable
MB991910: MUT-III Main Harness A
STEP 1. Using diagnostic tool MB991958, diagnose the
CAN bus line.
To prevent damage to diagnostic tool MB991958, always
turn the ignition switch to the "LOCK" (OFF) position
before connecting or disconnecting diagnostic tool
MB991958.
(1) Connect diagnostic tool MB991958 to the data link
connector. (Refer to P.13C-3).
(2) Turn the ignition switch to the "ON" position.
(3) Diagnose the CAN bus line. (Refer to P.13C-3).
(4) Turn the ignition switch to the "LOCK" (OFF) position.
(5) Disconnect diagnostic tool MB991958.
Q: Is the check result satisfactory?
YES : Go to Step 2
NO : Repair the CAN bus lines. (Refer to GROUP 54C,
Diagnosis
Can Bus Diagnostic Chart P.54C-15).
Then go to Step 4.

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-27
STEP 2. Using diagnostic tool MB991958, read the
diagnostic trouble code.
To prevent damage to diagnostic tool MB991958, always
turn the ignition switch to the "LOCK" (OFF) position
before connecting or disconnecting diagnostic tool
MB991958.
(1) Connect diagnostic tool MB991958 to the data link
connector. (Refer to P.13C-3).
(2) Turn the ignition switch to the "ON" position.
(3) Use diagnostic tool MB991958 to read the TCL diagnostic
trouble codes. (Refer to P.13C-3).
(4) Turn the ignition switch to the "LOCK" (OFF) position.
(5) Disconnect diagnostic tool MB991958.
Q: Is any DTC set?
YES : Refer to P.13C-8, Diagnostic Trouble Code Chart.
Then go to Step 4.
NO : Go to Step 3.
STEP 3. Using diagnostic tool MB991958, read the
diagnostic trouble code.
To prevent damage to diagnostic tool MB991958, always
turn the ignition switch to the "LOCK" (OFF) position
before connecting or disconnecting diagnostic tool
MB991958.
(1) Connect diagnostic tool MB991958 to the data link
connector. (Refer to P.17-11).
(2) Turn the ignition switch to the "ON" position.
(3) Check for Combination meter system diagnostic trouble
code. (Refer to GROUP 54A, Combination Meter Assembly
Diagnosis
Diagnosis Function How to Read and Erase
Diagnostic Trouble Code P.54A-46).
(4) Turn the ignition switch to the "LOCK" (OFF) position.
(5) Disconnect diagnostic tool MB991958.
Q: Is DTC U1102 set?
YES : Replace the hydraulic unit (integrated with
ABS/TCL-ECU). (Refer to GROUP 35B
Hydraulic
Unit P.35B-93). Then go to Step 4.
NO : Replace the combination meter assembly. (Refer to
GROUP 54A
Combination Meter Assembly
P.54A-142). Then go to Step 4.

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-28
STEP 4. Retest the system
Q: Turn the ignition switch to the "ON" position. Do the
"TCL OFF" indicator light and the TCL work indicator
light illuminate for three seconds, and then go out after
the engine starts?
YES : The procedure is complete.
NO : . Return to Step 1.
INSPECTION PROCEDURE 5: When the TCL Switch is Pushed On, TCL does not Cancel.
NOTE: If the ABS-8 ECU or the active wheel
speed sensor are disconnected, or if the wiring is
an open/ short circuit, the ABS 8 ECU will shut
off power supply to the respective wheel speed
sensor. All other wheel speed sensors will oper-
ate normally. To restore the power supply, the
ignition switch must be turned to the "OFF" posi-
tion then to the "ON" position again.
.
CIRCUIT OPERATION
ABS/TCL-ECU terminal 21 is grounded every time
the TCL switch is pressed. ABS/TCL-ECU monitors
this operation state and turns the TCL ON or OFF.
.
COMMENT
The cause is probably an open-circuit in the TCL
switch circuit.
.
TROUBLESHOOTING HINTS
Malfunction of the TCL switch.
Damaged harness or connector.
Malfunction of the ABS/TCL-ECU.
DIAGNOSIS
Required Special Tools:
MB991223: Harness Set
MB991219: Inspection Test Harness

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-29
STEP 1. Measure the resistance at ABS/TCL-ECU
connector A-02.
(1) Disconnect the ABS/TCL-ECU connector A-02.
(2) Measure the resistance at the ABS/TCL-ECU wiring
harness-side connector A-02 using the Inspection test
harness MB991219 (by inserting probe) and body ground.
NOTE: The special tool (Inspection test harness)
MB991219 for connector pin contact pressure should be
used. The test probe should never be forcibly inserted, as it
may cause a defective contact.
(3) Turn the ignition switch to the "OFF" position.
(4) Measure the resistance by probing ABS/TCL-ECU
connector A-02 terminal 21 (using inspection test harness
MB991219) and ground.
NOTE: The special tool (Inspection test harness)
MB991219 for connector pin contact pressure should be
used. The test probe should never be forcibly inserted, as it
may cause a defective contact.
When the TCL switch is not pressed, the resistance
should indicate an open circuit (more than 2 ohms).
When the TCL switch is pressed, the resistance should
measure 2 ohms or less.
(5) Turn the ignition switch to the "LOCK" (OFF) position.
(6) Disconnect inspection test harness MB991219.
(7) Connect the ABS/TCL-ECU connector A-02.
Q: Is the resistance value more than 2 ohms when the TCL
switch is not pressed, and is the resistance value less
than 2 ohms when the TCL switch is pressed?
YES : Go to Step 6.
NO : Go to Step 2.

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-30
STEP 2. Check the TCL switch.
(1) Remove the TCL switch. (Refer to P.13C-49).
(2) Connect an ohmmeter to the TCL switch between terminals
1 and 2.
(3) Check for continuity between terminals 1 and 2 when the
TCL switch is operated.
There is no continuity between terminals 1 and 2 when
the TCL switch is not pressed.
There is continuity between terminals 1 and 2 when the
TCL switch is pressed.
Q: Is there no continuity between terminals 1 and 2 when
the TCL switch is not pressed, and is there continuity
when the TCL switch is pressed?
YES : Install the TCL switch. (Refer to P.13C-49). Then go
to Step 3.
NO : Replace the TCL switch. (Refer to P.13C-49). Then
go to Step 7.

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-31
STEP 3. Check ABS/TCL-ECU connector A-02,
intermediate connector C-29 and TCL switch connectors
C-131 for loose, corroded or damaged terminals, or
terminals pushed back in the connector.
Q: Are there connectors and terminals in good condition?
YES : Go to Step 4.
NO : Repair or replace the faulty connector. (Refer to
GROUP 00E, Harness Connector Inspection
P.00E-2). Then go to Step 7.

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-32
STEP 4. Check the harness wire between ABS/TCL-ECU
connector A-02 terminal 21 and TCL switch connector
C-131 terminal 1 for damage.
Q: Are there harness wires in good condition?
YES : Go to Step 5.
NO : Repair the damaged harness wire. Then go to Step 7.

TRACTION CONTROL SYSTEM (TCL) DIAGNOSIS
TRACTION CONTROL SYSTEM (TCL)13C-33
STEP 5. Check the harness wire between TCL switch
connector C-131 terminal 2 and ground for damage.
Q: Is the harness wire in good condition?
YES : Go to Step 6.
NO : Repair the damaged harness wire. Then go to Step 7.
STEP 6. Retest the system
Q: Does TCL system cancel, when the TCL switch is
pushed on?
YES : It can be assumed that this malfunction is intermittent.
(Refer to GROUP 00, How to Use
Troubleshooting/Inspection Service Points
How to
Cope with Intermittent Malfunction P.00-14).
NO : Replace the hydraulic unit (integrated with
ABS/TCL-ECU). (Refer to GROUP 35B
Hydraulic
Unit P.35B-93). Then go to Step 7.
STEP 7. Retest the system
Q: Does TCL system cancel, when the TCL switch is
pushed on?
YES : The procedure is complete.
NO : Return to Step 1.
