Page 7 of 1500
GENERAL DESCRIPTION
SIMPLIFIED WIRING SYSTEM (SWS)54B-7
SEAT BELT INDICATOR
If any of the following conditions is met with the igni-
tion switch at "ON" or "ST", the ETACS-ECU illumi-
nates, flashes or extinguishes the seat belt indicator
by using the driver's seat belt switch signal and the
vehicle speed signal sent from the combination
meter.
Illuminates when the ignition switch is at "ON"
and the seat belt switch is turned on (the driver's
seat belt is unfastened).
Flashes and illuminates the indicator 12 cycles
(after 0.5 seconds) if any of the following condi-
tions is met when sixty seconds or more have
elapsed since the ignition switch is turned "ON".
One cycle consists of five-second "flashing" and
then three-second "illumination".
a. The vehicle speed has reached 8 km/h (5
mph) while the seat belt switch is turned on
(driver's seat belt is not fastened) with the
ignition switch "ON.
b. The seat belt switch has been turned on
(driver's seat belt has not been fastened) for
at least ten seconds while the ignition switch
has been turned "ON" and the vehicle speed
has been 8 km/h (5 mph) or more.
NOTE: Once this timer operation has been acti-
vated, it will not be activated again until the
vehicle speed reduces to 3 km/h (2 mph) or
less even if any of the following conditions is
met.
The indicator stops illuminating if the ignition
switch or the seat belt switch is turned off (the
driver's seat belt is fastened) while the timer
operation is active.
DOOR-AJAR INDICATOR LAMP
The combination meter receives the signal sent from
the ETACS-ECU about whether each door or trunk is
open or closed and turns the door ajar indicator lamp
on and off. While the door ajar indicator is illumi-
nated, the door ajar warning function is activated and
the door ajar indicator lamp flashes 4 times. If the
door remains open even after the 4 warning flashes,
the door ajar indicator lamp will be illuminated again.
CONFIGURATION FUNCTION
The following functions can be adjusted by operating
the middle-grade multi center display (if equipped).
Keyless entry horn answerback function
Keyless entry hazard lamp answerback function
Timed locking mechanism
Turn-signal lamp buzzer
Door ajar warning buzzer
Adjustment of door unlocking operation on key-
less entry system
Vehicle speed-dependent wiper function
Headlamp automatic shutdown function
Delay-off time of the dome lamp
Interior lamp automatic shutoff function
Initialisation of above mentioned functions
Page 534 of 1500
FRONT SEAT TRIM COVER
INTERIOR52A-45
3. Pull the cover over the outside of the pad and reattach the
retaining clips where required.
NOTE: It may be necessary to make some adjustment and
work the cover into position to remove creases. Reassemble
seat and fit to vehicle.
Page 547 of 1500
FRONT SEAT BELT
INTERIOR52A-58
FRONT SEAT BELT
REMOVAL AND INSTALLATIONM1523001300370
SRS: Before removing and installing the seat belts with pre-tensioner, refer to GROUP 52B, Seat
Belt with Pre-tensioner P.52B-250.
NOTE:
*If so equipped
Pre-removal and Post-installation Operation
Turn the ignition key to the LOCK (OFF) position.
Disconnect the negative battery terminal.Post-installation Operation
Adjustment Procedures of Special Function (refer to GROUP
52B, On-Vehicle Service P.52B-250.)
1. EXTENDER SEAT BELT
ASSEMBLY*
OUTER SEAT BELT REMOVAL
STEPS
2. SASH GUIDE COVER
CENTER PILLAR TRIM LOWER
(REFER TO P.52A-11.)
3. OUTER SEAT BELT (REFER TO
GROUP 52B, SEAT BELTS WITH
PRE-TENSIONER P.52B-250.)4. CENTER PILLAR TRIM UPPER
(REFER TO P.52A-11.)
5. ADJUSTABLE SEAT BELT ANCOR
INNER SEAT BELT
6. SEAT BELT SWITCH
CONNECTOR
SHIELD COVER (REFER TO
P.52A-33.)
7. INNER SEAT BELTOUTER SEAT BELT REMOVAL
STEPS (Continued)
Page 1208 of 1500
36-1
GROUP 36
PARKING BRAKES
CONTENTS
GENERAL DESCRIPTION. . . . . . . . .36-2
PARKING BRAKE DIAGNOSIS . . . .36-2
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . 36-2
TROUBLESHOOTING STRATEGY . . . . . . 36-2
SYMPTOM CHART. . . . . . . . . . . . . . . . . . . 36-2
SYMPTOM PROCEDURES . . . . . . . . . . . . 36-3
ON-VEHICLE SERVICE . . . . . . . . . . .36-3
PARKING BRAKE LEVER STROKE CHECK
AND ADJUSTMENT . . . . . . . . . . . . . . . . . . 36-3
PARKING BRAKE SWITCH CHECK . . . . . 36-5
PARKING BRAKE LINING SEATING
PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . 36-5
PARKING BRAKE LEVER . . . . . . . . .36-6
REMOVAL AND INSTALLATION . . . . . . . . 36-6
PARKING BRAKE CABLE . . . . . . . . .36-7
REMOVAL AND INSTALLATION . . . . . . . . 36-7
PARKING BRAKE LINING AND
DRUM . . . . . . . . . . . . . . . . . . . . . . . . .36-8
REMOVAL AND INSTALLATION . . . . . . . . 36-8
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . 36-11
SPECIFICATIONS . . . . . . . . . . . . . . .36-12
FASTENER TIGHTENING SPECIFICATIONS36-12
SERVICE SPECIFICATIONS . . . . . . . . . . . 36-12
LUBRICANT . . . . . . . . . . . . . . . . . . . . . . . . 36-12
Page 1210 of 1500
ON-VEHICLE SERVICE
PARKING BRAKES36-3
SYMPTOM PROCEDURES
INSPECTION PROCEDURE 1: Insufficient Parking Brake Function
DIAGNOSIS
STEP 1. Check the excessive parking brake lever
stroke.
Refer to P.36-3.
Q: Is the parking brake lever stroke adjusted
properly?
YES :
Go to Step 2.
NO : Adjust the parking brake lever stroke or
check the parking brake cable routing. Then
go to Step 5.
STEP 2. Check the parking brake cable for
sticking.
Q: Is the parking brake cable stuck?
YES :
Replace the cable. Then go to Step 5.
NO : Go to Step 3.
STEP 3. Check the brake lining and brake drum
for wear.
Refer to P.36-11.
Q: Is the brake lining thickness or brake drum inside
diameter outside of specification?
YES :
Replace the rear brake shoe assembly or
rear brake disc (Refer to P.36-8). Then go to
Step 5.
NO : Go to Step 4.
STEP 4. Check for oil, water, etc., on the lining
contact surfaces.
Q: Is oil, water, etc., on the lining contact surface?
YES :
Replace the part and determine and repair
source/cause of foreign material. Then go to
St e p 5.
NO : Carry out the parking brake lining seating
(Refer to P.36-5) and then go to Step 5.
STEP 5. Retest the system.
Q: Is the malfunction eliminated?
YES :
The procedure is complete.
NO : Recheck from Step 1.
ON-VEHICLE SERVICE
PARKING BRAKE LEVER STROKE CHECK AND
ADJUSTMENT
M1361000900362
1. Pull the parking brake lever with a force of approximately
200 N (45 pounds) and count the number of notches.
Standard value: 5
7 notches
2. If the parking brake lever stroke is not within the standard
value, adjust as described below.
(1) Release the parking brake.
Page 1215 of 1500
