DODGE RAM 2003 Service Repair Manual OUTPUT SPEED SENSOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 T14 18LG/WT OUTPUT SPEED SENSOR SIGNAL
2 T13 18DB/BK SPEED SENSOR GROUND
OVERDRIVE SWITCH - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 T6 20OR/WT OVERD

Page 1146 of 2895

DODGE RAM 2003 Service Repair Manual OXYGEN SENSOR 1/2 DOWNSTREAM - NATURAL 4 WAY
CAV CIRCUIT FUNCTION
1 A141 18DG/WT (EXCEPT CALIFORNIA) FUSED AUTO SHUT DOWN RELAY OUTPUT
1 A42 18DG (CALIFORNIA) OXYGEN SENSOR RELAY OUTPUT
1 K199 18BR/VT

Page 1147 of 2895

DODGE RAM 2003 Service Repair Manual PARK/TURN SIGNAL LAMP-LEFT FRONT - BROWN 3 WAY
CAV CIRCUIT FUNCTION
1 L61 18LG LEFT FRONT TURN LAMP DRIVER
2 Y174 18PK/VT FUSED PARK LAMP RELAY OUTPUT
3 Z148 18DB/BK GROUND
PARK/TURN SIGNAL LAMP-RIGHT

Page 1148 of 2895

DODGE RAM 2003 Service Repair Manual POWER MIRROR-RIGHT - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 F121 18TN/BK HEATED MIRROR RELAY OUTPUT
2 P76 20OR/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 P74 20DB RIGHT MIRROR LEFT DRIVER
4 P72 20YL/BK R

Page 1149 of 2895

DODGE RAM 2003 Service Repair Manual POWER SEAT MOTOR-DRIVER HORIZONTAL - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 P17 12RD/LB LEFT SEAT HORIZONTAL REARWARD
2 P15 12YL/LB LEFT SEAT HORIZONTAL FORWARD
POWER SEAT MOTOR-DRIVER REAR VERTICAL-2WAY

Page 1150 of 2895

DODGE RAM 2003 Service Repair Manual POWER STEERING PRESSURE SWITCH (3.7L/4.7L/5.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z244 20BK/DG GROUND
2 S28 18YL/BK P/S SWITCH SIGNAL
POWER WINDOW MOTOR-DRIVER - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1

Page 1151 of 2895

DODGE RAM 2003 Service Repair Manual POWER WINDOW SWITCH-LEFT REAR - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q13 14DB DRIVER REAR WINDOW DRIVER (UP)
2 Q27 14RD/BK LEFT REAR WINDOW DRIVER (DOWN)
3- -
4 Q17 14DB/WT LEFT REAR WINDOW DRIVER (UP)
5

Page 1152 of 2895

DODGE RAM 2003 Service Repair Manual POWERTRAIN CONTROL MODULE - C1 (DIESEL) - 32 WAY
CAV CIRCUIT FUNCTION
24 - -
25 - -
26 - -
27 - -
28 - -
29 - -
30 - -
31 Z82 14BK/TN GROUND
32 Z81 14BK/TN GROUND
POWERTRAIN CONTROL MODULE - C2 (DIESE
