DODGE RAM 2003 Service Repair Manual 8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
Automatic Day/Night Mirror........ 8W-31-7, 15
Brake Lamp Switch................. 8W-31-17
Clockspring........................ 8W-31-18
Clutch Interloc

8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
Automatic Day/Night Mirror........ 8W-31-7, 15
Brake Lamp Switch................. 8W-31-17
Clockspring........................ 8W-31-18
Clutch Interlock Brake Switch......... 8W-31-20
Data Link Connector....... 8W-31-5, 8, 17, 19, 25
Engine Control Module............ 8W-31-18, 19
Front Control Module.............. 8W-31-7, 10
Fuse 5.................... 8W-31-2, 10, 13, 16
Fuse 19........................... 8W-31-18
Fuse 28........................... 8W-31-23
Fuse 38...................... 8W-31-7, 10, 15
Fuse 43........................... 8W-31-20
Fuse 50........................... 8W-31-16
G107......................... 8W-31-2, 4, 10
G117............................. 8W-31-19
G201..................... 8W-31-9, 11, 19, 23
G203.......................... 8W-31-20, 25
Ignition Switch...................... 8W-31-5
Input Speed Sensor............... 8W-31-6, 14
Instrument Cluster............. 8W-31-5, 15, 23
Integrated Power Module . . . 8W-31-2, 7, 10, 13, 15,
16, 18, 20, 23
Line Pressure Sensor................. 8W-31-6
Output Speed Sensor........ 8W-31-6, 13, 14, 16Component Page
Overdrive Switch.............. 8W-31-9, 11, 19
Powertrain Control
Module . . 8W-31-3, 5, 8, 9, 10, 11, 12, 13, 14, 15,
16, 17, 18, 19
Speed Control Servo................. 8W-31-17
Speed Control Switch-Left............ 8W-31-18
Speed Control Switch-Right........... 8W-31-18
Starter Motor Relay................. 8W-31-20
Tail/Stop/Turn Signal Lamp-Left........ 8W-31-7
Tail/Stop/Turn Signal Lamp-Right....... 8W-31-7
Throttle Position Sensor............... 8W-31-9
Transfer Case Control
Module........... 8W-31-20, 21, 22, 23, 24, 25
Transfer Case Mode Sensor........ 8W-31-21, 22
Transfer Case Selector Switch...... 8W-31-23, 24
Transfer Case Shift Motor............ 8W-31-25
Transmission Control
Module.............. 8W-31-2, 3, 4, 5, 6, 8, 9
Transmission Control Relay . . . 8W-31-2, 10, 13, 16
Transmission Range Sensor........... 8W-31-15
Transmission Solenoid Assembly.... 8W-31-13, 16
Transmission Solenoid/TRS
Assembly........ 8W-31-2, 3, 4, 6, 7, 10, 11, 12
DR8W-31 TRANSMISSION CONTROL SYSTEM 8W - 31 - 1
