Page 1105 of 2895

DODGE RAM 2003 Service Repair Manual C313 - (DRIVER SEAT TO JUMPER)
CAV CIRCUIT
1 F37 12RD/LB
2 Z238 14BK
3 P106 12DG/WT
4 P13 12RD/WT
5 P107 12OR/BK
6 Z88 14BK/LB
7 F37 12RD/LB
8 P11 12YL/WT
9 P17 12RD/LB
10 P15 12YL/LB
11 P21 12RD/LG
1

Page 1106 of 2895

DODGE RAM 2003 Service Repair Manual C315 - (JUMPER TO DRIVER SEAT)
CAV CIRCUIT
1 Z121 20BK/WT
2 P142 18TN/DB
3 P37 12RD/LB
4 P144 20BK/LG
5 P86 20PK/BK
6 Z238 14BK
C316 - (JUMPER TO PASSENGER SEAT)
CAV CIRCUIT
1 Z121 20BK/WT
2 P142 18TN

Page 1107 of 2895

DODGE RAM 2003 Service Repair Manual C317 - (SEAT SWITCH PASSENGER SEAT)
CAV CIRCUIT
1 Z238 18BK
2 P105 12LG/DB
3 F37 12RD/LB
4 P104 12YL/LB
5 Z238 18BK
6-
C319 - (JUMPER TO POWER POINT)
CAV CIRCUIT
1 Y148 16BR/YL
2 Z300 16BK/WT
C319 - (

Page 1108 of 2895

DODGE RAM 2003 Service Repair Manual C322 - (BODY TO SEAT)
CAV CIRCUIT
1 F235 18RD
2 P137 20VT/DG
3 P133 20TN/DG
4 G10 20LG/RD
5 P139 20VT/WT
6 P138 20VT/LG
7 Z238 14BK
8 F37 12RD/LB
9 P134 20TN/LG
10 P140 20VT/BK
11 Z237 20BK/OR
12 Z121

Page 1109 of 2895

DODGE RAM 2003 Service Repair Manual C327 - BLACK (CHASSIS TO
DUAL-REAR-WHEELS)
CAV CIRCUIT
1 Y174 20PK/VT
2 Z57 20BK
C327 - BLACK (DUAL-REAR-WHEELS TO
CHASSIS)
CAV CIRCUIT
1 Y174 18PBK/YL
2 Z57 18BK
C328 - BLACK (CHASSIS TO
DUAL-REAR-WH

Page 1110 of 2895

DODGE RAM 2003 Service Repair Manual CAPACITOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 A142 16DG/OR AUTO SHUT DOWN RELAY OUTPUT
2- -
CENTER HIGH MOUNTED STOP LAMP/CARGO LAMP-4WAY
CAV CIRCUIT FUNCTION
1 F32 18RD/YL FUSED B(+)
2 M3 20PK/DB CA

Page 1111 of 2895

DODGE RAM 2003 Service Repair Manual CLEARANCE LAMP NO. 3 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L7 20BK/YL HEADLAMP SWITCH OUTPUT
2 Z253 20BK/RD GROUND
CLEARANCE LAMP NO. 4 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L7 20BK/YL HEADLAMP

Page 1112 of 2895

DODGE RAM 2003 Service Repair Manual CLOCKSPRING C3 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
B1 X3 20BK/RD HORN RELAY CONTROL
B2 K4 20BK/LB SENSOR GROUND
B3 V37 20RD/LG S/C SWITCH NO.1 SIGNAL
B4 V38 20VT/OR (ELECTRONIC
TRANSMISSION CONTROL)SPE
