Page 2673 of 2895

DODGE RAM 2003 Service Repair Manual NOTE: All measurements are in mm. O/F = Over Flush U/F = Under Flush DIMENSION DESCRIPTION GAP FLUSH 1 Tailgate to outer box (Up/Down surface only)Ð 0.0   1.5 Parallel within 1.0 2 Cab Back to box f

Page 2674 of 2895

DODGE RAM 2003 Service Repair Manual OPENING DIMENSIONS SPECIFICATIONS - BODY OPENING DIMENSIONS INDEX DESCRIPTION FIGURE WINDSHIELD OPENING 4 DOOR OPENING - STANDARD CAB5 DOOR OPENINGS - QUAD CAB 6 REAR WINDOW OPENING 7 ENGINE COMPARTME

Page 2675 of 2895

DODGE RAM 2003 Service Repair Manual Fig. 5 DOOR OPENING - STANDARD CAB Fig. 6 DOOR OPENINGS - QUAD CAB 23 - 100 BODY STRUCTUREDR OPENING DIMENSIONS (Continued)

Page 2676 of 2895

DODGE RAM 2003 Service Repair Manual Fig. 7 REAR WINDOW OPENING DRBODY STRUCTURE 23 - 101 OPENING DIMENSIONS (Continued)

Page 2677 of 2895

DODGE RAM 2003 Service Repair Manual Fig. 8 ENGINE COMPARTMENT/FRONT STRUCTURE 23 - 102 BODY STRUCTUREDR OPENING DIMENSIONS (Continued)

Page 2678 of 2895

DODGE RAM 2003 Service Repair Manual SEALER LOCATIONS SPECIFICATIONS INDEX DESCRIPTION FIGURE LOWER WINDSHIELD PILLAR, LOWER PLENUM AND COWL BAR 9 DASH PANEL, LOWER PLENUM AND COWL SIDE PANEL 10 LOWER DASH PANEL, LOWER COWL SIDE AND FLOO

Page 2679 of 2895

DODGE RAM 2003 Service Repair Manual Fig. 10 DASH PANEL 23 - 104 BODY STRUCTUREDR SEALER LOCATIONS (Continued)

Page 2680 of 2895

DODGE RAM 2003 Service Repair Manual Fig. 11 LOWER DASH PANEL DRBODY STRUCTURE 23 - 105 SEALER LOCATIONS (Continued)
