DODGE RAM 2003 Service Repair Manual COIL ON PLUG NO. 2 (3.7L/4.7L/5.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K92 18TN/PK COIL ON PLUG DRIVER NO. 2
1 A142 16DG/OR (NGC) ASD RELAY OUTPUT
2 A142 16DG/OR AUTO SHUT DOWN RELAY OUTPUT
2 K92 18

Page 1114 of 2895

DODGE RAM 2003 Service Repair Manual COIL ON PLUG NO. 6 (3.7L/4.7L/5.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K96 18TN/LB COIL ON PLUG DRIVER NO. 6
1 A142 16DG/OR (NGC) ASD RELAY OUTPUT
2 A142 16DG/OR AUTO SHUT DOWN RELAY OUTPUT
2 K96 18

Page 1115 of 2895

DODGE RAM 2003 Service Repair Manual CONDENSER FAN - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 Z212 16LG/BK GROUND
2 C23 16DG CONDENSER FAN RELAY OUTPUT
CONTROLLER ANTILOCK BRAKE C1 - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 B113 20RD/VT REAR WHEEL

Page 1116 of 2895

DODGE RAM 2003 Service Repair Manual CRANKSHAFT POSITION SENSOR - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K24 18GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
1 K7 18OR (5.7L) 5 VOLT SUPPLY
1 K24 18GY/BK (4.7L/) CKP SIGNAL
2 K4 18BK/LB (3.7L/4.7L/5.

Page 1117 of 2895

DODGE RAM 2003 Service Repair Manual DATA LINK CONNECTOR - ENGINE (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
A D1 18VT/BR CCD BUS (+)
B D2 18WT/BK CCD BUS (-)
C Z11 14BK/WT GROUND
DOME LAMP - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1- -
2 M20 20BR COUR

Page 1118 of 2895

DODGE RAM 2003 Service Repair Manual DOOR AJAR SWITCH-RIGHT REAR (BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G76 20VT/OR RIGHT REAR DOOR AJAR SWITCH SENSE
2 Z74 20BK GROUND
DOOR LOCK MOTOR/AJAR SWITCH-DRIVER (EXCEPT BASE) - BLACK 4 WAY
C

Page 1119 of 2895

DODGE RAM 2003 Service Repair Manual DOOR LOCK MOTOR/AJAR SWITCH-RIGHT REAR (EXCEPT BASE) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 G76 20VT/OR RIGHT REAR DOOR AJAR SWITCH SENSE
2 Z74 20BK GROUND
3 Y156 18TN/OR DOOR UNLOCK DRIVER RIGHT DOORS

Page 1120 of 2895

DODGE RAM 2003 Service Repair Manual DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q28 14DG/WT RIGHT REAR WINDOW DRIVER (DOWN)
2 Q18 14GY/BK RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14BR/WT MASTER WINDOW SWITCH RIGHT FRONT (UP)
4
