Page 1097 of 2895

DODGE RAM 2003 Service Repair Manual C220 - (BODY TO I/P)
CAV CIRCUIT
1 Y105 20BR/RD
2 X91 18WT/BK
3 F32 18RD/YL
4 X87 18LG/RD
5 G75 20TN
6 G77 20VT/OR
7 X85 18LG/DG
8 G10 20LG/RD
9 G73 20LG/OR (EXCEPT BASE)
10 X93 18WT/RD
11 -
12 D25 20

Page 1098 of 2895

DODGE RAM 2003 Service Repair Manual C301 - WHITE (PASSENGER DOOR TO BODY)
CAV CIRCUIT
1 G74 20TN/RD
2 P76 20OR/YL
3 P72 20YL/BK
4 X82 18LB/RD
5 X80 18LB/BK
6 P74 20DB
7 Q1 14YL
8-
9-
10 Z315 20BK/LG
C302 - BLACK (BODY TO PASSENGER DOOR)

Page 1099 of 2895

DODGE RAM 2003 Service Repair Manual C304 - WHITE (BODY TO DRIVER DOOR)
CAV CIRCUIT
1 G75 20TN
2 P76 20OR/YL (EXCEPT BASE)
3 P72 20YL/BK (EXCEPT BASE)
4 X87 18LG/RD
5 X85 18LG/DG
6 P74 20DB (EXCEPT BASE)
7 F21 12TN (EXCEPT BASE)
8 Q1 12Y

Page 1100 of 2895

DODGE RAM 2003 Service Repair Manual C305 - BLACK (DRIVER DOOR TO BODY)
CAV CIRCUIT
1 F121 18TN/BK
2 Q16 14BR/WT
3 Q26 14VT/WT
4 Y157 18TN/PK
5-
6 P55 15DB
7 Z239 14BK/LB
8 Q28 14DG/WT
9-
10 P97 20WT/DG
11 G73 20LG/OR
12 Q18 14GY/BK
13 Q

Page 1101 of 2895

DODGE RAM 2003 Service Repair Manual C307 (TAIL LAMP JUMPER) - (CHASSIS TO TAIL
LAMPS)
CAV CIRCUIT
1 L7 18 BK/YL
2-
3 Z151 18 BK
4 L22 18LB/WT
5 L62 18BR/RD
6 L1 18VT/BK
C307 (TAIL LAMP JUMPER) - (TAIL LAMPS TO
CHASSIS)
CAV CIRCUIT
1 L7

Page 1102 of 2895

DODGE RAM 2003 Service Repair Manual C308 - WHITE (I/P TO BODY)
CAV CIRCUIT
1 G74 20TN/RD
2 G72 20DG/OR
3-
4 X80 18LB/BK
5 P96 20WT/LG
6 G76 20TN/YL
7-
8 Y200 18TN/VT
9 Y156 18TN/WT
10 Y107 20VT/RD
11 R53 18LG/YL
12 R55 18LG/DG
13 -
14 X

Page 1103 of 2895

DODGE RAM 2003 Service Repair Manual C310 (TAIL LAMP JUMPER) - (CHASSIS TO LEFT
TAIL)
CAV CIRCUIT
1 Y174 18PK/VT
2-
3 Z150 18BK
4 L24 18WT/LG
5 L63 18DG/RD
6 L1 18VT/BK
C310 (TAIL LAMP JUMPER) - (LEFT TAIL TO
CHASSIS)
CAV CIRCUIT
1 Y174

Page 1104 of 2895

DODGE RAM 2003 Service Repair Manual C312 - WHITE (BODY TO RIGHT REAR DOOR)
CAV CIRCUIT
1 Z74 20BK
2 G76 20TN/YL
3 Y200 18TN/VT
4 Y156 18TN/WT
5 Q1 14YL
6 Q18 14GY/BK
7 Q28 14 DG/WT
8 X92 18TN/BK
9 X94 18TN/VT
10 -
C312 - WHITE (RIGHT RE
