Removal and Installation
IWhen removing or installing the seat trim, carefully handle it to keep dirt out and avoid damage.
CAUTION:
IBefore removing the front seat, turn the ignition switch off, disconnect both battery cables and wait
at least 3 minutes (models with side air bag).
IDo not drop, tilt, or bump the side air bag module installed in the seat. Always handle it with care.
IDisconnect the side air bag harness connector and heated seat harness connector from under the
seat before removing the seat.
IDisconnect the side air bag harness connector before removing the seatback. Refer to RS-27,
ªFront Side Air Bag Moduleº for details.
FRONT SEAT
BT-34
Page 323 of 1767
NBT177
FRONT SEAT
Removal and Installation (Cont'd)
BT-35
Page 324 of 1767
Heated Seat
HFor Wiring Diagram, refer to EL-128, ªHEATED SEATº for details.
Active Head Restraint
The active head restraint system is designed so that the headrest
instantaneously moves towards the front upper direction by utiliz-
ing the force at the seatback during a rear-end collision.
As a result, the occupant's head is protected from being
overextended, reducing the chance for neck injury as much as
possible.
Seat with active head restraint have the labels shown in figures at
left.
OPERATION OUTLINE
When the seatback receives a sharp backward force during a rear-
end collision, the input plate moves with the link rotating center as
a pivot. The headrest will then move towards the front upper direc-
tion with the center of the sliding roller as a pivot.
As the backward force on the seatback is eliminated, spring tension
returns the headrest to its original position.
SBT014A
SBT888
FRONT SEAT
BT-36
Page 325 of 1767
Removal and Installation
IWhen removing or installing the seat trim, handle carefully to keep dirt out and avoid damage.
TYPE 1 (HARDTOP)
EBF024
SECOND SEAT
BT-37
Page 326 of 1767
TYPE 2 (WAGON)
EBF025
SECOND SEAT
Removal and Installation (Cont'd)
BT-38
Page 327 of 1767
Removal and Installation
NBF236
THIRD SEAT
BT-39
Page 328 of 1767
Removal and Installation
IAfter any adjustment, check sunroof operation and lid alignment.
IHandle finisher plate and glass lid with care so not to cause damage.
IIt is desirable for easy installation to mark each point before removal.
CAUTION:
IAlways work with a helper.
IRemove sunroof frame rear door opening.
SUNROOF LID ASSEMBLY
q1Open sunroof shade.
q
2Close sunroof lid, and remove adjustment screw covers.
q
3Remove the four adjuster screws
q
4Remove sunroof lid assembly.
SUNROOF ASSEMBLY
1. Remove headlining. For details, refer to ªROOF TRIMº, BT-20.
2. Disconnect interior lamp harness.
3. Disconnect front and rear drain hoses.
4. Remove nuts and bolts securing sunroof frame and motor to roof.
5. Remove sunroof assembly.
SUNROOF
