1996 TOYOTA RAV4 Service Repair Manual

BO10B−01
N11413
BO−32
− BODYREAR WIPER AND WASHER
1996 RAV4 (RM447U)
REMOVAL
1. REMOVE REAR WIPER ARM
2. REMOVE BACK DOOR UPPER COVER
3. REMOVE BACK DOOR TRIM BOARD
4. REMOVE SERVICE HOLE COVER
5. REMOVE REAR WIPER MOTOR ASSEMBLY
(a) Disconnect the connector, then loosen the 3 bolts.
(b) Remove the motor assembly.

BO10C−01
H02952
A B
− BODYREAR WIPER AND WASHER
BO−33
1996 RAV4 (RM447U)
ADJUSTMENT
INSPECT REAR WASHER NOZZLE
While operating the washer, check that the point where the
washer fluid hits the back door glass and the upsurge area are
within the range indicated by the circle.
AApprox. 174 mm (6.85 in.)
BApprox. 167 mm (6.57 in.)

BO10D−01
N11513
A
B BO−34
− BODYREAR WIPER AND WASHER
1996 RAV4 (RM447U)
INSTALLATION
1. INSTALL REAR WIPER MOTOR ASSEMBLY
(a) Install the wiper motor assembly.
(b) Torque the 3 bolts.
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
(c) Connect the connector.
2. INSTALL SERVICE HOLE COVER
3. INSTALL BACK DOOR TRIM BOARD
4. INSTALL BACK DOOR UPPER COVER
5. INSTALL REAR WIPER ARM
(a) Install the nut.
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
(b) Install the wiper arm and operate the wiper once and turn
the wiper switch OFF.
(c) Adjust the installation position of the wiper arm to the posi-
tion, as shown.
AApprox. 6.2 mm (0.24 in.)
BApprox. 184 mm (7.24 in.)

BO489−01
N17307
− BODYBODY OUTSIDE MOULDING
BO−35
1996 RAV4 (RM447U)
BODY OUTSIDE MOULDING
COMPONENTS

BO48A−01
N11441
N11442
N11443
N17309
BO−36
− BODYBODY OUTSIDE MOULDING
1996 RAV4 (RM447U)
REMOVAL
HINT:
Tape the screwdriver tip before using to pry parts.
1. REMOVE FRONT FENDER MOULDING
(a) Remove the fender liner.
(b) Remove the 3 screws.
(c) Using a screwdriver, pry out the clips and remove the
moulding.
2. REMOVE FRONT DOOR MOULDING
(a) Remove the 2 plug hole covers and 2 nuts.
(b) Using a moulding remover, pry loose the clips.
(c) Pull off the moulding by cutting the adhesive with a knife.
(d) Scrape off adhesive from the body with a cutter or sand-
paper.
If the clip remains on the body, turn the clip, then pull it out.
3. 3 Door models:
REMOVE REAR FENDER MOULDING
(a) Remove the 3 clips and 3 screws.
(b) Using a screwdriver, pry out the clips and remove the
moulding.
4. 5 Door models:
REMOVE REAR DOOR MOULDING
(a) Remove the 2 plug hole covers and 2 nuts.
(b) Using a screwdriver, pry out the clips and remove the
moulding.

N17310
− BODYBODY OUTSIDE MOULDING
BO−37
1996 RAV4 (RM447U)
5. 5 Door models:
REMOVE QUARTER OUTSIDE MOULDING
(a) Remove the 4 screws.
(b) Using a screwdriver, pry out the clips and remove the
moulding.

BO48B−01
BO−38
− BODYBODY OUTSIDE MOULDING
1996 RAV4 (RM447U)
INSTALLATION
Installation is in the reverse order of removal procedure (See page BO−36).

BO10N−01
H03769
Windshield Dam
 Stopper
Sun Visor
Holder
Inner Rear
View Mirror Cover
Sun Visor
Inner Rear
View Mirror
Personal Light
Personal Light Cover
Front Pillar Garnish
Hood to Cowl Top Seal
Wiper Arm
Cowl Top Vent ilat or
Louver Arm Cover
N·m (kgf·cm, ft·lbf) : Specified torque
 Non−reusable part  Windshield Moulding
20 (200, 15)
20 (200, 15)
Arm Cover
Wiper Arm
Holder
Front Pillar Garnish
− BODYWINDSHIELD
BO−39
1996 RAV4 (RM447U)
WINDSHIELD
COMPONENTS
