1996 TOYOTA RAV4 Service Repair Manual

SA0U5−02
F03767
ABS Speed
SensorRear Drive Shaft Rear Differential
Rear Brake Hub Bolt
Brake DrumCotter pin Lock Cap Parking Brake Cable
Bearing
Axle Hub
Pin
56 (570, 41)
15 (155, 11)
80, (820, 59)
206 (2,100, 152)

7.8 (80, 69 in.·lbf)
Backing Plate
N·m (kgf·cm, ft·lbf)
: Specified torque
Non−reusable part

8 (80, 69 in.·lbf)
Brake Line
− SUSPENSION AND AXLEREAR AXLE HUB (4WD)
SA−55
1996 RAV4 (RM447U)
REAR AXLE HUB (4WD)
COMPONENTS

SA0U6−02
R10700
SST
R10750
SA−56
− SUSPENSION AND AXLEREAR AXLE HUB (4WD)
1996 RAV4 (RM447U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 103 N·m (1,050 kgf·cm, 76 ft·lbf)
2. REMOVE BRAKE DRUM
3. CHECK BEARING BACKLASH AND AXLE HUB DEVI-
ATION (See page SA−52)
4. REMOVE BOLT AND ABS SPEED SENSOR
Torque: 8 N·m (80 kgf·cm, 69 in.·lbf)
5. REMOVE REAR DRIVE SHAFT (See page SA−62)
6. DISASSEMBLE REAR BRAKE (See page BR−30)
7. DISCONNECT BRAKE LINE
Using SST, disconnect the brake line from the wheel cylinder.
SST 09023−00100
Torque: 15 N·m (155 kgf·cm, 11 ft·lbf)
8. REMOVE REAR AXLE HUB WITH BACKING PLATE
(a) Remove the 2 bolts and disconnect the parking brake
cable.
Torque: 8 N·m (80 kgf·cm, 69 in.·lbf)
(b) Remove the 4 bolts and rear axle hub.
Torque: 80 N·m (820 kgf·cm, 59 ft·lbf)

SA0U7−01
R10738
SST
SST
R10739
SSTSST
− SUSPENSION AND AXLEREAR AXLE HUB (4WD)
SA−57
1996 RAV4 (RM447U)
DISASSEMBLY
REMOVE AXLE HUB FROM BEARING
(a) Using SST, remove the axle hub from the bearing.
SST 09950−60010 (09951−00370),
09950−40010 (09951−04020, 09952−04010,
09953−04020, 09954−04010, 09955−04060,
09957−04010, 09958−04010)
(b) Using SST, remove the inner race (outside) from the axle
hub.
SST 09950−60010 (09951−00370),
09950−40010 (09951−04020, 09952−04010,
09953−04020, 09954−04010, 09955−04060,
09957−04010, 09958−04010)

SA0U8−01
R10740
SST
SST SA−58
− SUSPENSION AND AXLEREAR AXLE HUB (4WD)
1996 RAV4 (RM447U)
REASSEMBLY
INSTALL AXLE HUB TO NEW BEARING
Using SST and a press, install the axle hub to a new bearing.
SST 09527−17011, 09550−60010 (09951−00530)
HINT:
Before install the bearing, place the backing plate on the axle
hub.

SA0U9−01
− SUSPENSION AND AXLEREAR AXLE HUB (4WD)
SA−59
1996 RAV4 (RM447U)
INSTALLATION
Installation is in the reverse order of removal (See page SA−56).
AFTER INSTALLATION, BLEED BRAKE SYSTEM (See page BR−4) AND CHECK FOR LEAKS

SA0UA−01
R10741
SST
R10751
SA−60
− SUSPENSION AND AXLEREAR WHEEL HUB BOLT
1996 RAV4 (RM447U)
REAR WHEEL HUB BOLT
REPLACEMENT
1. REMOVE REAR WHEEL
2. REMOVE BRAKE DRUM
3. REMOVE HUB BOLT
Using SST, remove the hub bolt.
SST 09628−10011
4. INSTALL HUB BOLT
Install a washer and nut to the hub bolt, as shown in the illustra-
tion, and install the hub bolt by tightening the nut.
5. INSTALL BRAKE DRUM
6. INSTALL REAR WHEEL
Torque: 103 N·m (1,050 kgf·cm, 76 ft·lbf)

SA0UB−06
Z19331
Rear Drive Shaft
ABS Speed Sensor
Lock CapCotter pin
Inboard Joint Tulip
Snap Ring
Boot Clamp
Outboard Joint Boot
Inboard Joint Boot Tripod
Outboard Joint with Drive Shaft
Dust Deflector
Boot Clamp
Boot Clamp
56 (570, 41)
8 (80, 69 in.·lbf)
206 (2,100, 152)




N·m (kgf·cm, ft·lbf) : Specified torque
Non−reusable part

− SUSPENSION AND AXLEREAR DRIVE SHAFT
SA−61
1996 RAV4 (RM447U)
REAR DRIVE SHAFT
COMPONENTS

R10041
SST
SA0UC−03
R10773Matchmarks SA−62
− SUSPENSION AND AXLEREAR DRIVE SHAFT
1996 RAV4 (RM447U)
REMOVAL
NOTICE:
The hub bearing could be damaged if it is subjected
to the vehicle weight, such as when moving the ve-
hicle with the drive shaft bearing removed. Therefore,
if it is absolutely necessary to place the vehicle
weight on the hub bearing, first support it with SST.
SST 09608−16042 (09608−02021, 09608−02041)
w/ ABS:
After disconnecting the drive shaft from the axle hub,
work carefully so as not to damage the sensor rotor
serrations on the drive shaft.
1. REMOVE REAR WHEEL
Torque: 103 N·m (1,050 kgf·cm, 76 ft·lbf)
2. w/ ABS:
REMOVE BOLT AND ABS SPEED SENSOR
Torque: 7.8 N·m (80 kgf·cm, 69 ft·lbf)
3. REMOVE DRIVE SHAFT LOCK NUT
(a) Remove the cotter pin and lock cap.
(b) With depressing the brakes, remove the nut.
Torque: 206 N·m (2,100 kgf·cm, 152 ft·lbf)
4. REMOVE DRIVE SHAFT
(a) Place matchmarks on the drive shaft and differential side
gear shaft.
(b) Remove the 4 nuts and washers, and disconnect the
drive shaft from the differential side gear shaft.
Torque: 56 N·m (570 kgf·cm, 41 ft·lbf)
(c) Remove the drive shaft from the axle carrier.
