1996 TOYOTA RAV4 Service Repair Manual

S01831
New Gasket
FI1654
Fulcrum Length
30 mm
SST
FI0420
O−Ring
Injector
GrommetDelivery PipeCORRECT
WRONG
P15485
O−Ring
Injector Grommet
O−Ring Insulator
− SFISFI SYSTEM
SF−3
1996 RAV4 (RM447U)
(b) When connecting the flare nut or union bolt on the high
pressure pipe union, observe the following procedures:
(1) Union Bolt Type:
Always use 2 new gaskets.
(2) Union Bolt Type:
Tighten the union bolt by hand.
(3) Union Bolt Type:
Tighten the union bolt to the specified torque.
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(4) Flare Nut Type:
Apply a light coat of engine oil to the flare nut, and
tighten the flare nut by hand.
(5) Flare Nut Type:
Using SST, tighten the flare nut to specified torque.
SST 09631−22020
NOTICE:
Do not rotate the fuel pipe, when tightening the flare nut.
Torque: 34 N·m (350 kgf·cm, 25 ft·lbf)
28 N·m (285 kgf·cm, 21 ft·lbf) for SST
HINT:
Use a torque wrench with a fulcrum length of 30 cm (11.81 in.).
(c) Observe the following precautions when removing and
installing the injectors.
(1) Never reuse the O−ring.
(2) When placing a new O−ring on the injector, take
care not to damage it in any way.
(3) Coat a new O−ring with spindle oil or gasoline be-
fore installing−never use engine, gear or brake oil.
(4) Install the injector to the delivery pipe and intake
manifold as shown in the illustration.

S01354
TOYOTA
Hand−Held Tester
S01830
Fuel Inlet Hose SF−4
− SFISFI SYSTEM
1996 RAV4 (RM447U)
(d) Check that there are no fuel leaks after performing main-
tenance anywhere on the fuel system.
(1) Connect the TOYOTA hand−held tester to the
DLC3.
(2) Turn the ignition switch ON and TOYOTA hand−
held tester main switch ON.
NOTICE:
Do not start the engine.
(3) Select the active test mode on the TOYOTA hand−
held tester.
(4) Please refer to the TOYOTA hand−held tester oper-
ator ’s manual for further details.
(5) If you have no TOYOTA hand−held tester, connect
the positive (+) and negative (−) leads from the bat-
tery to the fuel pump connector (See page
SF−5).
(6) Pinch the fuel inlet hose.
The pressure in the high pressure line will rise to
approx. 400 kPa (4 kgf/cm
2, 57 psi). In this state,
check that there are no leaks from any part of the
fuel system.
NOTICE:
Always pinch the hose. Avoid bending as it may cause the
hose to crack.
(7) Turn the ignition switch to LOCK.
(8) Disconnect the TOYOTA hand−held tester from the
DLC3.
(9) Start the engine.
NOTICE:
Keep cranking the engine until the air is removed from the
fuel line.
(10) After the engine starts, check again that there are
no fuel leaks.

S01354
TOYOTA
Hand−Held Tester
SF0Q5−03
S01830
Fuel Inlet Hose
S01827
− SFIFUEL PUMP
SF−5
1996 RAV4 (RM447U)
FUEL PUMP
ON−VEHICLE INSPECTION
1. CHECK FUEL PUMP OPERATION
(a) Connect the TOYOTA hand−held tester to the DLC3.
(b) Turn the ignition switch ON and TOYOTA hand−held tes-
ter main switch ON.
NOTICE:
Do not start the engine.
(c) Select the active test mode on the TOYOTA hand−held
tester.
(d) Please refer to the TOYOTA hand−held tester operator’s
manual for further details.
(e) If you have no TOYOTA hand−held tester, connect the
positive (+) and negative (−) leads from the battery to the
fuel pump connector (See page SF−5).
(f) Check that there is pressure in the fuel inlet hose from the
fuel filter.
HINT:
If there is fuel pressure, you will hear the sound of fuel flowing.
If there is no pressure, check the H−fuse, fuses, EFI main relay,
circuit opening relay, fuel pump, ECM and wiring connections.
(g) Turn the ignition switch to LOCK.
(h) Disconnect the TOYOTA hand−held tester from the
DLC3.
2. CHECK FUEL PRESSURE
(a) Check the battery positive voltage is above 12 V.
(b) Disconnect the negative (−) terminal cable from the bat-
tery.
(c) Remove the air cleaner assembly (See page ST−4).
(d) Remove the 2 bolts, and disconnect the engine comport-
ment R/B No.2 from the bracket on the body.
(e) Remove the union bolt and 2 gaskets, and disconnect the
fuel inlet hose from the fuel filter outlet.
CAUTION:
Put a shop towel under the fuel filter. Slowly loosen the
union bolt.

S01834
Gasket
SST (Union)
SST
Fuel Inlet Hose Gasket
SST (Union)
S01835
301 − 347 kPa
S01836
For 5 Minutes After Engine has Stopped
147 kPa
or More SF−6
− SFIFUEL PUMP
1996 RAV4 (RM447U)
(f) Install the fuel inlet hose and SST (pressure gauge) to the
fuel filter outlet with the 3 gaskets and SST (union bolt).
SST 09268−45012
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(g) Wipe off any splattered gasoline.
(h) Connect the TOYOTA hand−held tester to the DLC3.
(i) Reconnect the negative (−) terminal cable to the battery.
(j) Turn the ignition switch ON.
(k) Measure the fuel pressure.
Fuel pressure:
301 − 347 kPa (3.1 − 3.5 kgf/cm
2, 44 − 50 psi)
If pressure is high, replace the fuel pressure regulator.
If pressure is low, check these parts:
Fuel hoses and connections
Fuel pump
Fuel filter
Fuel pressure regulator
(l) Remove the TOYOTA hand−held tester from the DLC3.
(m) Start the engine.
(n) Measure the fuel pressure at idle.
Fuel pressure:
301 − 347 kPa (3.1 − 3.5 kgf/cm
2, 44 − 50 psi)
(o) Stop the engine.
(p) Check that the fuel pressure remains as specified for 5
minutes after the engine has stopped.
Fuel pressure:
147 kPa (1.5 kgf/cm
2, 21 psi) or more
If pressure is not as specified, check the fuel pump, pressure
regulator and/or injectors.
(q) After checking fuel pressure, disconnect the negative (−)
terminal cable from the battery and carefully remove the
SST to prevent gasoline from splashing.
SST 09268−45012
(r) Reconnect the fuel inlet hose with 2 new gaskets and the
union bolt.
Torque: 29 N·m (300 kgf·cm, 21 ft·lbf)
(s) Reconnect the negative (−) terminal cable to the battery.
(t) Check for fuel leakage (See page SF−1).
(u) Reinstall the engine comportment R/B No.2 and air clean-
er assembly.
3. CHECK FUEL PUMP
(a) Remove the LH rear seat assembly.
(b) Remove the floor service hole cover.

S01908
Ohmmeter
45
S01914
45
Battery
− SFIFUEL PUMP
SF−7
1996 RAV4 (RM447U)
(c) Disconnect the fuel pump and sender gauge connector.
(d) Inspect the fuel pump resistance.
Using an ohmmeter, measure the resistance between ter-
minals 4 and 5.
Resistance: At 20°C (68°F): 0.2 − 3.0 Ω
If the resistance is not as specified, replace the fuel pump.
(e) Inspect the fuel pump operation.
Connect the positive (+) lead from the battery to terminal
4 of the connector, and the negative (−) lead to terminal
5. Check that the fuel pump operates.
NOTICE:
These tests must be done quickly (within 10 seconds) to
prevent the coil burning out. Keep the fuel pump as far
away from the battery as possible. Always do the switching
at the battery side.
If operation is not as specified, replace the fuel pump or lead
wire.
(f) Reconnect the fuel pump and sender gauge connector.
(g) Reinstall the floor service hole cover.
(h) Reinstall the LH rear seat assembly.

SF0Q6−01
S01937
3 Door Vehicles
LH Rear Seat Assembly5 Door Vehicles
LH Rear Seat Assembly
37 (375, 27)
37 (375, 27)
Rear Seat Hinge Cover
Floor Service Hole Cover
29 (300, 22)
Fuel Pump & Sender
Gauge Connector
 Gasket
Fuel Suction w/ Pump &
Gauge AssemblyFuel Return
Vent Hose Gasket
Fuel Outlet Pipe
x 8
 GasketFuel Hose
Fuel Pump Connector
Ground Strap
Fuel Pump
Fuel Pump Filter
Rubber Cushion  Clip Fuel Pump Clamp
N·m (kgf·cm, ft·lbf) : Specified torque
 Non−reusable part SF−8
− SFIFUEL PUMP
1996 RAV4 (RM447U)
COMPONENTS

SF0Q7−02
S01828(a)
(b)
S01829
− SFIFUEL PUMP
SF−9
1996 RAV4 (RM447U)
REMOVAL
CAUTION:
Do not smoke or work near an open flame when working on
the fuel pump.
1. REMOVE LH REAR SEAT ASSEMBLY
2. REMOVE FLOOR SERVICE HOLE COVER
(a) Take out the floor carpet.
(b) Remove the 4 screws and service hole cover.
HINT:
At the time of installation, plaese refer to the following items.
Check for fuel leakage (See page SF−1).
3. DISCONNECT FUEL PUMP & SENDER GAUGE CON-
NECTOR
4. DISCONNECT FUEL PIPE AND HOSE FROM FUEL
SUCTION TUBE
CAUTION:
Remove the fuel filler cap to prevent the fuel from flowing
out.
(a) Remove the union bolt and 2 gaskets, and disconnect the
outlet pipe from the suction tube.
HINT:
At the time of installation, plaese refer to the following items.
Install the outlet pipe with 2 new gaskets and bolt.
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
(b) Disconnect the return vent hose from the suction tube.
5. REMOVE FUEL SUCTION w/ PUMP & GAUGE TUBE
ASSEMBLY
(a) Remove the 8 bolts.
Torque: 3.5 N·m (35 kgf·cm, 31 in.·lbf)
(b) Pull out the suction w/ pump & gauge tube assembly.
NOTICE:
Do not damage the fuel pump filter. Be careful that the arm
of the sender gauge should not bent.
(c) Remove the gasket from the set plate.
HINT:
At the time of installation, plaese refer to the following items.
Install a new gasket to the set plate.

SF0Q8−02
S01896
Pull
FI6376
SF−10
− SFIFUEL PUMP
1996 RAV4 (RM447U)
DISASSEMBLY
1. DISCONNECT FUEL PUMP CONNECTOR
2. REMOVE FUEL PUMP FROM FUEL PUMP BRACKET
(a) Disconnect the ground strap from the fuel pump clamp.
(b) Pull off the lower side of the fuel pump from the pump
bracket.
(c) Disconnect the fuel hose from the fuel pump, and remove
the fuel pump.
(d) Remove the rubber cushion from the fuel pump.
3. REMOVE FUEL PUMP CLAMP
4. REMOVE FUEL PUMP FILTER FROM FUEL PUMP
(a) Using a small screwdriver, remove the clip.
(b) Pull out the pump filter.
HINT:
At the time of installation, plaese refer to the following items.
Install the pump filter with a new clip.
