1996 TOYOTA RAV4 Service Repair Manual

MX05Y−01
Z17559
GasketO−Ring
Oil Strainer
Oil Pump Driven Rotor
Oil Pump Drive Gear Oil Pump Drive Rotor
Oil Pump Cover
Spring Holder Spring
Ball Relief Valve Transmission Oil Pump Case
N·m (kgf·cm, ft·lbf): Specified torque
 Non−reusable partOil Line Case
No.3 Oil Pipe
10 (105, 8)
10 (105, 8)
 MX−46
− MANUAL TRANSAXLEOIL PUMP (4WD)
1996 RAV4 (RM447U)
OIL PUMP (4WD)
COMPONENTS

MX05Z−01
− MANUAL TRANSAXLEOIL PUMP (4WD)
MX−47
1996 RAV4 (RM447U)
INSPECTION
(See page MX−45)

MX02I−02
Q06217
Shift Interlock Plate
Transmission Oil Baffle Shift Interlock Plate
No.1 Compression SpringControl Shaft Cover
Oil Seal
Snap Ring
No.1 Select Spring Seat
Slotted Spring Pin
No.1 Shift Inner Lever
Shift and Select Lever Shaft Snap Ring
Non−reusable part No.2 Select Spring SeatNo.2 Compression SpringNo.2 Shift Inner LeverSlotted Spring Pin
Apply MP grease
Dust Boot
 MX−48
− MANUAL TRANSAXLESHIFT AND SELECT LEVER SHAFT
1996 RAV4 (RM447U)
SHIFT AND SELECT LEVER SHAFT
COMPONENTS

MX060−01
Z17560
Transaxle Case Cover
Differential Spider
Differential Pinion
Differential Side Gear
Side Gear Thrust
Washer
Pinion Thrust Washer
 Tapered Roller Bearing
and Outer Race
Differential Right Case
Vehicle Speed Sensor Drive Gear
Differential Left Case
 Tapered Roller Bearing
and Outer Race Ring Gear
Oil Baffle
 Oil Seal x16
Shim  Oil Seal
54 (550, 40)
63 (640, 46)
N·m (kgf·cm, ft·lbf): Specified torque
 Non−reusable part

x16
 Precoated partStud Bolt
54 (550, 40)
124 (1,260, 91)
− MANUAL TRANSAXLEDIFFERENTIAL CASE (2WD)
MX−49
1996 RAV4 (RM447U)
DIFFERENTIAL CASE (2WD)
COMPONENTS

Q05166
SST
MX0DV−01
Z00281
Matchmarks
Z00284
MX−50
− MANUAL TRANSAXLEDIFFERENTIAL CASE (2WD)
1996 RAV4 (RM447U)
DISASSEMBLY
1. REMOVE TAPERED ROLLER BEARING
Using SST, remove the left and right bearings.
SST 09950−40010
2. REMOVE RING GEAR
(a) Place matchmarks on both the differential case and ring
gear.
(b) Remove the 16 bolts.
(c) Using a plastic hammer, tap the ring gear and remove it.
3. DISASSEMBLE DIFFERENTIAL CASE
(a) Place matchmarks on the differential right and left cases.
(b) Using a torx wrench (T50), remove the 16 torx screws.
(c) Using a plastic hammer, tap the differential left case.
(d) Remove the vehicle speed sensor drive gear from the dif-
ferential right case.
(e) Remove the 2 differential side gears, side gear thrust
washers, 4 differential pinions and pinion thrust washers
from the differential left case.

Z00286
MX0DW−01
Z00288
SST
Z00289
Q06288
SST
− MANUAL TRANSAXLEDIFFERENTIAL CASE (2WD)
MX−51
1996 RAV4 (RM447U)
REPLACEMENT
1. Transmission Case Side:
REPLACE OIL SEAL AND TAPERED ROLLER BEAR-
ING OUTER RACE
(a) Using a screwdriver, remove the oil seal.
(b) Remove the oil baffle.
(c) Using a brass bar and hammer, drive out the bearing out-
er race lightly and evenly.
(d) Remove the shim.
(e) Install the shim (See page MX−49).
HINT:
First select and install a shim of lesser thickness than before.
(f) Using SST and a press, install a new tapered roller bear-
ing outer race.
SST 09316−60011 (09316−00011, 09316−00041)
(g) Install the oil baffle.
HINT:
Install the oil baffle projection into the case side cutout.
(h) Using SST and a hammer, drive in a new oil seal.
SST 09223−15020, 09950−70010 (09951−07150)
(i) Coat the lip of oil seal with MP grease.

MT0659
Z01427
SST
Z00292
SST
Z00293
SST
Z00294
FIPG
MX−52
− MANUAL TRANSAXLEDIFFERENTIAL CASE (2WD)
1996 RAV4 (RM447U)
2. Transaxle Case Side:
REPLACE OIL SEAL AND TAPERED ROLLER BEAR-
ING OUTER RACE
(a) Remove the 4 bolts and 3 nuts.
(b) Using a plastic hammer, tap the stud bolt and remove the
transaxle case cover.
(c) Using a screwdriver and hammer, drive out the oil seal
from the transaxle case cover.
(d) Using SST, a brass bar and hammer, remove the tapered
roller bearing outer race.
SST 09612−65014
(e) Using SST and a press, install a new tapered roller bear-
ing outer race.
SST 09316−60011 (09316−00011, 09316−00041)
(f) Using SST and a hammer, drive in a new oil seal.
SST 09316−60011 (09316−00011)
(g) Coat the oil seal lip with MP grease.
(h) Apply FIPG to the transaxle case cover, as shown.
FIPG:
Part No. 08826−00090, THREE BOND 1281 or equiva-
lent
(i) Apply sealant to the bolt threads.
Sealant:
Part No.08833−00080, THREE BOND 1344, LOCTITE
242 or equivalent
(j) Install the stud bolt and cover to the transaxle case.

− MANUAL TRANSAXLEDIFFERENTIAL CASE (2WD)
MX−53
1996 RAV4 (RM447U)
(k) Install and torque the 4 bolts and 3 nuts.
Torque: 54 N·m (550 kgf·cm, 40 ft·lbf)
