1996 TOYOTA RAV4 Service Repair Manual

mm in.
5
0.20
INSTALLATION
Butt Weld
Body Sealer
Butt Weld
RH:
LH:
Butt weld
Body sealer
Braze
about 5 mm
RH:
LH:
2. Temporarily install the new parts and check
the fit of the rear door, back door and rear
combination light. 1. Before temporarily installing the new parts,
apply body sealer to the wheel arch.
HINT:
1) Apply body sealer about 5 mm (0.20in.) from
the flange, avoiding any oozing.
2) Apply sealer evenly, about 3 - 4 mm (0.12 -
0.16in.) in diameter.
3) For other sealing points, refer to section AR.
BODY PANEL REPLACEMENTREœ11

QUARTER PANEL (CUT-P)
REMOVAL
Cut and Join Location
RH:
LH:
Braze
RH:
LH:
1. Cut and join the parts at the location shown
above.
BODY PANEL REPLACEMENTREœ12

mmin.
5
0.20Braze
INSTALLATION
Butt Weld
Body Sealer
RH:
LH:
Body Sealer
about 5 mm
RH:
LH:
1. Before temporarily installing the new parts,
apply body sealer to the wheel arch.
HINT:
1) Apply body sealer about 5 mm (0.20 in.) from
the flange, avoiding any oozing.
2) Apply sealer evenly, about 3 - 4 mm (0.12 -
0.16 in.) diameter.
3) For other sealing points, refer to section AR.
2. Temporarily install the new parts and check the
fit of the rear door, back door and rear combinaœ
tion light.
3. Before welding, cut the lining away from the
weld seams a little.
BODY PANEL REPLACEMENTREœ13

QUARTER WHEEL HOUSING OUTER PANEL
(ASSY): Right Side
REMOVAL (With the quarter panel removed.)
BODY PANEL REPLACEMENTREœ14

INSTALLATION
Assembly Mark
Assembly Mark
Quarter Wheel Housing
Bracket
2. Before welding the new parts, temporarily
install the quarter panel and check the fit. 1. Determine the position of the new parts by the
assembly marks of the inner and outer panels.
BODY PANEL REPLACEMENTREœ15

QUARTER WHEEL HOUSING OUTER PANEL
(ASSY): Left Side
REMOVAL (With the quarter panel removed.)
BODY PANEL REPLACEMENTREœ16

INSTALLATION
Assembly MarkAssembly Mark
Fuel Tank Protector Bracket
1. Determine the position of the new parts by the
assembly marks of the inner and outer panels.2. Before welding the new parts, temporarily
install the quarter panel and check the fit.
BODY PANEL REPLACEMENTREœ17

QUARTER PANEL EXTENSION (ASSY)
REMOVAL (With the quarter panel removed.)
BODY PANEL REPLACEMENTREœ18
