1996 TOYOTA RAV4 Service Repair Manual

− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
DI−281
1996 RAV4 (RM447U)
2 Check for open and short in harness and connector between ABS ECU and
DLC1, and DLC1 and body ground (See page IN−30).
NG Repair or replace harness or connector.
OK
Check and replace ABS ECU.

W01419
DI−282
− DIAGNOSTICSANTI−LOCK BRAKE SYSTEM
1996 RAV4 (RM447U)
Check for Fluid Leakage
Check for fluid leakage from actuator or hydraulic lines.
DI41X−02

DI42G−01
Customer Problem Analysis
Check and Clear DTC (Precheck)
Vehicle Brought to Workshop
Problem Symptom ConfirmationSymptom Simulation Symptom does not occur
DTC CheckNormal code
DTC ChartMatrix Chart of Problem Symptoms
Circuit InspectionInput Signal Check
Parts Inspection
Identification of Problem
Repair
Confirmation Test
EndItems inside
are titles of pages in this
manual with the page number indicated in the
bottom portion. See the indicated pages
for detailed explanations. 1
2
34
5
6
7
89
10
Step 2, 5, 8, 10: Diagnostic steps permitting the use
of the TOYOTA hand−held tester or
TOYOTA break−out−box. P. DI−327
P. DI−328
P. DI−328
P. DI−332
P. DI−336
P. DI−338 − P DI−376
Symptom occur
Malfunction codeP. IN−20 DI−326
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 RAV4 (RM447U)
CRUISE CONTROL SYSTEM
HOW TO PROCEED WITH TROUBLESHOOTING
Perform troubleshooting in accordance with the procedure on the following page.

DI42H−01
CRUISE CONTROL SYSTEM Check Sheet
Inspector ’s name:
Customer ’s Name
Date of VehicleRegistration No.
Registration Year
Frame No.
Odometer Reading / /km
Mile
Condition of
Problem Occurrence
Date of Problem
Frequency Problem
Occurrence
Occurs
Vehicle Speed when
Problem Occurred / /
Continuous Intermittent ( Times a day)
km
Mile Brought in
Auto cancel
occurs Driving condition
 City driving  Freeway  Up hill  Down hill
 After cancel occurred, did the driver activate cruise control
again?
 Yes  No
 Cancel does not
occur With brake ON
 Except D position shift  At 40 km/h (25 mph) or less
 When control SW turns to CANCEL position
 Cruise control
malfunction Slip to acceleration side
 Slip to deceleration side
 Hunting occurs
 O/D cut off does not occur
 O/D does not return
 Switch
malfunction SET  ACCEL  COAST  RESUME  CANCEL
 Faulty CRUISE
MAIN indicator light Remains ON  Does not light up  Blinking Symptoms
DTC Check1st Time2nd Time
 Normal Code  Malfunction Code (Code )
 Normal Code  Malfunction Code (Code )
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−327
1996 RAV4 (RM447U)
CUSTOMER PROBLEM ANALYSIS CHECK

N17436CRUISE Indicator Light
DI42I−02
BE4034
ON
OFF1.5 sec 0.5 secWarning
F02201Tc E1
DI−328
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 RAV4 (RM447U)
PRE−CHECK
1. DIAGNOSIS SYSTEM
(a) Check the indicator.
(1) Turn the ignition switch to ON.
(2) Check that the CRUISE MAIN indicator light comes
on when the cruise control main switch is pushed
ON, and that the indicator light goes off when the
main switch is pushed OFF.
HINT:
If the indicator check result is not normal, proceed to trouble-
shooting (See page BE−2) for the combination meter
section.
(b) Check the DTC.
HINT:
If a malfunction occurs in the vehicle speed sensors or actuator,
etc. during cruise control driving, the ECU actuates AUTO CAN-
CEL of the cruise control and blinks the CRUISE MAIN indicator
light to inform the driver of a malfunction. At the same time, the
malfunction is stored in memory as a DTC.
(c) Output of DTC using diagnosis check wire.
(1) Turn the ignition switch to ON.
(2) Using SST, connect terminals Tc and E
1 of DLC1.
SST 09843−18020
(3) Read the DTC on the CRUISE MAIN indicator light.
HINT:
If the DTC is not output, inspect the diagnosis circuit (See
page DI−374).
As an example, the blinking patterns for codes; normal,
11 and 21 are shown in the illustration.

BE4032
BE4033I00021
ON
OFF0.25 secNormal code
Malfunction codes 11 and 21
0.5 sec
0.5 sec
2.5 sec 4 sec 1.5 sec
Code 11
Code 21
0.25 sec
ON
OFF
N09348
ECUTOYOTA
hand−held tester
TOYOTA
break−out−box
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−329
1996 RAV4 (RM447U)
(4) Check for the problem, use the DTC table on the
next page.
(5) After completing the check, disconnect terminals Tc
and E
1, and turn off the display.
2. ECU TERMINAL VALUES MEASUREMENT USING
TOYOTA BRAKE−OUT−BOX AND TOYOTA HAND−
HELD TESTER
(a) Hook up the TOYOTA break−out−box and TOYOTA
hand−held tester to the vehicle.
(b) Read the ECU input/output values by following the
prompts on the scan tool screen.
HINT:
TOYOTA hand−held tester has a ”Snapshot” function.
This records the measured values and is effective in the diagno-
sis of intermittent problems.
Please refer to the TOYOTA hand−held tester/TOYOTA break−
out−box operator’s manual for further details.

N17904
R/B No. 2
DOME Fuse
DI−330
− DIAGNOSTICSCRUISE CONTROL SYSTEM
1996 RAV4 (RM447U)
3. DTC CLEARANCE
(a) After completing repairs, the DTC retained in memory can
be cleared by removing the ECU−IG fuse for 10 seconds
or more, with the ignition switch off.
(b) Check that the normal code is displayed after connecting
the fuse.

BE6443
(1)
(2)
(1)
No.Operation MethodCRUISE MAIN Indicator Light
Blinking PatternDiagnosis
1 Turn SET/COAST switch ON
2Turn RES/ACC switch ON
3Turn CANCEL switch ON
Turn stop light switch ON
Depress brake pedal
Turn PNP switch OFF
(Shift to except D position)
4Drive at about 40 km/h
(25 mph)or higher
Drive at about 40 km/h
(25 mph) or below
LightON
OFF
LightON
OFF
LightON
OFFSwitch ON
Switch OFF
LightON
OFFSwitch OFF
Switch ONSET/COAST switch circuit
is normal
RES/ACC switch circuit
is normal
CANCEL switch circuit
is normal
Stop light switch circuit
is normal
PNP switch circuit is
normal
Vehicle Speed Sensor is
normal
LightON
OFF LightON
OFF
1sec.
0.25 sec.0.25 sec.
Turn clutch switch OFF
(Depress clutch pedal)Clutch switch circuit
is normal
− DIAGNOSTICSCRUISE CONTROL SYSTEM
DI−331
1996 RAV4 (RM447U)
4. INPUT SIGNAL CHECK
HINT:
(1) For check No.1 − No.2.
Turn the ignition switch ON.
(2) For check No.3.
Turn ignition switch ON.
Shift to D position. (A/T Vehicle)
(3) For check No.4.
Jack up the vehicle.
Start the engine.
Shift to D position. (A/T Vehicle)
(a) Press the control switch to the SET/COAST or RES/ACC
position and hold it down or hold it up (1).
(b) Push the main switch ON (2).
(c) Check that the CRUISE MAIN indicator light blinks twice
or 3 times repeatedly after 3 seconds.
(d) Turn the SET/COAST or RES/ACC switch OFF.
(e) Operate each switch as listed in the table below.
(f) Read the blinking pattern of the CRUISE MAIN indicator
light.
(g) After performing the check, turn the main switch OFF.
HINT:
When 2 or more signals are input to the ECU, the lowest num-
bered code will be displayed first.
