1996 TOYOTA RAV4 oil type

AX0T6−02
Q05259
Q05234
Q06417
Q06418
− AUTOMATIC TRANSAXLE (A241E)VALVE BODY ASSEMBLY
AX−5
1996 RAV4 (RM447U)
VALVE BODY ASSEMBLY
ON−VEHICLE REPAIR
1. REMOVE DRAIN PLUG AND DRAIN ATF
2. REMOVE OIL PAN AND GASKET
Remove the 18 bolts.
NOTICE:
Some fluid will remain in the oil pan. Remove all pan bolts,
and carefully remove the oil pan assembly. Discard the
gasket.
3. EXAMINE PARTICLES IN PAN
Remove the magnets and use them to collect any steel chips.
Look carefully at the chips and particles in the pan and the mag-
net to anticipate what type of wear you will find in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. REMOVE OIL STRAINER AND APPLY PIPE BRACKET
NOTICE:
Be careful as some fluid will come out with the oil strainer.
(a) Remove the 3 bolts, oil strainer and gasket.
(b) Remove the 2 bolts and apply pipe bracket.
5. REMOVE OIL PIPE CLAMP AND OIL PIPES
(a) Remove the bolt and oil pipe clamp.
(b) Pry up the both pipe ends with a large screwdriver and re-
move the 5 pipes.
NOTICE:
Be careful not to bend or damage the pipe.

Q06064
AX129−01
AT0103
D00691
D00692
AX−8
− AUTOMATIC TRANSAXLE (A540H)VALVE BODY ASSEMBLY
1996 RAV4 (RM447U)
VALVE BODY ASSEMBLY
ON−VEHICLE REPAIR
1. REMOVE NO.2 ENGINE UNDER COVER
2. DRAIN ATF
Using a 10 mm hexagon wrench, remove the drain plug, and
drain the ATF into a suitable container.
3. REMOVE OIL PAN AND GASKET
(a) Remove the 17 bolts.
(b) Remove the oil pan by lifting transaxle case.
NOTICE:
Some fluid remain in the oil pan.
4. EXHAUST PARTICLES IN PAN
Remove the magnet and use it to collect any steel chips.
Lock carefully at the chips and particles in the oil pan and on the
magnet to anticipate when type of wear you will find in the trans-
axle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bushing wear
5. REMOVE OIL PIPE BRACKET AND STRAINER
(a) Remove the 2 bolts and oil pipe bracket.
(b) Remove the 3 bolts and strainer.
(c) Remove the gasket from the strainer.
6. REMOVE MANUAL VALVE BODY
(a) Remove the 2 bolts and detent spring.

ANTI-RUST TREATMENT
When replacing body panels, always apply body sealer, anti-rust agent or undercoat according to the reœ
quirements of your country.
HINT: For further details, see the description given in Section AR of this manual.
BODY SEALER
Apply body sealer to the
required areas.ANTI-RUST AGENT (WAX)
Apply anti-rust agent to
following sections.

Inside of the hems of the
doors and hood.

Around the hinges of the
doors and hood.

Inside of the welded parts
with boxed cross-section.
Cartridge Type Tube Type
UNDERCOAT
Apply undercoat to the underbody and
wheel housings.
Spray Gun
Undercoating
(Oil base)Undercoating
(Water base)
INTRODUCTIONINœ13

OR0028
Q06076
AT3417
OK if hot
Add if hot
AT4252
0 − 1 mm
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−133
1996 RAV4 (RM447U)
Fluid type: ATF DEXRON ®II
NOTICE:
Do not overfill.
(b) Check the fluid condition.
If the fluid smells burnt or is black, replace it.
(c) Replace the fluid.
(1) Remove the drain plug and drain the fluid.
(2) Reinstall the drain plug securely.
(3) With the engine OFF, add new fluid through the oil
filler pipe.
Fluid type: ATF DEXRON ®II
Capacity:
Drain and refill: 3.3 liters (3.5 US qts, 2.9 lmp. qts)
(4) Start the engine and shift the shift lever into all posi-
tions from P to L position and then shift into P posi-
tion.
(5) With the engine idling, check the fluid level. Add
fluid up to the COOL level on the dipstick.
(6) Check the fluid level at the normal operating tem-
perature 70 − 80°C (158 − 176°F) and add as nec-
essary.
NOTICE:
Do not overfill.
(d) Check the fluid leaks.
Check for leaks in the transaxle.
If there are leaks, it is necessary to replace O−rings, gaskets,
oil seals, plugs or other parts.
(e) Inspect and adjust throttle cable.
(1) Check that the throttle valve is fully closed.
(2) Check that the inner cable is not slack.
(3) Measure the distance between the outer cable end
and stopper on the cable.
Standard distance: 0 − 1 mm (0 − 0.04 in.)
If the distance is not within the standard, adjust the cable by the
adjusting nuts.

Q06070
D02315
OK if hot
Add if hot
D00697
Ok if hot
Add if hot
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A540H)
DI−179
1996 RAV4 (RM447U)
7. BASIC INSPECTION
(a) Check the ATF level.
HINT:
The vehicle must have been driven so that the engine and
transaxle are at normal operating temperature.
ATF temperature: 70 − 80°C (158 − 176°F)
(1) Park the vehicle on a level surface, set the parking
brake.
(2) With the engine idling and the brake pedal de-
pressed, shift the shift lever into each gear from the
P position to L position smoothly and return to the
P position.
(3) Pull out the transaxle dipstick and wipe it clean.
(4) Push it back fully into the pipe.
(5) Pull it out and check that the fluid level is in the HOT
range.
If the level is at the low side of the hot range, add fluid.
Fluid type: ATF type T or equivalent
NOTICE:
Do not overfill.
(b) Check the transfer oil level.
(1) Park the vehicle on a level surface, set the parking
brake.
(2) Pull out the transfer dipstick and wipe it clean.
(3) Push it back fully into the pipe.
(4) Pull it out and check the oil level, as shown in the il-
lustration.
Oil grade: API GL−5
Oil viscosity: SAE 75W−90

D00698
: ATF Type T
: Gear Oil
Transaxle Oil Level Gauge
Transaxle Oil Level Gauge
DI−180
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A540H)
1996 RAV4 (RM447U)
NOTICE:
Do not overfill.
(c) Check the fluid condition.
If the fluid smells burnt or is black, replace it.

Q06065
Q06076
D02315
OK if hot
Add if hot
D00699
D00700
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A540H)
DI−181
1996 RAV4 (RM447U)
(d) Replace the ATF.
NOTICE:
Do not overfill.
(1) Using a 10 mm hexagon wrench, remove the drain
plug, gasket and drain the fluid.
(2) Install a new gasket and the drain plug securely.
(3) Add new fluid through the filler pipe.
Fluid type: ATF type T or equivalent
Drain and refill: 3.3 liters (3.5 US qts, 2.9 lmp. qts)
(4) Start the engine and shift the selector into all the
positions from P through L and then shift into the P
position.
(5) With the engine idling, check the fluid level. Add
fluid up to the COOL level on the dipstick.
(6) Check the fluid level with the normal fluid tempera-
ture 70 − 80°C (158 − 176°F) and add as neces-
sary.
NOTICE:
Do not overfill.
(e) Replace the transfer oil.
(1) Using a 10 mm hexagon wrench, remove the drain
plug and drain the oil.
(2) Install the drain plug.
(3) Add new oil through the filler pipe.
Recommended oil:
Oil grade API GL−5
Viscosity SAE 75W−90
Capacity: 0.7 liters (0.7 US qts, 0.6 lmp. qts)
(4) Check the oil level and add as necessary.
NOTICE:
Do not overfill.

EM0EM−03
S01283
B
SST
A
S01358
Oil Pump
S01630
SST
SST
− ENGINE MECHANICALTIMING BELT
EM−15
1996 RAV4 (RM447U)
REMOVAL
1. DISCONNECT PS RESERVOIR AND REMOVE RES-
ERVOIR BRACKET
2. DISCONNECT WIRE HARNESS BRACKET FOR DLC1
3. REMOVE GENERATOR (See page CH−7)
4. REMOVE GENERATOR BRACKET
5. w/ ABS:
REMOVE NO. 3 ABS ACTUATOR BRACKET (See page
BR−40)
6. REMOVE RH FRONT WHEEL
7. REMOVE RH ENGINE UNDER COVER
8. REMOVE PS PUMP DRIVE BELT
(a) Loosen the bolt A.
(b) Using SST and a deep socket wrench, loosen the bolt B.
SST SST09249−63010
(c) Remove the drive belt.
9. SLIGHTLY JACK UP ENGINE
Attach the jack to the oil pan, and raise the engine enough to
remove the weight from the engine mounting on the right side.
10. REMOVE RH ENGINE MOUNTING INSULATOR
11. REMOVE SPARK PLUGS
12. REMOVE CRANKSHAFT PULLEY
(a) Using SST (and bolt), remove the pulley bolt.
SST 09213−54015 (91651−60855 for type A),
09330−00021
Bolt: Part No. 91121−40665 for type B
HINT:
Either of 2 types of pulley may be used, each with its own
bolt size, type A and type B.
When using bolt type B, a plate washer must be inserted
between the bolt and SST.
