Page 1145 of 3745
![NISSAN TIIDA 2010 Service Repair Manual CVT-112
< SERVICE INFORMATION >[RE0F08B]
P0868 TRANSMISSION FLUID PRESSURE
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK LINE PRESSURE
Perform line pressure test. Refer to CVT-37, "
Inspections before Troubl NISSAN TIIDA 2010 Service Repair Manual CVT-112
< SERVICE INFORMATION >[RE0F08B]
P0868 TRANSMISSION FLUID PRESSURE
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK LINE PRESSURE
Perform line pressure test. Refer to CVT-37, "
Inspections before Troubl](/manual-img/5/57397/w960_57397-1144.png)
CVT-112
< SERVICE INFORMATION >[RE0F08B]
P0868 TRANSMISSION FLUID PRESSURE
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK LINE PRESSURE
Perform line pressure test. Refer to CVT-37, "
Inspections before Trouble Diagnosis".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts. Refer to CVT-37, "
Inspections before Trouble Diagnosis".
3.DETECT MALFUNCTIONING ITEM
Check the following:
• Secondary pressure solenoid valve. Refer to CVT-103, "
Component Inspection".
• Line pressure solenoid valve. Refer to CVT-94, "
Component Inspection".
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4.CHECK SECONDARY PRESSURE SENSOR SYSTEM
Check secondary pressure sensor system. Refer to CVT-105
.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5.DETECT MALFUNCTIONING ITEM
Check the following:
• Power supply and ground circuit for TCM. Refer to CVT-114, "
Wiring Diagram - CVT - POWER".
• The TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
6.CHECK DTC
Perform CVT-111, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Replace the transaxle assembly. Refer to CVT-173, "
Removal and Installation".
Revision: January 20102010 Versa
Page 1146 of 3745
![NISSAN TIIDA 2010 Service Repair Manual P1701 TCMCVT-113
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1701 TCM
DescriptionINFOID:0000000005397919
When the power supply to the TCM is cut OFF, for exam ple because the NISSAN TIIDA 2010 Service Repair Manual P1701 TCMCVT-113
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1701 TCM
DescriptionINFOID:0000000005397919
When the power supply to the TCM is cut OFF, for exam ple because the](/manual-img/5/57397/w960_57397-1145.png)
P1701 TCMCVT-113
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1701 TCM
DescriptionINFOID:0000000005397919
When the power supply to the TCM is cut OFF, for exam ple because the battery is removed, and the self-diag-
nosis memory function stop s, malfunction is detected.
NOTE:
Since “P1701” will be indicated when replacing TCM, perform diagnosis after erasing “SELF-DIAG
RESULTS”
On Board Diagnosis LogicINFOID:0000000005397920
• This is not an OBD-II self-diagnostic item.
• Diagnostic trouble code “P1701” with CONSULT-III is detected when TCM does not receive the voltage sig- nal from the battery power supply.
• This is not a malfunction message. (Whenever shutti ng OFF a power supply to the TCM, this message
appears on the screen.)
Possible CauseINFOID:0000000005397921
Harness or connectors
(Battery or ignition switch and TCM circuit is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000005397922
NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and
wait at least 10 seconds before conducting the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Wait for at least 2 consecutive seconds.
4. If DTC is detected, go to CVT-115, "
Diagnosis Procedure" .
Revision: January 20102010 Versa
Page 1147 of 3745
CVT-114
< SERVICE INFORMATION >[RE0F08B]
P1701 TCM
Wiring Diagram - CVT - POWER
INFOID:0000000005397923
TCM TERMINALS AND REFERENCE VALUES
Refer to CVT-46, "TCM Terminal and Reference Value" .
AADWA0023GB
Revision: January 20102010 Versa
Page 1148 of 3745
![NISSAN TIIDA 2010 Service Repair Manual P1701 TCMCVT-115
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
Diagnosis ProcedureINFOID:0000000005397924
1.CHECK DTC
1. Turn ignition switch ON. (Do not start engine.)
2. Selec NISSAN TIIDA 2010 Service Repair Manual P1701 TCMCVT-115
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
Diagnosis ProcedureINFOID:0000000005397924
1.CHECK DTC
1. Turn ignition switch ON. (Do not start engine.)
2. Selec](/manual-img/5/57397/w960_57397-1147.png)
P1701 TCMCVT-115
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
Diagnosis ProcedureINFOID:0000000005397924
1.CHECK DTC
1. Turn ignition switch ON. (Do not start engine.)
2. Select “SELF-DIAG RESULTS” mode for “TRANSMISSION” with CONSULT-III.
3. Erase self-diagnostic results. Refer to CVT-27, "
OBD-II Diagnostic Trouble Code (DTC)" .
4. Turn ignition switch OFF, and wait for 5 seconds or more.
5. Start engine.
6. Confirm self-diagnostic results again. Refer to CVT-48, "
CONSULT-III Function (TRANSMISSION)" .
Is the
“P1701” displayed?
YES >> GO TO 2.
NO >> INSPECTION END
2.CHECK TCM POWER SOURCE, STEP 1
1. Turn ignition switch OFF.
2. Check voltage between TCM connector terminal and ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 4.
3.CHECK TCM POWER SOURCE, STEP 2
1. Turn ignition switch ON. (Do not start engine.)
2. Check voltage between TCM connector terminals and ground.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4.DETECT MALFUNCTIONING ITEM
Check the following.
• Harness for short or open between battery and TCM connector terminal 28
• Harness for short or open between ignition switch and TCM connector terminal 10, 19
Name Connector Terminal Condition Voltage
(Approx.)
Power supply
(memory back-
up) E32 28, 30 - Ground Always
Battery
voltage
AWDIA0651GB
Name Connector Terminal Condition Voltage
(Approx.)
Power supply E3110 - Ground
Battery
voltage
0 V
Power supply 19 - Ground Battery
voltage
0 V
Power supply
(memory back-
up) E32 28, 30 - Ground Always
Battery
voltage
AWDIA0652GB
Revision: January 20102010 Versa
Page 1149 of 3745
CVT-116
< SERVICE INFORMATION >[RE0F08B]
P1701 TCM
• 10 A fuse (No.49, located in the IPDM E/R)
• 20 A fuse (No.53, located in the IPDM E/R)
• Ignition switch. Refer to
PG-4
.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5.CHECK TCM GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM connector terminals and ground.
OK or NG
OK >> GO TO 6.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK DTC
Perform CVT-113, "
DTC Confirmation Procedure" .
OK or NG
OK >> INSPECTION END
NG >> GO TO 7.
7.CHECK TCM
1. Check TCM input/output signals. Refer to CVT-46, "
TCM Terminal and Reference Value" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
Name Connector Terminal Continuity
Ground E3225
Ye s
48
SCIA2671E
Revision: January 20102010 Versa
Page 1150 of 3745
![NISSAN TIIDA 2010 Service Repair Manual P1705 TP SENSORCVT-117
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1705 TP SENSOR
DescriptionINFOID:0000000005397925
Electric throttle control actuator consists of throttle co NISSAN TIIDA 2010 Service Repair Manual P1705 TP SENSORCVT-117
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1705 TP SENSOR
DescriptionINFOID:0000000005397925
Electric throttle control actuator consists of throttle co](/manual-img/5/57397/w960_57397-1149.png)
P1705 TP SENSORCVT-117
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1705 TP SENSOR
DescriptionINFOID:0000000005397925
Electric throttle control actuator consists of throttle control motor, accelerator pedal position sensor, throttle
position sensor etc. The actuator sends a signal to the ECM, and ECM sends the signal to TCM with CAN
communication.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000005397926
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000005397927
• This is not an OBD-II self-diagnostic item.
• Diagnostic trouble code “P1705” with CONSULT-III is detected when TCM does not receive the proper
accelerator pedal position signals (input by CAN communication) from ECM.
Possible CauseINFOID:0000000005397928
•ECM
• Harness or connectors(CAN communication line is open or shorted.)
DTC Confirmation ProcedureINFOID:0000000005397929
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Depress accelerator pedal fully and release it, then wait for 5 seconds.
4. If DTC is detected, go to CVT-117, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000005397930
1.CHECK CAN COMMUNICATION LINE
Perform the self-diagnosis check. Refer to CVT-48, "
CONSULT-III Function (TRANSMISSION)".
Is any malfunction of the
“U1000” indicated?
YES >> Check the CAN communication line. Refer to CVT-56.
NO >> GO TO 2.
2.CHECK INPUT SIGNAL
With CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select “ECU INPUT SIGNALS” in “DATA MONITO R” mode for “TRANSMISSION” with CONSULT-III.
3. Read out the value of “ACC PEDAL OPEN”.
OK or NG
Item name Condition Display value (Approx.)
ACC PEDAL OPEN Released accelerator pedal - Fully depressed accelerator pedal 0.0/8 - 8.0/8
Item name ConditionDisplay value (Approx.)
ACC PEDAL OPEN Release accelerator ped-
al.↓
Fully depressed acceler- ator pedal 0.0/8
↓
8.0/8
Revision: January 20102010 Versa
Page 1151 of 3745
CVT-118
< SERVICE INFORMATION >[RE0F08B]
P1705 TP SENSOR
OK >> GO TO 4.
NG >> GO TO 3.
3.CHECK DTC WITH ECM
With CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select “SELF-DIAG RESULTS” mode for “ENGINE” with CONSULT-III. Refer to EC-612, "
CONSULT-III
Function (ENGINE)".
OK or NG
OK >> GO TO 4.
NG >> Check the DTC Detected Item. Go to EC-612, "
CONSULT-III Function (ENGINE)".
4.CHECK DTC
Perform CVT-117, "
DTC Confirmation Procedure".
OK or NG
OK >> INSPECTION END
NG >> Repair or replace damaged parts.
Revision: January 20102010 Versa
Page 1152 of 3745
![NISSAN TIIDA 2010 Service Repair Manual P1722 VEHICLE SPEEDCVT-119
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1722 VEHICLE SPEED
DescriptionINFOID:0000000005397931
The vehicle speed signal is transmitt ed from ABS NISSAN TIIDA 2010 Service Repair Manual P1722 VEHICLE SPEEDCVT-119
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1722 VEHICLE SPEED
DescriptionINFOID:0000000005397931
The vehicle speed signal is transmitt ed from ABS](/manual-img/5/57397/w960_57397-1151.png)
P1722 VEHICLE SPEEDCVT-119
< SERVICE INFORMATION > [RE0F08B]
D
E
F
G H
I
J
K L
M A
B
CVT
N
O P
P1722 VEHICLE SPEED
DescriptionINFOID:0000000005397931
The vehicle speed signal is transmitt ed from ABS actuator and electric unit (control unit) to TCM by CAN com-
munication line.
CONSULT-III Reference Val ue in Data Monitor ModeINFOID:0000000005397932
Remarks: Specification data are reference values.
On Board Diagnosis LogicINFOID:0000000005397933
• This is not an OBD-II self-diagnostic item.
• Diagnostic trouble code “P1722” with CONSULT-III is det ected when TCM does not receive the proper vehi-
cle speed signal (input by CAN communication) from ABS actuator and electric unit (control unit).
Possible CauseINFOID:0000000005397934
• Harness or connectors
(Sensor circuit is open or shorted.)
• ABS actuator and electric unit (control unit)
DTC Confirmation ProcedureINFOID:0000000005397935
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, touch “ERASE” on “SELF-DIAG RESULTS” and then perform the following procedure to con-
firm the malfunction is eliminated.
WITH CONSULT-III
1. Turn ignition switch ON. (Do not start engine.)
2. Select “DATA MONITOR” mode for “TRANSMISSION” with CONSULT-III.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds. ACC PEDAL OPEN: 1.0/8 or less
VEHICLE SPEED SE: 30 km/h (17 MPH) or more
4. If DTC is detected, go to CVT-119, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000005397936
1.CHECK CAN COMMUNICATION LINE
Perform the self-diagnosis check. Refer to CVT-48, "
CONSULT-III Function (TRANSMISSION)".
Is any malfunction of the
“U1000” indicated?
YES >> Check CAN communication line. Refer to CVT-56.
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform ABS actuator and electric unit (cont rol unit) self-diagnosis check. Refer to BRC-20, "
CONSULT-III
Function (ABS)".
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3.CHECK INPUT SIGNALS
Item name Condition Display value
ESTM VSP SIG During driving Approximately matches the speedometer reading.
VEHICLE SPEED
Revision: January 20102010 Versa
