PG-2
< SERVICE INFORMATION >
PRECAUTIONS
SERVICE INFORMATION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000005395347
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and w hether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
• To avoid rendering the SRS inopera tive, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including incorrect removal and installation of the SRS can lead to personal
injury caused by unintent ional activation of the system. For re moval of Spiral Cable and Air Bag
Module, see the SRS section.
• Do not use electrical test equipmen t on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harn esses can be identified by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or electri c power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers , always switch the Ignition OFF, disconnect the
battery, and wait at least 3 minu tes before performing any service.
Precaution Necessary for Steering W heel Rotation After Battery Disconnect
INFOID:0000000005995526
NOTE:
• This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
• Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK ″ position.
• Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
Revision: January 20102010 Versa

Page 3386 of 3745

NISSAN TIIDA 2010 Service Repair Manual PRECAUTIONSPG-3
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
PG
N
O P
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cabl

Page 3387 of 3745

NISSAN TIIDA 2010 Service Repair Manual PG-4
< SERVICE INFORMATION >
POWER SUPPLY ROUTING CIRCUIT
POWER SUPPLY ROUTING CIRCUIT
SchematicINFOID:0000000005395348
For detailed ground distribution, refer to PG-30, "Ground Distribution" .
AAMWA0

Page 3388 of 3745

NISSAN TIIDA 2010 Service Repair Manual POWER SUPPLY ROUTING CIRCUITPG-5
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
PG
N
O P
ABMWA0593GB
Revision: January 20102010 Versa

Page 3389 of 3745

NISSAN TIIDA 2010 Service Repair Manual PG-6
< SERVICE INFORMATION >
POWER SUPPLY ROUTING CIRCUIT
Wiring Diagram - POWER -
INFOID:0000000005395349
BATTERY POWER SUPPLY — IGNITION SWITCH IN ANY POSITION
AAMWA0248GB
Revision: January 201020

Page 3390 of 3745

NISSAN TIIDA 2010 Service Repair Manual POWER SUPPLY ROUTING CIRCUITPG-7
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
PG
N
O P
ABMWA0595GB
Revision: January 20102010 Versa

Page 3391 of 3745

NISSAN TIIDA 2010 Service Repair Manual PG-8
< SERVICE INFORMATION >
POWER SUPPLY ROUTING CIRCUIT
LKWA0374E
Revision: January 20102010 Versa

Page 3392 of 3745

NISSAN TIIDA 2010 Service Repair Manual POWER SUPPLY ROUTING CIRCUITPG-9
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
PG
N
O P
AWMWA0066GB
Revision: January 20102010 Versa
