Page 641 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-132 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> Door switch circuit is OK. NG >> GO TO 2 2.CHECK DOOR SWITCH CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect door switch and BCM

Page 642 of 3745

NISSAN TIIDA 2010 Service Repair Manual INTELLIGENT KEY SYSTEMBL-133 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P BACK DOOR Check continuity between back door lock assembly connector (back door switch) terminals 3 and 4 while pr

Page 643 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-134 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM • When doors are closed:Without CONSULT-III Check voltage between BCM connector M18 or M19 terminals 12, 13, 47, 48 and ground. OK or NG OK >> D

Page 644 of 3745

NISSAN TIIDA 2010 Service Repair Manual INTELLIGENT KEY SYSTEMBL-135 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P OK or NG OK >> Check door switch case ground condition. NG >> Replace door switch. Door Request Switch CheckINFOID:

Page 645 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-136 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> GO TO 3 NG >> Repair or replace harness between Intelligent Key unit and front door request switch. 3.CHECK DOOR REQUEST SWITCH OPE

Page 646 of 3745

NISSAN TIIDA 2010 Service Repair Manual INTELLIGENT KEY SYSTEMBL-137 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P Back Door Request Switch Check (Hatchback)INFOID:0000000005396620 1.CHECK BACK DOOR REQUEST SWITCH With CONSULT-III

Page 647 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-138 < SERVICE INFORMATION > INTELLIGENT KEY SYSTEM OK or NG OK >> GO TO 4 NG >> Replace back door request switch. 4.CHECK BACK DOOR REQUEST SWITCH GROUND CIRCUIT Check continuity between back door

Page 648 of 3745

NISSAN TIIDA 2010 Service Repair Manual INTELLIGENT KEY SYSTEMBL-139 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P OK or NG OK >> Trunk opener request switch circuit is OK. NG >> GO TO 2 2.CHECK TRUNK OPENER REQUEST SWITCH CIRCUIT
