Page 481 of 3745

NISSAN TIIDA 2010 Service Repair Manual AV-84 < SERVICE INFORMATION >[AUDIO WITH NAVIGATION] TELEPHONE 3. Check voltage between Bluetooth microphone connector R15 terminal 4 and ground. YES or NO YES >> GO TO 3. NO >> Replace Bluetooth cont

Page 482 of 3745

NISSAN TIIDA 2010 Service Repair Manual TELEPHONEAV-85 < SERVICE INFORMATION > [AUDIO WITH NAVIGATION] C D E F G H I J L M A B AV N O P OK >> GO TO 3. NG >> Repair harness or connector. 3.CHECK BLUETOOTH VOICE SIGNAL Check signal between Bl

Page 483 of 3745

NISSAN TIIDA 2010 Service Repair Manual AV-86 < SERVICE INFORMATION >[AUDIO WITH NAVIGATION] TELEPHONE Sedan Removal 1. For hatchback, remove luggage side lower finisher (RH). Refer to EI-54, "Removal and Installation". • Disconnect Blue

Page 484 of 3745

NISSAN TIIDA 2010 Service Repair Manual TELEPHONEAV-87 < SERVICE INFORMATION > [AUDIO WITH NAVIGATION] C D E F G H I J L M A B AV N O P Hatchback Sedan Removal 1. Disconnect the battery negative terminal. 2. For hatchback, remove luggage si

Page 485 of 3745

NISSAN TIIDA 2010 Service Repair Manual AV-88 < SERVICE INFORMATION >[AUDIO WITH NAVIGATION] TELEPHONE BLUETOOTH MICROPHONE Removal 1. Remove over-head console assembly, roof finisher. Refer to EI-48. 2. Remove the Bluetooth microphone. In

Page 486 of 3745

NISSAN TIIDA 2010 Service Repair Manual USB CONNECTOR AND AUX JACKAV-89 < SERVICE INFORMATION > [AUDIO WITH NAVIGATION] C D E F G H I J L M A B AV N O P USB CONNECTOR AND AUX JACK Removal and InstallationINFOID:0000000005924421 REMOVAL 1. R

Page 487 of 3745

NISSAN TIIDA 2010 Service Repair Manual AV-90 < SERVICE INFORMATION >[AUDIO WITH NAVIGATION] AUDIO ANTENNA AUDIO ANTENNA Location of AntennaINFOID:0000000005924423 Removal and Installati on of Roof AntennaINFOID:0000000005924424 REMOVAL 1.

Page 488 of 3745

NISSAN TIIDA 2010 Service Repair Manual AUDIO ANTENNAAV-91 < SERVICE INFORMATION > [AUDIO WITH NAVIGATION] C D E F G H I J L M A B AV N O P • : Vehicle front 7. Remove the roof antenna. INSTALLATION Installation is in the reverse order of
