Page 817 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-308 < SERVICE INFORMATION > BODY REPAIR • The repair of reinforcements (such as side members) by heat-ing is not recommended since it may weaken the component. When heating is unavoidable, do not

Page 818 of 3745

NISSAN TIIDA 2010 Service Repair Manual BODY REPAIRBL-309 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P • The spot weld on HSS panels is harder than that of an ordi- nary steel panel. Therefore, when cutting spot welds on a HSS

Page 819 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-310 < SERVICE INFORMATION > BODY REPAIR • Peel off old bonding material on the surface of outer wheelhouseand clean thoroughly. • Peel off a primer coat in the specified area where new adhesive

Page 820 of 3745

NISSAN TIIDA 2010 Service Repair Manual BODY REPAIRBL-311 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P - Remove foam material remaining on vehicle side. - Clean area in which foam was removed. - Install service part. - Insert noz

Page 821 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-312 < SERVICE INFORMATION > BODY REPAIR Sedan 1. Body side outer2. Front pillar lower reinforcement 3. Body side insulation (foam) front pil- lar 4. Roof panel assembly 5. Body side insulation (Foa

Page 822 of 3745

NISSAN TIIDA 2010 Service Repair Manual BODY REPAIRBL-313 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P Replacement OperationINFOID:0000000005396727 DESCRIPTION 1. Body side outer 2. Front pillar lower reinforcement 3. Body side i

Page 823 of 3745

NISSAN TIIDA 2010 Service Repair Manual BL-314 < SERVICE INFORMATION > BODY REPAIR This section is prepared for technicians who have attained a high level of skill and experience in repairing col- lision-damaged vehicles and also use modern

Page 824 of 3745

NISSAN TIIDA 2010 Service Repair Manual BODY REPAIRBL-315 < SERVICE INFORMATION > C DE F G H J K L M A B BL N O P The symbols used in this section for cutting and welding / brazing operations are shown below. PIIA0149E Revision: January 201
