2008 TOYOTA LAND CRUISER Owners Manual

130 1−7. Safety information
nForwardfacing Convertible seat
Fold the seatback while pulling
the seatback angle lever.
Return the seatback and secure
it at the first lock position.
(
P. 53)
Place the convertible seat on the
seat facing the front of the vehi−
cle.
Run the seat belt through the
convertible seat and insert the
plate into the buckle. Make sure
that the belt is not twisted.
STEP1
STEP 2
STEP 3

131
1−7. Safety information
1
Before driving
Fully extend the shoulder strap
and then allow it to retract
slightly into the ALR lock mode.
Lock mode allows the seat belt to
retract only.
While pushing the convertible
seat into the seat, allow the
shoulder belt to retract until the
convertible seat is securely in
place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
STEP4
STEP 5

132 1−7. Safety information
nBooster seat
Fold the seatback while pulling
the seatback angle lever.
Return the seatback and secure
it at the first lock position.
(
P. 53)
Place the booster seat on the
seat facing the front of the vehi−
cle.
Sit the child in the booster seat.
Fit the seat belt to the booster
seat according to the manufac−
turer ’s instructions and insert the
plate into the buckle. Make sure
that the belt is not twisted.
Check that the shoulder belt is
correctly positioned over the
child’s shoulder, and that the lap
belt is as low as possible.
(
P. 69)
STEP1
STEP 2
STEP 3

133
1−7. Safety information
1
Before driving
Removing a child restraint installed with a seat belt
Press the buckle release button
and fully retract the seat belt.
Installation with child restraint lower anchors
Fold the seatback forward and
then back to the 1st lock position
(most upright position) until it
locks into place.
Take off the covers between the
seat cushion a nd seatback, then
confirm the position of the lower
anchors below the symbol in the
seatback.
STEP1
ITY17C106
STEP2

134 1−7. Safety information
Type A
Latch the hooks of the lower
straps onto the anchors.
If the child restraint has a top
strap, the top strap should be
latched onto the anchor.
Type B
Latch the buckles onto the
anchors.
If the child restraint has a top
strap, the top strap should be
latched onto the anchor.
ITY17C124
STEP3
ITY17C056
STEP3

135
1−7. Safety information
1
Before driving
Child restraint systems with a top strap
Secure the child restraint using a seat belt or ISOFIX rigid
anchors, and do the following.
Outside
Adjust the head restraint to the
upmost position.
Center
Lower the head restraint to the
lowest position.
Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top strap.
Make sure the top strap is
securely latched.
Hook
Top strap
Anchor bracket
STEP1
ITY17C055
STEP1
ITY17C099
ITY17C057
STEP2

136 1−7. Safety information
Outside only: Adjust the head
restraint to the downmost posi−
tion.
ITY17C058
STEP3
nLaws and regulations pertaining to Anchors
Anchors conform to FMVSS225.
Child restraint systems conforming to FMVSS213 specifications can be
used.
This vehicle is designed to conform to the SAE J1819.
CAUTION
nWhen installing a booster seat
Do not fully extend the shoulder belt to prevent the belt from going to ALR
lock mode: (P. 72)
lALR mode causes the belt to tighten only which could cause injury or dis−
comfort to the child.
l
Do not allow the child to play with the seat belt or the child could be killed
or serious injured.

137
1−7. Safety information
1
Before driving
CAUTION
nWhen installing a child restraint system
Follow the directions given in the child restraint system installation manual
and fix the child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child may be
seriously injured or even killed in the event of sudden braking or an accident.
lWhen a booster seat is installed, always ensure that the shoulder belt is
positioned across the center of the child’s shoulder. The belt should be
kept away from the child’s neck, but not so that it could fall off the child’s
shoulder. Failing to do so may result in death or serious injury in the event
of an accident or sudden braking.
lEnsure the belt and tab are securely locked and that the seat belt is not
twisted.
lPush and pull the child seat in different directions to be sure it is secure.
l
Follow all installation instructions provided by the child restraint system
manufacturer.
lIf the driver ’s seat interferes with the
child restraint system and prevents it
from being attached correctly, attach
the child restraint system to the right−
hand rear seat.
lChild restraint system installed on the
third seat should not contact the second
seatbacks.
l
Only put a forward facing or booster
child seat on the front seat when
unavoidable. When installing a forward
facing or booster child restraint on the
front passenger seat, move the seat as
far back as possible even if the AIR
BAG OFF indicator light illuminates.
Failing to do so may result in death or
serious injury if the airbags deploy
(inflate).
