2008 TOYOTA LAND CRUISER Owners Manual

430 4−3. Do−it−yourself maintenance
nParking light
Turn the bulb base counterclock−
wise.
Remove the light bulb.
ITY43C048
STEP1
ITY43C049
STEP2

431
4−3. Do−it−yourself maintenance
4
Maintenance and care
nFront turn signal light
For the left side only: Remove
the securing bolt and move the
washer fluid filler opening.
Turn the bulb base counterclock−
wise.
Remove the light bulb.
ITY43C012
STEP1
ITY43C044
STEP2
ITY43C045
STEP3

432 4−3. Do−it−yourself maintenance
nFront side marker light
For the left side only: Remove
the securing bolt and move the
washer fluid filler opening.
Turn the bulb base counterclock−
wise.
Remove the light bulb.
ITY43C012
STEP1
ITY43C050
STEP2
ITY43C051
STEP3

433
4−3. Do−it−yourself maintenance
4
Maintenance and care
nBackup light
Open the back door and remove
the cover.
Turn the bulb bases counter−
clockwise.
Remove the light bulb.
ITY43C052
STEP1
ITY43C053
STEP2
ITY43C054
STEP3

434 4−3. Do−it−yourself maintenance
nRear turn signal light
Open the back door and remove
the cover.
Turn the bulb bases counter−
clockwise.
Remove the light bulb.
ITY43C058
STEP1
ITY43C059
STEP2
ITY43C060
STEP3

435
4−3. Do−it−yourself maintenance
4
Maintenance and care
nLicense plate light
Open the back door and remove
the license plate light unit.
Turn the bulb base counterclock−
wise.
Remove the light bulb.
STEP1
ITY43C067
STEP2
ITY43C068
STEP3

436 4−3. Do−it−yourself maintenance
nBulbs other than the above
If any of the bulbs listed below
has burnt out, have your Toyota
dealer replace it.
lStop/tail lights
l
Tail lights
l
High mounted stoplight
l
Rear side marker lights
nCondensation buildup on the inside of the lens
Contact your Toyota dealer for more information in the following situations.
Temporary condensation build−up on the inside of the headlight lens does
not indicate a malfunction.
lLarge drops of water are built up on the inside of the lens.
lWater has built up inside the headlight.
nLED light bulbs
The stop/tail, tail, rear side marker and high mounted stoplight consist of a
number of LEDs. If any LEDs burn out, take your vehicle to your Toyota
dealer to have the light replaced.
If two or more LEDs in a stoplight bur
n out, your vehicle may not conform to
local laws (SAE).

437
4−3. Do−it−yourself maintenance
4
Maintenance and care
CAUTION
nReplacing light bulbs
lTurn off the headlights. Do not attempt to replace the bulb immediately
after turning off the headlights.
The bulbs become very hot and may cause burns.
lDo not touch the glass portion of the light bulb with bare hands. Hold the
bulb by the plastic or metal portion.
If the bulb is scratched or dropped it may blow out or crack.
lFully install light bulbs and any parts used to secure them. Failing to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
lDo not attempt to repair or disassemble light bulbs, connectors, electric
circuits or component parts.
Doing so may result in death or serious injury due to electric shock.
n
To prevent damage or fire
Make sure bulbs are fully seated and locked.
