2008 TOYOTA LAND CRUISER Owners Manual

58 1−3. Adjustable components (seats, mirrors, steering wheel)
nFolding up the third seats
Fold down the head restraints
while pulling the head restraint
angle lever.
Push the seatback angle levers
and fold the third seats.
Lift the seats sideward while pull−
ing the seat leg lock release
levers.
The seat back striker will also
automatically sit up.
ITY13C022
STEP1
STEP 2
ITY13C026
STEP3

59
1−3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
Secure the seats by the strikers.
Remove the seat hook covers
from the back of the seat cush−
ion, and install them on the seat
hooks.
nReturning the third seats
Remove the seat hook covers
from the floor and install them
into the back of the seat cushion.
Unlock the seats by pulling the
stowed seat lock release levers
and lower the seats to its original
position.
ITY13C029
STEP4
ITY13C030
STEP5
STEP 1
STEP 2

60 1−3. Adjustable components (seats, mirrors, steering wheel)
Secure the seats by the strikers.
Pull the handle and raise the
seatbacks.
Raise the head restraints.
STEP3
STEP 4
STEP 5

61
1−3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
CAUTION
nSeat adjustment
Do not recline the seat more than necessary when the vehicle is in motion,
to reduce the risk of sliding under the lap belt.
If the seat is too reclined, during an accident the lap belt may slide past the
hips and apply restraint forces directly to the abdomen or your neck may
contact the shoulder belt, increasing the risk of death or serious injury.
nWhen the seatback is folded
lDo not sit on or place anything on the seatback while driving.
lBe sure to install the seat hook covers on the seat hooks, or you may get
burned when they become hot.
nWhen returning the seatbacks to their original position
Observe the following precautions. Failure to do so may result in death or
serious injury.
lBe careful not to get your hands or feet pinched in the seat.
lMake sure the seats are securely locked. Failure to do so will prevent the
seat belt from operating properly.
lCheck that the seat belts are not twisted or caught under the seat.
lArrange the seat belts in the proper positions for ready use.
nAvoiding damage to seat components
Do not hang or attach anything on the seat back striker.
NOTICE
nBefore tumbling, folding up the seats
The seat belts and buckles must be stowed.

62
1−3. Adjustable components (seats, mirrors, steering wheel)
Driving position memor y system
Your preferred driving position (th e position of the driver ’s seat,
steering wheel and outside rear view mirrors) can be entered into the
computer ’s memory and recalled with
the touch of a button. It is also
possible to set this function to activate automatically when the
doors are unlocked.
Three different driving positions can be entered into memory.
nEntering a position to memory
Check that the shift lever is set in “P”.
Switch to IGNITION ON mode.
Adjust the driver ’s seat, steering wheel, and outside rear
view mirrors to the desired positions.
While pressing the “SET” but−
ton, press button “1”, “2” or “3”
until the signal beeps.
If the selected button has
already been preset, the previ−
ously recorded position will be
overwritten.
nRecalling the memorized position
Check that the shift lever is set in “P”.
Switch to IGNITION ON mode.
Press button “1”, “2” or “3” to
recall the desired position.
STEP1
STEP 2
1SET23
1SET23
ITY13C036
STEP3STEP 3
STEP 1
1SET23
1SET23
ITY13C038
STEP2

63
1−3. Adjustable components (seats, mirrors, steering wheel)
1
Before driving
Linking driving position memory with door unlock operation
Record your driving position to button “1”, “2” or “3” before performing
the following:
Using the wireless remote control
Turn the “ENGINE START STOP” switch to OFF and close
the driver ’s door.
While pressing the desired but−
ton (“1”, “2” or “3”), press
on the wireless remote control
until the signal beeps.
The driving position is recalled
when the driver ’s door is
unlocked using the entry function
or wireless remote control and the
driver ’s door is opened.
STEP1
1SET23
ITY13C130
STEP2
nCanceling the linked door unlock operation
Turn the “ENGINE START STOP” switch to OFF and close the
driver ’s door.
Using the wireless remote control: While pressing “SET” button,
press button on the wireless remote control until the signal
beeps.
STEP1
STEP 2

64 1−3. Adjustable components (seats, mirrors, steering wheel)
nRetained accessory power
Each memorized position (except for the steering wheel position) can be
activated within 30 seconds after the driver ’s door is opened, even if the
“ENGINE START STOP” switch turns off.
nTo cancel seat position recall
Perform any one of the following operations.
lPress the “SET” button
lPress button “1”, “2” or “3”.
lAdjust the seat using the switches (only cancels seat position recall)
nIf the battery is disconnected
The memorized positions must be reset because the computer ’s memory is
erased when the battery is disconnected.
CAUTION
nSeat adjustment caution
Take care during seat adjustment that the seat does not strike the rear pas−
senger or squeeze your body against the steering wheel.

65
1
1−3. Adjustable components (seats, mirrors, steering wheel)
Before driving
Head restraints
Front seats, second seats
Vertical adjustment
Press and hold the lock
release button when lowering
the head restraint.
Angle adjustment (front
seats only)
Removal
Pull the head restraint up while
pressing the lock release but−
ton.
Lock
release
button
ITY13C105
ITY13C106
lock
release
button
