2008 TOYOTA LAND CRUISER Owners Manual

349
3−6. Other interior features
3
Interior features
Floor mats
CAUTION
nWhen inserting the floor mat
Observe the following precautions.
Failure to do so may result in the floor mat slipping and interfering with the
movement of the pedals during driving, resulting in an accident.
lMake sure the floor mat is properly placed on the vehicle carpet and the
correct side faces upward.
l
Do not place floor mats on top of existing mats.
Securely place a mat that matches the size of the space on the car
pet.
Secure the floor mat using the
hooks provided.
ITY35C020

350
3−6. Other interior features
Luggage compar tment features
nCargo hooks
Cargo hooks are provided for
securing loose items.
nCargo net hooks
To hang the cargo net, use the
cargo net hooks and rear tie−
down hooks.
The cargo net itself is not
included as an original equip−
ment.
nStorage compartment
Open the storage compart−
ment as shown.
ITY35C022
ITY35C024

351 3−6. Other interior features
3
Interior features
CAUTION
nWhen the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their positions when they
are not in use.
NOTICE
nTo prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.
nWarning reflector holder
Hold the warning reflector with
a band.
The warning reflector itself is
not included as an original
equipment.
nFirstaid kit holder
Hold the first−aid kit with a
band.
The first−aid kit itself is not
included as an original equip−
ment.
ITY35C025
ITY35C026

352
3−6. Other interior features
Garage door opener
The garage door opener (HomeLink Universal Transceiver) is manufac−
tured under license from HomeLink
.
Programming HomeLink (for U.S.A. owners)
The HomeLink compatible transceiver in your vehicle has 3 buttons
which can be programmed to operate 3 different devices. Refer to the
programming method below appropriate for the device.
Buttons
Indicator
The garage door opener can be programmed to operate garage
doors, gates, entry do ors, door locks, home lighting systems, secu
rity systems, and other devices.
ITY35C029

353 3−6. Other interior features
3
Interior features
nProgramming HomeLink
Point the remote control trans−
mitter for the device 1 to 3 in. (25
to 75 mm) from the HomeLink
buttons.
Keep the HomeLink indicator
light in view while programming.
Press and hold one of the
HomeLink buttons and the
transmitter button. When the
HomeLink indicator light
changes from a slow to a rapid
flash, you can release both but−
tons.
If the HomeLink indicator light
comes on but does not flash,
flashes rapidly for 2 seconds and
remains lit, the HomeLink button
is already programmed. Use the
other buttons or follow the
“Reprogramming a HomeLink
button” instructions. (
P. 357)
ITY35C030
STEP1
ITY35C031
STEP2

354 3−6. Other interior features
Test the HomeLink operation
by pressing the newly pro−
grammed button.
If a HomeLink button has been
programmed for a garage door,
check to see if the garage door
opens and closes. If the garage
door does not operate, see if your
remote control transmitter is of
the rolling code type. Press and
hold the programmed HomeLink
button. The remote control trans−
mitter is of the rolling code type if
the HomeLink indicator light
flashes rapidly for 2 seconds and
then remains lit. If your transmit−
ter is of the rolling code type, pro−
ceed to the heading
“Programming a rolling code sys−
tem”.
Repeat the steps above to program another device for each of
the remaining HomeLink
buttons.
ITY35C032
STEP3
STEP 4

355 3−6. Other interior features
3
Interior features
nProgramming a rolling code system
If your device is rolling code e
quipped, follow the steps under the
heading “Programming HomeLink ” before proceeding with the
steps listed below.
Locate the training button on the ceiling mounted garage door
opener motor. The exact location and color of the button may
vary by brand of garage door opener motor.
Refer to the operation manual supplied with the garage door opener
motor for the location of the training button.
Press the training button.
Following this step, you have 30 seconds in which to initiate step 3
below.
Press and hold the vehicle’s programmed HomeLink button
for 2 seconds and release it. Repeat this step once again. The
garage door may open.
If the garage door opens, the programming process is complete. If
the door does not open, press and release the button a third time.
This third press and release will complete the programming process
by opening the garage door.
The ceiling mounted garage door opener motor should now recog−
nize the HomeLink
signal and operate the garage door.
Repeat the steps above to prog ram another rolling code sys−
tem for any of the remaining HomeLink
buttons.
STEP1
STEP 2
STEP 3
STEP 4

356 3−6. Other interior features
nProgramming an entry gate (f or U.S.A. owners)/Programming
all devices in the Canadian market
Place your transmitter 1 to 3 in. (25 to 75 mm) away from the
surface of the HomeLink
.
Keep the HomeLink indicator light in view while programming.
Press and hold the selected HomeLink button.
Repeatedly press and release (cycle) the device’s remote
control button for two seconds each until step 4 is completed.
When the indicator light on the HomeLink
compatible trans−
ceiver starts to flash rapidly, release the buttons.
Test the operation of the HomeLink
by pressing the newly
programmed button. Check to se e if the gate/device operates
correctly.
Repeat the steps above to program another device for each of
the remaining HomeLink
buttons.
nProgramming other devices
To program other devices such
as home security systems, home
door locks or lighting, contact your authorized Toyota dealer for
assistance.
nReprogramming a button
The individual HomeLink
buttons cannot be erased but can be
reprogrammed. To reprogram a button, follow the “Reprogramming
a HomeLink
button” instructions.
STEP1
STEP 2
STEP 3
STEP 4
STEP 5
STEP6
