2008 TOYOTA LAND CRUISER Owners Manual

155
2−1. Driving procedures
2
When driving
Changing shift ranges in “S” mode
Shift the shift lever to the “S” position and operate the shift lever.
Upshifting
Downshifting
The initial shift range in “S” mode is automatically set to “5” or “4”
according to the vehicle’s speed. However, the initial shift range may
be set to “3” or “2” if the AI−SHIFT has operated while the shift lever
was in the “D” position. (
P. 157)
P
R
N
+
SD
ITY21C009

156 2−1. Driving procedures
nShift ranges and their functions
A lower shift range will provide greater engine braking force than a
higher shift range, and the engine
revolutions will also increase.
Shift range Function
6Automatically selecting gears between 1 and 6
according to vehicle speed and driving conditions.
5Automatically selecting gears between 1 and 5
according to vehicle speed and driving conditions.
4Automatically selecting gears between 1 and 4
according to vehicle speed and driving conditions.
3Automatically selecting gears between 1 and 3
according to vehicle speed and driving conditions.
2Automatically selecting gears between 1 and 2
according to vehicle speed and driving conditions.
1
Setting the gear at 1.

157
2−1. Driving procedures
2
When driving
n“S” mode
When the shift range is “5” or lower, holding the shift lever toward “+” sets
the shift range to “6”.
nDownshifting restrictions warning buzzer (in the “S” mode)
To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever is operated. (The warning buzzer will
sound twice.)
nWhen driving with the cruise control system
The engine brake will not operate in
the “S” mode, even when downshifting
to “5” or “4”. (P. 178)
nSecond start mode automatic deactivation
Second start mode is automatically deactivated if the engine is turned off
after driving in second start mode.
n
If the shift lever cannot be shifted from “P”
P. 478
nIf the “S” indicator does not come on even after shifting the shift lever
to “S”
This may indicate a malfunction in the automatic transmission system. Have
the vehicle inspected by your Toyota dealer immediately.
(In this situation, the vehicle will operate as if the shift lever is in “D”.)
nAISHIFT
The AI−SHIFT automatically shifts the gear to the optimal position according
to the driver performance and driving conditions.
The AI−SHIFT automatically operates when the shift lever is in the “D” posi−
tion. (Shifting the shift lever to the “S” position cancels the function.)

158
2−1. Driving procedures
Tur n signal lever
nTurn signals can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
nIf the indicators flash faster than usual
Check that a light bulb in the front or
rear turn signal lights has not burned
out.
Right turn
Left turn
Move and hold the lever
partway to signal a lane
change
The right hand signal will flash
until you release the lever.
Move and hold the lever
partway to signal a lane
change
The left hand signal will flash
until you release the lever.
ITY21C013

159
2−1. Driving procedures
2
When driving
Par king brake
NOTICE
nBefore driving
Fully release the parking brake.
Driving the vehicle with the parking brake set will lead to brake components
overheating, which may affect braking performance and increase brake
wear.
Sets the parking brake
Fully set the parking brake
while depressing the brake
pedal.
Releases the parking brake
Slightly raise the lever and
lower it completely while press−
ing the button.

160
2−2. Instrument cluster
Gauges and meters
The following gauges, meters and display illuminate when the
“ENGINE START STOP” switch is in IGNITION ON mode.
Tachometer
Displays the engine speed in revolutions per minute.
Engine coolant temperature gauge
Displays the engine coolant temperature.
Fuel gauge
Displays the quantity of fuel remaining in the tank.
Speedometer
Displays the vehicle speed.
Vo l t m e t e r
Displays the charge state.
Multi−information display
P. 166

161
2−2. Instrument cluster
2
When driving
Instrument panel light control
The brightness of the instrument panel lights can be adjusted.
Darker
Brighter Odometer and trip meter
Odometer: Displays the total distance the vehicle has been driven.
Trip meter: Displays the distance the vehicle has been driven since the
meter was last reset. Trip meters A and B can be used to record and
display different distances independently.
Engine oil pressure gauge
Displays the engine oil pressure.
Odometer/trip meter and trip meter reset button
Switches between odometer and trip meter displays. Pushing and hold−
ing the button will reset the trip meter when the trip meter is being dis−
played.

162 2−2. Instrument cluster
NOTICE
nTo prevent damage to the engine and its components
lDo not let the indicator needle of the tachometer enter the red zone, which
indicates the maximum engine speed.
lThe engine may be overheating if the engine coolant temperature gauge is
in the red zone (“H”). In this case, immediately stop the vehicle in a safe
place, and check the engine after it has cooled completely. (
P. 488)
nWhile driving
lWhen the voltmeter indicates more than 19 V or less than 9 V, the battery
may be malfunctioning. Have your vehicle checked at your Toyota dealer.
l
When the engine oil pressure gauge does not work properly, immediately
stop the engine and contact your Toyota dealer.
