2008 TOYOTA LAND CRUISER Owners Manual

496 6−1. Specifications
Engine
Fuel
Model3UR−FE
Ty p e
8−cylinder V type, 4−cycle, gasoline
Bore and stroke 3.70 4.02 in. (94.0
102.0 mm)
Displacement 345.6 cu.in. (5663 cm
3)
Valve clearance
(engine cold)
Automatic adjustment
Drive belt tension
Automatic adjustment
Fuel type
Unleaded gasoline only
Octane rating
87 (Research octane number 91) or higher
Fuel tank capacity
24.6 gal. (93 L, 20.5 lmp.gal)

497
6−1. Specifications
6
Vehicle specifications
Lubrication system
Oil viscosity:
l
The 0W portion of the oil viscosity rating indicates the characteristic
of the oil which allows cold startab ility. Oils with a lower value before
the W allow for easier starting of the engine in cold weather.
lThe 20 in 0W−20 indicates the oil viscosity when the oil is as its oper−
ating temperature. An oil with a higher viscosity may be better suited
if the vehicle is operated at high
speeds, or under extreme load con−
dition.
Oil capacity drain and
refill
(Reference)
with filter
without filter7.4 qt. (7.0 L, 6.2 lmp.qt.)
7.0 qt. (6.6 L, 5.8 lmp.qt.)
Oil grade
ILSAC multigrade engine oil
Recommended oil
viscosity
Use Toyota approved “Toyota Genuine Motor Oil”
or equivalent to satisfy the above grade and vis−
cosity.
Outside temperature

498 6−1. Specifications
Cooling system
Ignition system
Capacity16.3 qt. (15.4 L, 13.6 lmp.qt.)
Coolant typeUse either of the following:
“Toyota Super Long Life Coolant”
Similar high−quality ethylene glycol−based non−
silicate, non−amine, non−nitrite, and non−borate
coolant with long−life hybrid organic acid technol−
ogy
Do not use plain water alone.
Spark plug
Make DENSO
GapSK20HR11
0.043 in. (1.1 mm)
NOTICE
nIridiumtipped spark plugs
Use only iridium−tipped spark plugs. Do not adjust gap when tuning engine.

499
6−1. Specifications
6
Vehicle specifications
Electrical system
Differential
“Toyota Genuine Differential Oil” is filled in your Toyota vehicle at factory
fill.
Use Toyota approved “Toyota Genuine Differential Gear Oil” or an
equivalent of matching quality to satisfy the above specification. Please
contact your Toyota dealer for further details.
Battery
Open voltage at
68
F (20 C):12.6 12.8 V Fully charged
12.2 12.4 V Half charged
11.8 12.0 V Discharged
(Voltage is checked 20 minutes after
the key is removed with all lights
turned off.)
Charging rates
5 A max.
Oil capacity
Front
Rear2.00 qt. (1.90 L, 1.67 lmp.qt.)
4.39 qt. (4.15 L, 3.65 lmp.qt.)
Oil type and
viscosity
Toyota Genuine Differential gear oil LT
75W−85 GL−5 or equivalent

500 6−1. Specifications
Automatic transmission
Transfer
Brakes
*1: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50
kgf) while the engine is running.
*2: Parking brake pedal travel when pulled with a force of 45 lbf (200 N, 20 kgf).
Fluid
capacityWithout oil cooler11.5 qt. (10.9 L, 9.6 Imp.qt.)
With oil cooler
11.7 qt. (11.1 L, 9.8 Imp.qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of your transmission accompanied by
vibration, and ultimately damage the transmission of your vehicle.
Oil capacity
1.53 qt. (1.45 L, 1.28 lmp.qt.)
Oil type
Gear oil API GL−5
Recommended oil viscosity
SAE75W−90
Pedal clearance
*13.62 in. (92 mm) Min.
Pedal free play 0.04 0.24 in. (1.0
6.0 mm)
Brake pad wear limit
0.04 in. (1.0 mm)
Parking brake lining wear limit
0.04 in. (1.0 mm)
Parking brake adjustment
*25 7 clicks
Fluid type
SAE J1703 or FMVSS No. 116 DOT 3

501
6−1. Specifications
6
Vehicle specifications
Chassis lubrication
Steering
Propeller shafts
Spider
Slide yokeLithium base chassis grease, NLGI No.2
Molybdenum−disulfide lithium base chas−
sis grease, NLGI No.2 or lithium base
chassis grease, NLGI No.2
Free play
Less than 1.18 in. (30 mm)
Power steering fluid typeAutomatic transmission fluid DEXRON
®II
or III

502 6−1. Specifications
Tires and wheels
Tire sizeP285/60R18 114V
Tire inflation pressure
(Recommended cold tire
inflation pressure)Normal driving
Front tires:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear tires:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare tire:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Trailer towing
Front tires:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Rear tires:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Spare tire:
33 psi (230 kPa, 2.3 kgf/cm
2 or bar)
Wheel size 18
8 J
Wheel nut torque
97 ftlbf (131 Nm, 13.4 kgfm)

503
6−1. Specifications
6
Vehicle specifications
Light bulbs
A: H11 halogen bulbs
B: HB3 halogen bulbs
C: HB4 halogen bulbs
D: Single end bulbs
E: Wedge base bulbs
F: Double end bulbs
Light BulbsBulb No.WTy p e
ExteriorHeadlights
Low beam
High beam9006
900555
60A
B
Front turn signal lights 27 E
Parking lights 5 E
Front side marker lights 5 E
Front fog lights 51 C
Rear turn signal lights 7440 21 E
Back−up lights 921 16 E
License plate lights 168 5
E
InteriorFront interior light 8 E
Rear interior lights
With rear personal lights
Without rear personal lights8
8E
F
Front personal lights 8 E
Rear personal lights 8 E
Vanity lights 1.5 D
Door courtesy lights 5 E
Glove box light 1.2
E
