2006 Lexus GS430 Scheduled Maintenance Guide / LEXUS 2006 GS430/GS300 FROM JAN. 2005 PROD. OWNER'S MANUAL (OM30649U)

IN CASE OF AN EMERGENCY
484
(b) Using a flat bed truck
G40055
Tie down points
G40056
G40057
 AFront BRear
If your Lexus is transported by a flat bed, it should be tied
down at locations A and B as shown above.
G40028
 Rear emergency towing eyelets

IN CASE OF AN EMERGENCY
485
NOTICE
Do not use the rear emergency towing eyelets.
Tie down angle
G40058
If you use chains or wires to tie down your vehicle, the
angles shaded black must be at 45.
(c) Towing with a sling type truck
G40018
NOTICE
Do not tow with a sling type truck, either from the front
or rear. This may cause body damage.

IN CASE OF AN EMERGENCY
486
(d) Emergency towing
G40019
If towing is necessary, we recommend you to have it done
by your Lexus dealer or a commercial tow truck service.
If towing service is not available in an emergency, your
vehicle may be temporarily towed by a cable or chain
secured to the emergency towing eyelet. Use extreme
caution when towing the vehicle.
To install the front towing eyelet, see “Installing towing eyelet”
on page 488.
NOTICE
 Only use specified towing eyelet; otherwise your
vehicle may be damaged.
 Never tow a vehicle from the rear with four wheels on
the ground. This may cause serious damage to the
transmission.
A driver must be in the vehicle to steer it and operate the
brakes.
Towing in this manner may be done only on hard −surfaced
roads for a short distance and at low speeds. Also, the wheels,
axles, drive train, steering and brakes must all be in good
condition.
CAUTION
Use extreme caution when towing the vehicle. Avoid
sudden starts or erratic driving maneuvers which would
place excessive stress on the emergency towing eyelet
and towing cable or chain. The eyelet and towing cable
or chain may break and cause serious injury or damage.
NOTICE
Use only a cable or chain specifically intended for use
in towing vehicles. Securely fasten the cable or chain
to the towing eyelet provided.

IN CASE OF AN EMERGENCY
487
Before towing, release the
parking brake and put the
transmission in ”N”. The engine switch must be selected in
“ACC” or “IG −ON” mode.
CAUTION
If the engine is not running, the power assist for the
brakes and steering will not work so steering and
braking will be much harder than usual.
Emergency towing eyelet precautions:
 Before emergency towing, check that the eyelet is not
broken or damaged and that the installation bolts are not
loose.
 Fasten the towing cable or chain securely to the eyelet.
 Do not jerk the eyelet. Apply steady and even force.
 To avoid damaging the eyelet, do not pull from the side or
at a vertical angle. Always pull straight ahead.
CAUTION
If the emergency towing eyelet is used to get out when
your vehicle becomes stuck in the mud, sand or other
condition from which the vehicle cannot be driven out
under its own power, make sure to observe the
precautions mentioned below. Otherwise, excessive
stress will be put on the eyelet and the towing cable or
chain may break, causing serious injury or damage.
If the towing vehicle can hardly move, do not forcibly
continue the towing. Contact your Lexus dealer or a
commercial tow truck service for assistance.
 Tow the vehicle as straight ahead as possible.
 Keep away from the vehicle during towing.

IN CASE OF AN EMERGENCY
488Tips for towing a stuck vehicle:
The following methods are effective to use when your
vehicle is stuck in the mud, sand or other condition from
which the vehicle cannot be driven out under its own
power. Use extreme caution when towing the vehicle. In
addition, keep away from the vehicles and towing cable or
chain when towing.

Remove the sand and soil in the front and the back of the
tires.
 Place stones or wood under the tires.
(e) Installing towing eyelet
G40020
1. Remove the front towing eyelet cover on the front bumper
by using a flathead screwdriver. To protect the bodywork,
place a piece of rag over the cover.
G40021
2. Use the towing eyelet in the trunk. Secure it to the hole on
the bumper by turning clockwise. (For the eyelet location, see
page 474.)

IN CASE OF AN EMERGENCY
489
G40022
3. Tighten the towing eyelet securely by a wheel nut wrench.
CAUTION
When installing the eyelet on the vehicle, be sure to
tighten the eyelet securely. If the eyelet is loose, it may
come off when being towed and result in death or
serious injury.
IF YOU CANNOT SHIFT
AUTOMATIC TRANSMISSION SELECTOR LEVER
G40001
If you cannot shift the selector lever, use the shift lock
override button as follows:
1Turn the engine switch off. Make sure the parking brake
is applied. Pry up the cover with a flathead screwdriver
or equivalent.

IN CASE OF AN EMERGENCY
490
G40002
2Insert your finger, the screwdriver or equivalent into the
hole to push down the shift lock override button. You can
shift the selector lever while pushing the button.
For your safety, keep the brake pedal depressed.
Be sure to have the system checked by your Lexus dealer as
soon as possible.
IF YOU LOSE YOUR KEYS OR LOCK YOURSELF OUT
You can purchase a new key at your Lexus dealer if you
can give them the key number and electronic key.
Even if you lose only one key, contact your Lexus dealer to
make a new key. If you lose all your electronic keys, you
cannot make new keys; the whole engine immobilizer must be
replaced.
See the suggestion given in “Keys” on page 8.
You can use the smart access system with push −button start
with the new key. Contact your Lexus dealer for detailed
information.
If your keys are locked in the vehicle and you cannot get a
duplicate, many Lexus dealers can still open the door for you,
using their special tools. If you must break a window to get in,
we suggest breaking the smallest side window because it is the
least expensive to replace. Be extremely cautious to avoid
cuts from the glass.

SECTION 5
491
MAINTENANCE
Maintenance
Maintenance requirements492
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 493
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Does your vehicle need repairing? 496
. . . . . . . . . . . . . . . . . . . . . . . . .
Emissions inspection and maintenance (I/M) programs 497
. . . . . . . .
For scheduled maintenance informa tion, please refer
to the “Owner’s Manual Supplement / Scheduled
Maintenance”.
