EXTERIOR EQUIPMENT
132
MOON ROOF
G15010
 1Open 2Close
To slide open the moon roof, push the “OPEN” button for
about 1 second. The moon roof will open and stop
partway 40 mm (1.6 in.) from the fully opened position.
When you push the switch once again, the moon roof will
fully open. To stop partway, push the “OPEN”, “CLOSE”,
“UP” or “DOWN” button briefly.
As driving with the moon roof opened fully will cause wind
throbs, we recommend you to drive with the moon roof partway
40 mm (1.6 in.) from the fully opened position.
The sun shade can be opened or closed manually. However,
if you open the moon roof, the sun shade will be opened with
the moon roof. To close the moon roof, push the “CLOSE” button for
about 1 second. The moon roof will fully close. To stop
partway, push the “OPEN”, “CLOSE”, “UP” or “DOWN”
button briefly.
G15011
 1
Tilt up 2Lower
To tilt up the moon roof, push the “UP” button for about
1 second. The moon roof will fully tilt up. To stop partway,
push the “UP”, “DOWN”, “O PEN” or “CLOSE” button
briefly.
To lower the moon roof, push the “DOWN” button for
about 1 second. The moon roof will be fully lowered. To
stop partway, push the “UP”, “DOWN”, “OPEN” or
“CLOSE” button briefly.
To operate the moon roof, the engine switch must be selected
in “IG− ON” mode.

EXTERIOR EQUIPMENT
133
If the moon roof is left open when you turn the engine switch
to “OFF” mode and open the driver’s door, a buzzer will remind
you to close the moon roof.
Retained accessory power operation:
Even if the engine
switch is off, the moon roof can be operated until any of the
doors is opened (or for about 45 seconds).
Operating the moon roof from outside the
vehicle
The moon roof can be closed or opened using a mechanical
key.*
NOTE:
*This feature can be deactivated, or sliding open or tilting up
can be selected.
Ask your Lexus dealer for details.
G15020
Insert the mechanical key into the key hole on the driver’s
door.
To close the moon roof: Turn the key in the locking direction
and hold it.
After the door is locked, the moon roof begins to close. To stop
in the middle, return the key.

EXTERIOR EQUIPMENT
134To open the moon roof:
Turn the key in the unlocking
direction and hold it.
After the door is unlocked, the moon roof begins to open. To
stop in the middle, return the key.
Jam protection function
If something gets caught into the roof opening during closing
operation, the moon roof stops and is open.
If the moon roof receives a strong impact, this function may
work even if nothing is caught.
If the battery is disconnected or run down
The moon roof may not operate automatically and the jam
protection function will not function correctly after you
reconnect, replace or recharge the battery. In any of these
cases, you should normalize the moon roof.
To normalize the moon roof, push and hold the “UP” button until
the moon roof tilts all the way up and then down a little
automatically.
Make sure the moon roof opens and closes automatically. If
the moon roof cannot be operated properly, have it checked by
your Lexus dealer.
CAUTION
To avoid serious personal injury, you must do the
following.
 While the vehicle is moving, always keep the heads,
hands and o ther parts of the bodies of all occupants
away from the roof opening. Otherwise, they could
be seriously injured if the vehicle stops suddenly or
if the vehicle is involved in an accident.
 Before you close the moon roof, always make sure
there is nobody around the moon roof. You must also
make sure nobody places his or her head, hands and
other parts of the body in the roof opening. If
someone’s neck, head or hands get caught in the
closing roof, it could result in death or serious injury.
When anyone closes the moon roof, first make sure
it is safe to do so.
 Be sure to turn the engine switch to “OFF” mode
when you leave your vehicle.
 Never leave anyone (particularly a small child) alone
in your vehicle, especially when the engine switch is
on. Otherwise, he/she could use the moon roof
switches and get trapped in the roof opening.
Unattended persons (particularly a small child) can
be involved in a serious accident.
 Never sit on top of the vehicle around the roof
opening.

EXTERIOR EQUIPMENT
135
Never try jamming any part of your body to activate
the jam protection function intentionally.
 The jam protection function may not work if
something gets caught just before the moon roof
fully closed.

EXTERIOR EQUIPMENT
136

SECTION 1 – 6
137
INSTRUMENTS AND CONTROLS
Occupant restraint systems
Seats138
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . .
Front seats 138
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Rear seats 143
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Armrest 144
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Head restraints 144
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Seat belts 147
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
SRS driver airbag and front passenger airbag 158
. . . . . . . . . . . . . . . .
SRS side airbags and curtain shield airbags 168
. . . . . . . . . . . . . . . . .
Child restraint 178
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Driving position memory system 198
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front passenger seat position memory system 200
. . . . . . . . . . . . . . .

OCCUPANT RESTRAINT SYSTEMS
138
SEATS
While the vehicle is being driven, all vehicle occupants should
have the seatback upright, sit well back in the seat and properly
wear the seat belts provided.
CAUTION
 Do not drive the vehicle unless the occupants are
properly seated. Do not allow any passengers to sit
in the luggage compartment or cargo area. Persons
not properly seated and/or not properly restrained by
seat belts can be severely injured in the event of
emergency braking or a collision.
 During driving, do not allow any passengers to stand
up or move around between seats. Otherwise, severe
injuries can occur in the event of emergency braking
or a collision.
FRONT SEATS
Front seat precautions
Driver seat
CAUTION
The SRS driver airbag deploys with considerable force,
and can cause death or serious injury especially if the
driver is very close to the airbag. The National Highway
Traffic Safety Administration (”NHTSA”) advises:
Since the risk zone for driver airbag is the first 5075
mm (23 in.) of inflation, placing yourself 250 mm (10 in.)
from your driver airbag provides you with a clear margin
of safety. This distance is measured from the center of
the steering wheel to your breastbone. If you sit less
than 250 mm (10 in.) away now, you can change your
driving position in several ways:
 Move your seat to the rear as far as you can while still
reaching the pedals comfortably.
 Slightly recline the back of the seat. Although vehicle
designs vary, many drivers can achieve the 250 mm
(10 in.) distance, even with the driver seat all the way
forward, simply by reclining the back of the seat
somewhat. If reclining the back of your seat makes
it hard to see the road, raise yourself by using a firm,
nonslippery cushion, or raise the seat if your vehicle
has that feature.

OCCUPANT RESTRAINT SYSTEMS
139
If your steering wheel is adjustable, tilt it downward.
This points the airbag toward your chest instead of
your head and neck.
The seat should be adjusted as recommended by
NHTSA above, while still maintaining control of the foot
pedals, steering wheel, and your view of the instrument
panel controls.
Front passenger seat
CAUTION
The SRS front passenger airbag also deploys with
considerable force, and can cause death or serious
injury especially if the front passenger is very close to
the airbag. The front passenger seat should be as far
from the airbag as possible with the seatback adjusted,
so the front passenger sits upright.
Front seats
CAUTION
The SRS front side airbags are installed in the driver and
front passenger seats. Observe the following
precautions.
 Do not lean against the front door when the vehicle
is in use, since the front side airbag inflates with
considerable speed and force. Otherwise, you may
be killed or severely injured.
 Do not use seat accessories which cover the parts
where the front side airbags inflate. Such
accessories may prevent the front side airbags from
activating correctly, causing death or serious injury.
 Do not modify or replace the front seats or upholstery
of the seats equipped with front side airbags. Such
change may prevent the side airbag system from
activating correctly, disable the system or cause the
front side airbags to inflate accidentally, resulting in
death or serious injury.
