INTRODUCTION
508
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do−it−yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
Checking the engine oil level
Parts (if level is low):
“Toyota Genuine Motor Oil” or equivalent
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil. For recommended oil viscosity, see
page 525.
Tools:
 Rag or paper towel
 Funnel (only for adding oil)
Checking the engine coolant level
Parts (if level is low):
”Toyota Super Long Life Coolant” or similar high quality
ethylene glycol based non −silicate, non −amine, non −nitrite,
and non −borate coolant with long −life hybrid organic acid
technology.
“Toyota Super Long Life Coolant” is a mixture of 50%
coolant and 50% deionized water (for the U.S.A.) or 55% of
coolant and 45% deionized water (for Canada).
Tools:
 Funnel (only for adding coolant)
Checking brake fluid
Parts (if level is low):
FMVSS No. 116 DOT 3 or SAE J1703 brake fluid
Tools:
 Funnel (only for adding fluid)
Checking battery condition
Tools:
Warm water
 Baking soda
 Grease
 Conventional wrench (for terminal clamp bolts)

INTRODUCTION
509
Checking and replacing the blade type fuses
Parts (if replacement is necessary):
Fuse with same amperage rating as original
Checking the cartridge type fuses
Parts (if replacement is necessary):
Genuine Lexus fuse or equivalent with same amperage
rating as original
Adding washer fluid
Parts:
Water
 Washer fluid containing antifreeze (for winter use)
Tools:
 Funnel

INTRODUCTION
510

SECTION 6 – 2
511
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications (GS430)512
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications (GS300) 515
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 518
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel pump shut off system 520
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumption 520
. . . . . . . . . . . . . . . . . . . . . . . .
Used engine oil 522
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Checking the engine oil level 522
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 527
. . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the radiator and condenser 529
. . . . . . . . . . . . . . . . . . . . . . .
Spark plugs 529
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .

ENGINE
512
SPECIFICATIONS (GS430)
– GENERALModel
3UZ−FE
Type8 cylinder V type, 4 cycle, gasoline
Bore and stroke91.0 X 82.5 mm (3.58 X 3.25 in.)
Displacement4293 cm3 (262.0 cu.in.)
Valve clearance (engine cold) Intake
Exhaust0.15 − 0.25 mm (0.006 − 0.010 in.)
0.25 − 0.35 mm (0.010 − 0.014 in.)
Drive belt tensionAutomatic adjustment
– FUEL
Fuel type
Unleaded gasoline only
Octane rating91 (Research octane number 96) or higher

62L042
Outside temperature
ENGINE
513
– LUBRICATION SYSTEM
Oil capacity Drain and refillwith filter
without filter
5.1 L (5.4 qt., 4.5 lmp.qt.)
4.5 L (4.8 qt., 4.0 lmp.qt.)
Oil gradeAPI grade SL “Energy− Conserving” or ILSAC multigrade engine oil
Recommended oil viscosity5W−30
NOTE:
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “T oyota Genuine Motor Oil” or equivalent to satisfy
the above grade and viscosity. Please contact your Lexus dealer for further details.

ENGINE
514– COOLING SYSTEM
Capacity
10.1 L (10.7 qt., 8.9 lmp.qt.)
Coolant type”Toyota Super Long Life Coolant” or similar high quality ethylene glyco\
l
based non −silicate, non− amine, non−nitrite, and non −borate coolant
with long −life hybrid organic acid technology (Coolant with long −life
hybrid organic acid technology is a combination of low phosphates and
organic acids.)
Do not use plain water alone.
NOTE:
“Toyota Super Long Life Coolant” is used in your Lexus vehicle at factory fil\
l. In order to avoid technical problems, only use ”Toyota
Super Long Life Coolant” or similar high quality ethylene glycol based non −silicate, non −amine, non −nitrite, and non −borate coolant
with long−life hybrid organic acid technology. (Coolant with long −life hybrid organic acid technology is a combination of low
phosphates and organic acids.) Do not use plain water alone. Please contact you\
r Lexus dealer for further details.
– IGNITION SYSTEM
Spark plug – Make DENSO NGK
– Gap
SK20R11
IFR6A11
1.1 mm (0.043 in.)
– ELECTRICAL SYSTEM
Battery – Open voltage at 20 C (68F):
– Charging rates
12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the engine switch is off with all
the lights turned off]
5A max.

ENGINE
515
SPECIFICATIONS (GS300)
– GENERALModel
3GR−FSE
Type6 cylinder V type, 4 cycle, gasoline
Bore and stroke87.5 X 83.0 mm (3.44 X 3.26 in.)
Displacement2995 cm3 (182.75 cu.in.)
Valve clearance (engine cold) Intake
ExhaustAutomatic adjustment
Automatic adjustment
Drive belt tensionAutomatic adjustment
– FUEL
Fuel type
Unleaded gasoline only
Octane rating91 (Research octane number 96) or higher
