2006 Lexus GS430 Scheduled Maintenance Guide / LEXUS 2006 GS430/GS300 FROM JAN. 2005 PROD. OWNER'S MANUAL (OM30649U)

OCCUPANT RESTRAINT SYSTEMS
188
G16054
2. Fully extend the shoulder belt to put it in the lock mode.
When the belt is then retracted even slightly, it cannot be
extended.
To hold the convertible seat securely, make sure the belt is in
the lock mode before letting the belt retract.
G16055
3. While pressing the convertible seat firmly against the seat
cushion and seatback, let the shoulder belt retract as far as it
will go to hold the convertible seat securely.

OCCUPANT RESTRAINT SYSTEMS
189
G16056
CAUTION
Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its manufacturer.
G16057
4. To remove the convertible seat, press the buckle release
button and allow the belt to retract completely. The belt will
move freely again and be ready to work for an adult or older
child passenger.

OCCUPANT RESTRAINT SYSTEMS
190(C) Booster seat installation
G16040
A booster seat must be used in forwardfacing position
only.
G16059

Move seat fully back
CAUTION
 A forwardfacing child restraint system should be
allowed to be installed on the front passenger seat
only when it is unavoidable. Always move the seat
as far back as possible, because the front passenger
airbag could inflate with considerable speed and
force. Otherwise, the child may be killed or seriously
injured.

OCCUPANT RESTRAINT SYSTEMS
191
Do not allow the child to lean his/her head or any part
of his/her body against the door or the area of the
seat, front or rear pillar or roof side rail from which the
front (or rear) side airbags or curtain shield airbags
deploy even if the child is seated in a child restraint
system. It is dangerous if the front (and rear) side
airbags and curtain shield airbags inflate, and the
impact could cause death or serious injury to the
child.
G16060
1. Sit the child on a booster seat. Run the lap and shoulder belt
through or around the booster seat and across the child
following the instructions provided by its manufacturer and
insert the tab into the buckle taking care not to twist the belt.
Make sure the shoulder belt is correctly across the child’s
shoulder and that the lap belt is positioned as low as possible
on the child’s hips. See ”Seat belts” on page 147 for details.
CAUTION
 Always make sure the shoulder belt is positioned
across the center of child’ s shoulder. The belt should
be kept away from child’s neck, but not falling off
child’s shoulder. Otherwise, the child may be killed
or seriously injured in case of sudden braking or a
collision.

OCCUPANT RESTRAINT SYSTEMS
192
Both highpositioned lap belts and loosefitting
belts could cause death or serious injuries due to
sliding under the lap belt during a collision or other
unintended event. Keep the lap belt positioned as
low on a child’s hips as possible.
 For child’s safety, do not place the shoulder belt
under child’s arm.
 After inserting the tab, make sure the tab and buckle
are locked and that the lap and shoulder portions of
the belt are not twisted.
 Do not insert coins, clips, etc. in the buckle as this
may prevent your child from properly latching the tab
and buckle.
 If the seat belt does not function normally, it cannot
protect your child from death or serious injury.
Contact your Lexus dealer immediately. Do not
install the child restraint system on the seat until the
seat belt is fixed.
G16061
2. To remove the booster seat, press the buckle release button
and allow the belt to retract.

OCCUPANT RESTRAINT SYSTEMS
193
Using a top strap
G16062
Follow the procedure below for a child restraint system
that requires the use of a top strap.
G16063
 1Anchor bracket 2Symbol
Use the anchor bracket on the package tray behind the rear
seat to attach the top strap.
Anchor brackets are installed for each rear seating position.
This symbol indicates the locations of the anchor bracket.

OCCUPANT RESTRAINT SYSTEMS
194
G16121
TO USE THE ANCHOR BRACKET
1. Lower the head restraint to the lowest position.
G16122
2. Push the lid of the anchor bracket to open it.

OCCUPANT RESTRAINT SYSTEMS
195
G16064
3. Fix the child restraint system with the seat belt.
4. Latch the hook onto the anchor bracket and tighten the
top strap.
For instructions to install the child restraint system, see “Types
of child restraint system” on page 180.
CAUTION
Make sure the top strap is securely latched, and check
that the child restraint system is secure by pushing and
pulling it in different directions. Follow all the
installation instructions provided by its manufacturer.
Installation with child restraint lower
anchorages
G16065
Lower anchorages for the child restraint systems
complying with the FMVSS225 or CMVSS210.2
specifications are installed in the rear seat.
The anchorages are installed in the gap between the seat
cushion and seatback of both outboard rear seats.
Child restraint system comp lying with the FMVSS213 or
CMVSS213 specification can be fixed to these anchorages. In
this case, it is not necessary to fix the child restraint system
with a seat belt on the vehicle.
