2006 Lexus GS430 Scheduled Maintenance Guide / LEXUS 2006 GS430/GS300 FROM JAN. 2005 PROD. OWNER'S MANUAL (OM30649U)

ENGINE
524
G62006
GS300 (fourwheel drive models)
1
Add oil 2O.K. 3Too full
4. Pull the dipstick out and look at the oil level while holding a
rag under the end. If it is between the full level mark (
5 ) and
the low level mark ( 4 ), it is O.K.
NOTICE
Be careful not to drop engine oil on the vehicle
components.
G62003
GS430 GS300
If the oil level is below or only slightly above the low level
mark, add engine oil of the same type as already in the
engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil. The approximate quantity of oil needed to
raise the level between low and full on the dipstick is indicated
as follows:
1.5 L (1.6 qt., 1.3 lmp. qt.)
For the engine oil capacity, see “Specifications” on pages 512
and 515.
When the level reaches within the correct range, return the
filler cap and turn the cap clockwise until you hear a click.

ENGINE
525
NOTICE
Be careful not to spill engine oil on the vehicle
components.
 Avoid overfilling, or the engine could be damaged.
 Check the oil level on the dipstick once again after
adding the oil.
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use
Lexus approved “Toyota Genuine Motor Oil” or equivalent to
satisfy the following grade and viscosity.
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil.
Recommended viscosity: 5W−30
62L042
Outside temperature
SAE 5W30 is the best choice for good fuel economy, and
good starting in cold weather.
If SAE 5W30 is not available, SAE10W30 may be used.
However, it should be replaced with 5W30 at the next oil
change.

ENGINE
526
Oil identification marks
62L038
API Service Symbol ILSAC Certification Mark
Either or both API registered marks are added to some oil
containers to help you select the oil you should use.
 The API Service Symbol is located anywhere on the outside
of the container.
The top portion of the label shows the oil quality by API
(American Petroleum Institut e) designation such as SL.
The center portion of the label shows the SAE viscosity
grade such as SAE 5W −30. ”Energy− Conserving”, shown
in the lower portion, indicates that the oil has fuel −saving
capabilities.
 The ILSAC (International L ubricant Standardization and
Approval Committee) Certification Mark is displayed on the
front of the container. To ensure excellent lubrication for your engine, “Toyota
Genuine Motor Oil” is available, which has been specifically
tested and approved for all Lexus engines.
Please contact your Lexus deal
er for further details about
“Toyota Genuine Motor Oil”.

ENGINE
527
CHECKING THE ENGINE COOLANTLEVEL
G62007
GS430
1
Reservoir cap 2“FULL” line 3“LOW” line
G62008
GS300
1
Reservoir cap 2“FULL” line 3“LOW” line Look at the seethrough coolant reservoir when the
engine is cold. The coolant level is satisfactory if it is
between the”FULL” and ”LOW” lines on the reservoir. If
the level is low, add the coolant. (For the coolant type, see
“Coolant type selection” described below.)
The coolant level in the reservoir will vary with engine
temperature. However, if the level is on or below the ”LOW”
line, add coolant. Bring the level up to the ”FULL” line.
If the coolant level drops within a short time after replenishing,
there
may be a leak in the system. V isually check the radiator,
hoses, engine coolant filler cap, radiator cap and drain cock
and water pump.
If you can find no leak, have your Lexus dealer test the cap
pressure and check for leaks in the cooling system.
CAUTION
To prevent burning yourself, do not remove the radiator
cap when the engine is hot.

ENGINE
528
Coolant type selection
Use of improper coolants may damage your engine cooling
system.
Only use ”Toyota Super Long Life Coolant” or similar high
quality ethylene glycol based non−silicate, non −amine,
non− nitrite, and non −borate coolant with long −life hybrid
organic acid technology. (Coolant with long −life hybrid organic
acid technology is a combination of low phosphates and
organic acids.)
For the U.S.A.—“Toyota Super Long Life Coolant” is a mixture
of 50% coolant and 50% deionized water. This coolant
provides protection down to about −35C (− 31F).
For Canada—“Toyota Super Long Life Coolant” is a mixture of
55% coolant and 45% deionized water. This coolant provides
protection down to about −42C (− 44F).
NOTICE
Do not use plain water alone.
Lexus recommends “Toyota Super Long Life Coolant,” which
has been tested to ensure that it will not cause corrosion nor
result in malfunction of your engine coolant system with proper
usage. “Toyota Super Long Life Coolant” is formulated with
long−life hybrid organic acid technology and has been
specifically designed to avoid engine cooling system
malfunction on Lexus vehicles.
Please contact your Lexus dealer for further details.

ENGINE
529
CHECKING THE RADIATOR ANDCONDENSER
If either of the above parts are extremely dirty or you are not
sure of their condition, take your vehicle to your Lexus dealer.
CAUTION
To prevent burning yourself , be careful not to touch the
radiator or condenser when the engine is hot.
NOTICE
To prevent damage to the radiator and condenser, do
not perform the work by yourself.
SPARK PLUGS
62R031c
GS430
Your engine is fitted with iridiumtipped spark plugs.
NOTICE
Use only iridiumtipped spark plugs and do not adjust
gaps for your engine performance and smooth
drivability.

ENGINE
530
G62009
GS300
Your engine is fitted with the designated iridiumtipped
spark plugs.
NOTICE
Use the designated iridiumtipped spark plugs only and
do not adjust gaps for your engine performance and
smooth drivability.

SECTION 6 – 3
531
SERVICE PROCEDURES AND
SPECIFICATIONS
Chassis
Specifications (GS430)532
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications (GS300) 535
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking brake fluid 538
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Checking tire inflation pressure 539
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire information 542
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Run−flat tires 552
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Types of tires 553
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Rotating tires 554
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Checking and replacing tires 554
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing snow tires and chains 558
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing wheels 560
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Aluminum wheel precautions 561
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension and chassis 562
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
