AIR CONDITIONING
268This
button allows the air intake to select OUTSIDE AIR mode
automatically. This is to clean up the front view more quickly.
If you want to return the setting to RECIRCULATED AIR mode,
push the air intake control button once again.
Touch the “A/C” switch for dehumidified heating or cooling.
This setting clears the front view more quickly.
 To heat the vehicle interior while defrosting the windshield,
choose floor/windshield air flow.
(e) Center vents, side vents and rear vents
G21015
Center vents
G21016
Side vents (driver’s side)
G21064
Side vents (front passenger’s side)

AIR CONDITIONING
269
G21017
Rear vents
If air flow control is not satisfactory, check the center
vents, side vents and rear vents. They may be opened or
closed as shown.
(f) Replacing the air conditioning filter
G21011
The air conditioning filter information label is placed in the
glove box as shown and indicates that a filter has been
installed.
The air conditioning filter, in addition to removing odors,
prevents dust and pollen from entering the vehicle through the
air conditioning vent.

AIR CONDITIONING
270
G21012
The air conditioning filter is behind the glove box.
The air conditioning filter may clog after long use. The filter
may need to be replaced if the air flow of the air conditioning
and heater experiences extreme reductions in operating
efficiency, or if the windows fog up easily.
If the symptoms of air conditioning efficiency problems occur,
contact your nearest Lexus dealer to have the filter replaced.
To maintain the air conditioning efficiency, replace the air
conditioning filter according to the maintenance schedule. In
dusty areas or areas with heavy traffic flow, such as inner city
or desert areas, early replacement may be required. (For
scheduled maintenance information, see the “Owner’s Manual
Supplement / Scheduled Maintenance”). 1. Turn the air intake control to RECIRCULATED AIR
mode.
The filter case cannot be removed in the OUTSIDE AIR mode.
2. Turn off the engine switch.
3. When you replace the filter, be sure to turn off the fan.G21013
4. Open
the glove box and remove the partition by pulling.
G21019

AIR CONDITIONING
271
5. Pull the filter cover toward you.
G21020
6. Push the tabs and pull the filter case toward you.
G21021
7. Take out the filter.
G21022
8. Remove the filter from the filter case.
9. Inspect the filter on the surface.
If it is dirty, it should be replaced.
NOTICE
When setting the filter to the filter case, the UP marks
shown on the filter and filter case should be noted and
fitted as shown.
INFORMATION
The air conditioning filter should be installed properly
in position. The use of air conditioning with the filter
removed may cause deteriorated dustproof perfor-
mance and then affect air conditioning performance.

AIR CONDITIONING
272

SECTION 2 – 2
273
AIR CONDITIONING AND AUDIO
Audio
Audio system274
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .

AUDIO
274
AUDIO SYSTEM
Quick reference for your audio system
G22108
 AVehicles with Navigation system BVehicles without Navigation system

AUDIO
275
1Audio operation screen display button
The audio operation screen is shown.
2Function switch display screen
(See page 280 for details.)
3
CD slot
(See page 300 or details.)
4Mode selectors
(See page 279 for details.)
5
Frequency turning knob
(See page 285 for details.)
6
CD load button
(See page 300 for details.)
7Radio mode: Preset tuning
(See page 285 for details.)
Tape mode: Side change of cassette tape
(See page 298 for details.)
CD mode: Disc selection
(See page 303 for details.)
8
Scan button
(See page 286 for details.)
9
Cassette tape slot
(See page 296 for details.)
10Stopping and ejecting a cassette tape
(See page 296 for details.)
11Radio mode: Seek tuning
(See page 286 for details.)
Tape/CD mode: Direct access to a desired
program
(See page 299 or 304 for details.)
12Ejecting a CD
(See page 301 or details.)
13Turning the system on and adjusting the volume
(See page 279 for details.)
