2006 Lexus GS430 Scheduled Maintenance Guide / LEXUS 2006 GS430/GS300 FROM JAN. 2005 PROD. OWNER'S MANUAL (OM30649U)

BODY
596
Carpets, Windows and Seat Belts
Begin by vacuuming thoroughly to remove as much dirt as
possible. Several types of foam cleaners are available; some
are in aerosol cans and others are powders or liquids which
you mix with water to produce a foam. To shampoo the
carpets, use a sponge or brush to apply the foam. Rub in
overlapping circles. Do not apply water − the best results are
obtained by keeping the carpet as dry as possible. Read the
shampoo instructions and follow them closely.
The seat belts may be cleaned with mild soap and water
or with lukewarm water.
Use a cloth or sponge. As you are cleaning, check the belts
for excessive wear, fraying or cuts.
NOTICE
 Use a good foamtype shampoo to clean the carpets.
 Do not use dye or bleach on the belts it may weaken
them.
 Do not use the belts until they become dry.
 The windows may be cleaned with any household
window cleaner.
 When cleaning the inside of the rear window, be
careful not to scratch or damage the heater wires.
Air Conditioning Control Panel, Audio
System, Instrument Panel, Console Panel,
and Switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or lukewarm water then lightly
wipe off any dirt.
NOTICE
 Do not use organic substances (solvents, kerosene,
alcohol, gasoline, etc.) or alkaline or acidic solutions.
These chemicals can cause discoloring, staining or
peeling of the surface.
 If you use cleaners or polishing agents, make sure
their ingredients do not include the substances
mentioned above.
 If you use a liquid car freshener , do not spill the liquid
onto the vehicle’s interior surfaces. It may contain
the ingredients ment ioned above. Immediately clean
any spill using the method mentioned above.
If you have any questions about the cleaning of your
Lexus, your local Lexus dealer will be pleased to answer
them.

SECTION 7
597
REPORTING SAFETY DEFECTS
FOR U.S. OWNERS
Reporting safety defects for U.S. owners
Reporting safety defects for U.S. owners598
. . . . . . . . . . . . . . . . . . . .

REPORTING SAFETY DEFECTS FOR U.S. OWNERS
598
REPORTING SAFETY DEFECTSFOR U.S. OWNERS
If you believe that your vehicle has a defect which
could cause a crash or could cause injury or death,
you should immediately inform the National
Highway Traffic Safety Administration (NHTSA) in
addition to notifying Toyota Motor Sales, U.S.A.,
Inc. (Toll −free: 1 −800− 25−LEXUS).
If NHTSA receives similar complaints, it may open
an investigation, and if it finds that a safety defect
exists in a group of vehicles, it may order a recall
and remedy campaign. However, NHTSA cannot
become involved in individual problems between
you, your dealer, or Toyota Motor Sales, U.S.A.,
Inc.
To contact NHTSA, you may either call the Auto
Safety Hotline toll− free at 1−800−424−9393 (or
366−0123 in Washington, D.C. area) or write to:
NHTSA, U.S. Department of Transportation,
Washington, D.C. 20590. You can also obtain
other information about motor vehicle safety from
the Hotline.

cm1
You should know as much about the quality and
importance of proper maintenance of your new
vehicle as the people who built it.
The Lexus authorized Repair Manual tells you
how to maintain your vehicle and enables you to
correctly perform your own maintenance.
The best way to keep your new vehicle in top running
order is to maintain it properly from the moment you
drive it off the showroom floor.
The Lexus authorized Repair Manual is packed with
literally everything you need to know to perform your
own maintenance in virtually every area of your new
vehicle.

cm2
Maintenance procedures for the engine, chassis,
body, electrical system, and more, are clearly
explained and illustrated.
Periodic maintenance and tuneup
Periodic maintenance and tuneup helps to prevent small
problems from growing into larger ones later on. The repair
manual outlines exactly what maintenance is required and
clearly explains how to do the work yourself stepbystep.
Areas covered include such things as spark plug replacement,
valve clearance adjustment and engine oil and filter
replacement.
Where to obtain the Repair Manual
The repair manual for GS430, GS300 may be purchased from
any Lexus dealer or call the Material Distribution Center. To
purchase the repair manual, please contact your Lexus dealer
or the Material Distribution Center tollfree at
18006222033.

GAS STATION INFORMATION
Fuel selection:
Select premium unleaded gasoline with an Octane Rating
of 91 (Research Octane Number 96) or higher for optimum
engine performance. However, if such premium type
cannot be obtained, you may temporarily use unleaded
gasoline with an Octane Rating as low as 87 (Research
Octane Number 91).
 Fuel tank capacity:
71 L (18.7 gal., 15.6 lmp.gal.)
 Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil.
Recommend oil viscosity − SAE 5W−30 if normal
temperatures are below 38 C (100F)
Oil capacity: L (qt., lmp.qt.)
Drain and refill with filter without filter GS430 5.1 (5.4, 4.5) 4.5 (4.8, 4.0)
GS300 (2WD) 6.3 (6.6, 5.5) 5.9 (6.2, 5.1)
GS300 (4WD) 6.4 (6.7, 5.6) 6.0 (6.3, 5.2)
See page 522 for detailed information.
 Engine coolant:
Capacity: GS430 − 10.1 L (10.7 qt., 8.9 lmp.qt.)
GS300 − 9.1 L (9.6 qt., 8.0 lmp.qt.) Coolant type −
”Toyota Super Long Life Coolant” or similar
high quality ethylene glycol based non −silicate, non −amine,
non−nitrite, and non −borate coolant with long −life hybrid
organic acid technology (Coolant with long −life hybrid
organic acid technology is a combination of low phosphates
and organic acids.)
Do not use plain water alone.
For checking the engine coolant, see page 527.
 Automatic transmission:
Fluid type − “Toyota Genuine ATF WS”
See page 532 or 535 for detailed information.
 Tire information:
See page 539 through 561 for detailed information.
 Tire inflation pressure:
Tire size: GS430 − 245/40R18 93Y or P245/40R18 93V
GS300 − 225/50R17 94W or P225/50R17 93V
Tire inflation pressure:
Front 230 kPa (2.3 kgf/cm
2 or bar, 33 psi)
Rear 230 kPa (2.3 kgf/cm2 or bar, 33 psi)
For sustained high speeds above 160 km/h (100 mph), in
countries where such speeds are permitted by law, add the
tire inflation pressure given below to the front tires and rear
tires, but never exceed the maximum cold tire inflation
pressure molded on the tire sidewall.
GS430 60 kPa (0.6 kgf/cm
2 or bar, 9 psi)
GS300 50 kPa (0.5 kgf/cm2 or bar, 7 psi)
