IN CASE OF AN EMERGENCY
468
IF YOU HAVE A FLAT TIRE
(Vehicles with runflat tires)
G63004
You may continue driving a vehicle with runflat
tires even if any tire goes flat. It may be able to run
for a maximum of 160 km (100 miles) at a speed
below 90 km/h (55 mph) after the low tire pressure
warning light comes on. When you drive your
vehicle after the low tire pressure warning light
comes on, the tire must be replaced. Do not use the
repaired tire.
Observe the following precautions and take your vehicle
to the nearest Lexus dealer or authorized tire dealer.
CAUTION
If the low tire pressure warning light comes on,
take your vehicle to the nearest Lexus dealer or
authorized tire dealer as soon as possible,
observing the following instructions:
 Decelerate as soon as possible to the most
appropriate speed that conditions permit. Do
not drive for longer than 160 km (100 miles) or
over 90 km/h (55 mph).
 Avoid abrupt steering wheel maneuvering and
braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the
brakes, causing death or serious injury.
 The warning system may not activate
immediately if bursts or sudden air leakage
should occur.

IN CASE OF AN EMERGENCY
469
NOTICE
Do not use liquid sealants for a flat tire as tire
pressure sensors will be damaged.
 Take due care not to go over a curb stone and
be careful of the holes in the road because
deflated tire pressure affects tire cushion
performance. The wheels, tires, body,
suspension and other components could be
damaged.
 Your ground clearance is reduced if the runflat
tire goes flat so avoid driving over obstacles
and drive slowly on rough, unpaved roads and
speed bumps. Also, do not attempt to go
through an automatic car wash as the vehicle
may get caught, resulting in damage.
 When the tires must be replaced, have them
replaced by the nearest Lexus dealer or
authorized tire dealer. The tire pressure
sensors will be affected by the installation or
removal of tires.
 When the tires must be replaced, replace the
grommets for tire pressure sensors as well.
IF YOU HAVE A FLAT TIRE
(Vehicles with standard tires)
CAUTION
If the low tire pressure warning light comes on,
observe the following instructions:
 Decelerate as soon as possible to the most
appropriate speed that conditions permit.
 Avoid abrupt steering wheel maneuvering and
braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the
brakes, causing death or serious injury.
 The warning system may not activate
immediately if bursts or sudden air leakage
should occur.
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place − well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission
in ”P”.
4. Have everyone get out of the vehicle on the side away
from traffic.

IN CASE OF AN EMERGENCY
470
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
 Follow jacking instructions.
 Do not put any part of your body under a vehicle
supported by a jack. Otherwise, personal injury
may occur.
 Do not start or run the engine while your vehicle
is supported by the jack.
 Stop the vehicle on a level firm ground, firmly
set the parking brake and put the transmission
in ”P”. Block the wheel diagonally opposite to
the one being changed if necessary.
 Make sure to set the jack properly in the jack
point. Raising the vehicle with jack improperly
positioned will damage the vehicle or may allow
the vehicle to fall off the jack and cause
personal injury.
 Never get under the vehicle when the vehicle is
supported by the jack alone.
Use the jack only for lifting your vehicle during
wheel changing.
 Do not raise the vehicle with someone in the
vehicle.
 When raising the vehicle, do not put an object
on or under the jack.
 Raise the vehicle only high enough to remove
and change the tire.
NOTICE
Do not use liquid sealants for a flat tire as tire
pressure sensors will be damaged.
 Do not continue driving with a deflated tire.
Driving even a short distance can damage a tire
beyond repair.
 When the tires must be repaired or replaced,
have them repaired or replaced by the nearest
Lexus dealer or authorized tire dealer. The tire
pressure sensors will be affected by the
installation or removal of tires.
 When the tires must be replaced, replace the
grommets for tire pressure sensors as well.

IN CASE OF AN EMERGENCY
471
Compact spare tire
G40025
The compact spare tire is designed for temporary
emergency use only.
The compact spare tire is identified by the distinctive
wording “TEMPORARY USE ONLY” molded into the
side wall of the tire.
To keep the compact spare tire noticeable, do not hide
the wheel by a wheel cover or such.
The compact spare tire saves space in your luggage
compartment, and its lighter weight helps to improve fuel
economy and permits easier installation in case of a flat
tire. The compact spare tire is not equipped with the tire
pressure sensor
. If tire inflation pressure becomes low,
the tire pressure warning system will not be activated.
Also, if you replace the compact spare tire after the low
tire pressure warning light comes on, the light remains
on.
The compact spare tire can be used many times, if
necessary. It has tread life of up to 4800 km (3000 miles)
depending on road conditions and your driving habits.
When tread wear indicators appear on the tire, replace
the tire. (See “Checking and replacing tires” on page
554.)

IN CASE OF AN EMERGENCY
472
CAUTION
The compact spare tire was designed especially
for your Lexus. Do not use it on any other
vehicle.
 Do not use more than one compact spare tire at
the same time.
 The pressure for the compact spare tire must be
420 kPa (4.3 kgf/cm
2, 4.2 bar, 60 psi).
 Do not exceed 80 km/h (50 mph) when driving
with the compact spare tire.
 Replace the compact spare tire with the
standard tire as soon as possible.
 Avoid sudden acceleration, sudden
deceleration and sharp turns with the compact
spare tire.
NOTICE
Your ground clearance is reduced when the
compact spare tire is installed so avoid driving
over obstacles and drive slowly on rough,
unpaved roads and speed bumps. Also, do not
attempt to go through an automatic car wash as
the vehicle may get caught, resulting in damage.

IN CASE OF AN EMERGENCY
473
Access to spare tire
G40003
1. Pull up the deck board.
G40004
2. Lift up the back side of the board and secure the
board by hooking the lever at the top of the trunk lid
opening as shown.
Make sure the board is secured and does not fall down.

IN CASE OF AN EMERGENCY
474
G40005
When closing the board, replace the hook also in its
original position as shown.
NOTICE
If you close the trunk lid with the board hooked,
the hook may be damaged.
G40023
 1Wrench
2Towing eyelet (for emergency towing)
3Jack handle
4Screwdriver
5Spare tire
6Wrenches
7Pliers
8Jack
3. Get the jack, wrench and spare tire.
To prepare yourself for an emergency, you should
familiarize yourself with the use of the jack and each tool,
and their storage locations.

IN CASE OF AN EMERGENCY
475
G40006
 1 Joint
2 When removing the jack, turn the joint by hand inthe ”contract” direction until the jack is free.
3 When storing, turn the joint by hand in the”expand” direction until the jack is firmly secured
to prevent it from flying forward during a collision
or sudden braking.
G40024
To remove the spare tire:
1Remove the luggage tray.
2Loosen the bolt and remove it.
When storing the spare tire, place it with the outer side
of the wheel facing up. Then bolt the tire in place and
install the luggage tool box to prevent the tire from flying
forward during a collision or sudden braking.
