2005 LEXUS ES300 Repair Manual

A78671
SST (B)
Magnetic Finger
EM0494
EXAMPLE (Intake):
Measured valve clearance = 0.45 mm (0.0177 in.)
0.45 mm (0.0177 in.) - 0.20 mm (0.0079 in.) = 0.25 mm (0.0098 in.)
(Measured - Specification = Excess clearance)
Used shim measurement = 2.80 mm (0.1102 in.)
0.25 mm (0.0098 in.) + 2.80 mm (0.1102 in.) = 3.05 mm (0.1201 in.)
(Excess clearance + Used shim = Ideal new shim)
Closest new shim = 3.05 mm (0.1201 in.)
Select No. 12 shim
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-73
2165 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(d) Using a small screwdriver and magnetic finger, remove
the adjusting shim.
(e) Using a micrometer, measure the thickness of the re-
moved shim.
(f) Calculate the thickness of a new shim so that the valve
clearance comes within the specified value.
AThickness of new shim
BThickness of used shim
CMeasured valve clearance
Specified value (Cold):
Intake A = B + (C - 0.20 mm (0.0079 in.))
Exhaust A = B + (C - 0.30 mm (0.0118 in.))
(g) Select a new shim with a thickness which is as close to the
calculated values as possible.
HINT:

Shims are available in 17 sizes in increments of 0.05 mm
(0.0020 in.), from 2.50 mm (0.0984 in.) to 3.30 mm
(0.1299 in.).

Refer to New Shim Thickness table on the next 2 pages.

V00719
Adjusting Shim Selection Chart (Intake)
Intake valve clearance (Cold):
0.15 to 0.25 mm (0.0059 to 0.0098 in.)
EXAMPLE: The 2.800 mm (0.1102 in.) shim is installed, and
the measured clearance is 0.450 mm (0.0177 in.).
Replace the 2.800 mm (0.1102 in.) shim with a new No. 12
shim.New Shim Thickness mm (in.)
HINT: New shims have the thickness in millimeters
imprinted on the face.Thickness
Thickness Shim
No. Shim
No.
Installed Shim Thickness
Measured Clearance
mm (in.)mm (in.)
14-74
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2166 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)

V00720
Adjusting Shim Selection Chart (Exhaust)
Exhaust valve clearance (Cold):
0.25 to 0.35 mm (0.0098 to 0.0138 in.)
EXAMPLE: The 2.800 mm (0.1102 in.) shim is installed, and
the measured clearance is 0.450 mm (0.0177 in.).
Replace the 2.800 mm (0.1102 in.) shim with a new No. 10
shim.New Shim Thickness mm (in.)
ThicknessThickness Shim
No. Shim
No.
HINT: New shims have the thickness in millimeters
imprinted on the face.
Installed Shim Thickness
Measured Clearance
mm (in.)mm (in.)
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
14-75
2167 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)

A78672
SST (B)
SST (A)
A78673
: Seal Packing
Front
A78674
: Seal Packing
Front 14-76
- ENGINE MECHANICALPARTIAL ENGINE ASSY (3MZ-FE)
2168 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(h) Place a new adjusting shim on the valve lifter with the im-
printed number facing down.
(i) Press down the valve lifter with SST (A), then remove SST
(B).
SST 09248-55040 (09248-05410, 09248-05420)
(j) Recheck the valve clearance.
101. INSTALL CYLINDER HEAD COVER SUB-ASSY
(a) Install the gasket to the cylinder head cover.
(b) Apply seal packing to the cylinder head as shown in the
illustration.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:

Remove any oil from the contact surface.

Install the cylinder head cover within 3 minutes after
applying seal packing.

Do not start the engine within 2 hours after installing.
(c) Install the cylinder head cover with the 9 bolts. Tighten the
bolts uniformly in several steps.
Torque: 8.0 NVm (80 kgfVcm, 71 in.Vlbf)
102. INSTALL CYLINDER HEAD COVER SUB-ASSY LH
(a) Install the gasket to the cylinder head cover.
(b) Apply seal packing to the cylinder head as shown in the
illustration.
Seal packing: Part No. 08826-00080 or equivalent
NOTICE:

Remove any oil from the contact surface.

Install the cylinder head cover within 3 minutes after
applying seal packing.

Do not start the engine within 2 hours after installing.
(c) Install the cylinder head cover with the 9 bolts. Tighten the
bolts uniformly in several steps.
Torque: 8.0 NVm (80 kgfVcm, 71 in.Vlbf)
103. INSTALL SPARK PLUG
Torque: 25 NVm (250 kgfVcm, 18 ftVlbf)

141JA-01
A84916
64 (653, 47)
64 (653, 47)
Front Fender Apron
Seal RH
Vane Pump V Belt
V Belt No. 1
Generator Bracket No. 2
Engine Mounting Stay No. 2 RHEngine Moving Control Rod
N´m (kgf´cm, ft´lbf)
: Specified torque
23 (235, 17)
58 (591, 43)
28 (286, 21)
Radio Setting Condenser
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
14-77
2169 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
TIMING BELT (3MZ-FE)
COMPONENTS

A78353
N´m (kgf´cm, ft´lbf)
: Specified torque
8.5 (87, 75 in.Vlbf)
220 (2,250, 162)8.5 (87, 75 in.Vlbf)
28 (286, 21)
27 (280, 20)
Timing Belt Tensioner AssyCrankshaft PulleyTiming Belt No. 1 Cover
Timing Belt Guide No. 2
Engine Mounting Bracket RH Timing Belt No. 2 Cover
Timing Belt
Engine Wire
Protector
14-78
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
2170 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)

141JB-01
A78546
A52344
P18816
A78755
SST
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
14-79
2171 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
REPLACEMENT
1. REMOVE FRONT WHEEL RH
2. REMOVE FRONT FENDER APRON SEAL RH
3. REMOVE V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See page 14-5)
4. REMOVE VANE PUMP V BELT (See page 14-5)
5. REMOVE ENGINE MOVING CONTROL ROD
(a) Remove the reserve tank cap.
(b) Remove the 4 bolts, engine moving control rod and brack-
et.
6. REMOVE ENGINE MOUNTING STAY NO.2 RH
(a) Remove the bolt, engine mounting stay No. 2 and engine
mounting bracket No. 2.
7. REMOVE GENERATOR BRACKET NO.2
(a) Remove the nut and generator bracket.
8. REMOVE CRANKSHAFT PULLEY
(a) Using SST, loosen the pulley bolt.
SST 09213-54015 (91651-60855), 09330-00021

A78756
SST
A78759
Clamp
Clamp
P18814
A78326
Turn 14-80
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
2172 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using SST and the pulley bolt, remove the pulley.
SST 09950- 50013 (09951- 05010, 09952- 05010,
09953-05020, 09954-05031)
NOTICE:
Before using SST, apply lubricating oil to the threads and
tip of the center bolt 150.
9. REMOVE TIMING BELT NO.1 COVER
10. REMOVE TIMING BELT NO.2 COVER
(a) Disconnect the 2 engine wire protector clamps from the
timing belt No. 3 cover.
(b) Remove the 5 bolts and timing belt cover.
11. REMOVE ENGINE MOUNTING BRACKET RH
(a) Remove the 2 bolts, nut and engine mounting bracket
RH.
12. REMOVE TIMING BELT GUIDE NO.2
13. REMOVE TIMING BELT
(a) Set the No. 1 cylinder to the TDC/compression.
(1) Temporarily install the crankshaft pulley bolt and
washer to the crankshaft.
(2) Turn the crankshaft clockwise, then align the timing
mark of the crankshaft timing pulley with the oil
pump body.
