2005 LEXUS ES300 Repair Manual

3305K-02
C90471
C90462F41690
- PARKING BRAKEPARKING BRAKE CABLE ASSY NO.3
33-1 1
2507 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
PARKING BRAKE CABLE ASSY NO.3
REPLACEMENT
HINT:

COMPONENTS: See page 33-3

For parking brake cable No.2, employ the same procedure to the RH side.
1. REMOVE REAR WHEEL
2. REMOVE REAR DISC BRAKE CALIPER ASSY LH
(a) Remove the 2 bolts and separate the rear disc brake caliper assy LH.
HINT:
Do not the flexible hose from the brake caliper assy LH.
3. REMOVE REAR DISC(See page 33-16)
4. REMOVE PARKING BRAKE SHOE RETURN TENSION SPRING(See page 33-16)
5. REMOVE PARKING BRAKE SHOE STRUT COMPRESSION SPRING(See page 33-16)
6. REMOVE PARKING BRAKE SHOE STRUT LH(See page 33-16)
7. REMOVE PARKING BRAKE SHOE(See page 33-16)
8. REMOVE PARKING BRAKE CABLE HEAT INSULATOR
(a) Remove the 3 nuts and parking brake heat insulator.
9. REMOVE PARKING BRAKE CABLE ASSY NO.3
(a) Remove the 2 bolts and disconnect the parking brake
cable assy No.3 from the backing plate.
(b) Remove the 2 nuts, bolt and parking brake cable assy
No.3.

C90462F41690
C90471
33-12
- PARKING BRAKEPARKING BRAKE CABLE ASSY NO.3
2508 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Disconnect the parking brake cable assy No.3 from the
parking brake equalizer.
10. INSTALL PARKING BRAKE CABLE ASSY NO.3
(a) Connect the parking brake cable assy No.3 to the parking
brake equalizer.
(b) Install the parking brake cable assy No.3 with the 2 nuts
and bolt.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
(c) Install the parking brake cable assy No.3 with the 2 bolts
to the backing plate.
Torque: 7.8 NVm (80 kgfVcm, 69 in.Vlbf)
11. INSTALL PARKING BRAKE CABLE HEAT INSULATOR
(a) Install the parking brake heat insulator with the 3 nuts.
Torque: 5.4 NVm (55 kgfVcm, 48 kgfVcm)
12. APPLICATION HIGH TEMPERATURE GREASE(See page 33-16)
13. INSTALL PARKING BRAKE SHOE(See page 33-16)

- PARKING BRAKEPARKING BRAKE CABLE ASSY NO.3
33-13
2509 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
14. INSTALL PARKING BRAKE SHOE STRUT LH(See page 33-16)
15. INSTALL PARKING BRAKE SHOE STRUT COMPRESSION SPRING(See page 33-16)
16. INSTALL PARKING BRAKE SHOE RETURN TENSION SPRING(See page 33-16)
17. CHECK PARKING BRAKE INSTALLATION(See page 33-16)
18. INSTALL REAR DISC(See page 33-16)
19. ADJUST PARKING BRAKE SHOE CLEARANCE(See page 33-16)
20. INSTALL REAR DISC BRAKE CALIPER ASSY LH
(a) Install the rear disc brake caliper with the 2 bolts.
Torque: 47 NVm (480 kgfVcm, 35 ftVlbf)
21. INSTALL REAR WHEEL
Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)
22. INSPECT AND ADJUST PARKING BRAKE PEDAL TRAVEL(See page 33-2)

3305L-02
C90470
Turn
Buckle
C90464
C90464
33-14
- PARKING BRAKEPARKING BRAKE CABLE ASSY NO.4
2510 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
PARKING BRAKE CABLE ASSY NO.4
REPLACEMENT
HINT:
COMPONENTS: See page 71-8 and 33-3
1. REMOVE CONSOLE PANEL UPPER REAR(See page 71-1 1)
2. REMOVE CONSOLE BOX CARPET
3. REMOVE RR CONSOLE BOX(See page 71-1 1)
4. REMOVE CONSOLE BOX MOUNTING BRACKET NO.2
(a) Remove the 2 bolts and console box mounting bracket No.2.
5. REMOVE YAWRATE SENSOR (W/ VSC)(See page 32-59)
6. REMOVE PARKING BRAKE CABLE ASSY NO.4
(a) Loosen the turn buckle, disconnect the parking brake
cable assy No.4 from the parking brake cable assy No.1.
(b) Disconnect the parking brake cable assy No.4 from the
parking brake equalizer.
(c) Remove the 2 bolts and parking brake cable assy No.4.
7. INSTALL PARKING BRAKE CABLE ASSY NO.4
(a) Install the parking brake cable No.4 with the 2 bolts.
Torque: 12.5 NVm (128 kgfVcm, 9 ftVlbf)
(b) Connect the parking brake cable assy No.4 to the parking
brake equalizer.

C90470
Turn
Buckle
- PARKING BRAKEPARKING BRAKE CABLE ASSY NO.4
33-15
2511 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Tighten the turn buckle, connect the parking brake cable
assy No.4 to the parking brake cable assy No.1.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
8. INSTALL YAWRATE SENSOR (W/ VSC)(See page 32-59)
9. INSTALL CONSOLE BOX MOUNTING BRACKET NO.2
(a) Install the console box mounting bracket No.2 with the 2 bolts.
Torque: 12.5 NVm (128 kgfVcm, 9 ftVlbf)
10. INSTALL RR CONSOLE BOX
11. INSTALL CONSOLE BOX CARPET
12. INSTALL CONSOLE PANEL UPPER REAR
13. INSPECT AND ADJUST PARKING BRAKE PEDAL TRAVEL
14. CHECK VSC SENSOR SIGNAL (W/ VSC)(See page 05-471)

3305M-03
C64523
Contract
F06409
F40318
33-16
- PARKING BRAKEPARKING BRAKE ASSY
2512 Author
: Date
:
PARKING BRAKE ASSY
OVERHAUL
HINT:

COMPONENTS: See page 33-3

Overhaul the RH side by the same procedures with LH side.
1. REMOVE REAR WHEEL
2. REMOVE REAR DISC BRAKE CALIPER ASSY LH
(a) Remove the 2 bolts and separate the rear disc brake caliper assy LH.
HINT:
Do not disconnect the flexible hose from the brake caliper.
3. REMOVE REAR DISC
(a) Release the parking brake, and remove the rear disc.
HINT:

Put matchmarks on the disc and the axle hub.

If the disc cannot be removed easily, turn the shoe adjust-
er until the wheel turns freely.
4. INSPECT BRAKE DISC INSIDE DIAMETER
(a) Using a brake drum gauge or equivalent, measure the in-
side diameter of the disc.
Standard inside diameter: 170 mm (6.69 in.)
Maximum inside diameter: 171 mm (6.73 in.)
5. REMOVE PARKING BRAKE SHOE RETURN TENSION
SPRING
(a) Using a needle-nose pliers, remove the 2 return tension
springs.
6. REMOVE PARKING BRAKE SHOE STRUT COMPRESSION SPRING
(a) Slide out the front shoe and remove the compression spring.
7. REMOVE PARKING BRAKE SHOE STRUT LH

F40319
F40320
BR5332
BR0828
- PARKING BRAKEPARKING BRAKE ASSY
33-17
2513 Author
: Date
:
8. REMOVE PARKING BRAKE SHOE
(a) Release the cup claw and remove the front and rear park-
ing brake shoe.
(b) Disconnect the parking brake cable from the shoe lever.
(c) Remove the tension spring and shoe adjuster screw set
from the front and rear shoe.
(d) Remove the 2 shoe hold-down springs, 4 cups and 2
pins.
(e) Using a screwdriver, remove the C-washer.
(f) Remove the shim and shoe lever from the parking brake
shoe.
9. INSPECT PARKING BRAKE SHOE LINING
THICKNESS
(a) Using a ruler, measure the thickness of the shoe lining.
Standard thickness: 2.0 mm (0.079 in.)
Minimum thickness: 1.0 mm (0.039 in.)
If the lining thickness is at the minimum thickness or less, or if
there is severe, uneven wear, replace the brake shoe.
10. INSPECT BRAKE DISC AND PARKING BRAKE SHOE
LINING FOR PROPER CONTACT
(a) Apply chalk to the inside surface of the disc, then grind
down the brake shoe lining to fit.
If the contact between the brake disc and the shoe lining is im-
proper, repair it using a brake shoe grinder or replace the brake
shoe assembly.
11. APPLICATION HIGH TEMPERATURE GREASE
(a) Apply the high temperature grease to the shoe attached surface of backing plate.

R00343
C80705
F40318
33-18
- PARKING BRAKEPARKING BRAKE ASSY
2514 Author
: Date
:
12. INSTALL PARKING BRAKE SHOE
(a) Install the shoe lever and shim to the rear shoe with a new
C-washer .
(b) Using a feeler gauge, measure the clearance.
Standard clearance: Less than 0.35 mm (0.0138 in.)
If the clearance is not within the specification, replace the shim
with one of the correct size.
Shim ThicknessShim Thickness
0.3 mm (0.012 in.)0.9 mm (0.035 in.)
0.6 mm (0.024 in.)-
(c) Apply the high temperature grease to the adjusting bolt.
(d) Install the shoe adjusting screw set and tension spring to
the front and rear shoe.
(e) Install the 2 pins, 4 cups and 2 shoe hold-down springs.
(f) Connect the parking brake cable to the shoe lever.
(g) Install the front and rear parking brake shoe.
13. INSTALL PARKING BRAKE SHOE STRUT LH
14. INSTALL PARKING BRAKE SHOE STRUT COMPRESSION SPRING
15. INSTALL PARKING BRAKE SHOE RETURN TENSION
SPRING
(a) Using a needle nose pliers, install the 2 return tension
springs.
