2005 LEXUS ES300 Repair Manual

RESET MEMORY FUNCTION ± TC002-03 Revised May 5, 2003
Page 3 of 3
1. Disconnect the negative battery cable for 5 minutes.
2. Reconnect battery cable.
3. Start the engine and warm it up to normal operating temperatures before test±driving.
4. Perform a thorough test drive with several accelerations from a stop with ªlight
throttleº application until proper transmission shifting is verified.Reset
Procedure 2

Lexus Supports ASE CertificationPage 1 of 6
Title:
ECM CALIBRATION: SHIFT FEELING
ENHANCEMENT
Models:
'02 ± '03 ES 300 & '04 ± '05 ES 330
Technical Service
Information Bulletin
August 4, 2003
TC004-03
REVISION NOTICE:
April 1, 2005: 2004 ± 2005 model year ES 330 vehicles have been added to
Applicable Vehicles. Introduction and Note have been updated on page 1.
Calibration Identification Chart has been updated to include ES 330 calibration IDs.
August 6, 2003: There has been a change in Warranty Time.
Previous versions of this TSIB should be discarded.
To improve the transmission shift feeling during specific operating modes, the Engine
Control Module (SAE term: Powertrain Control Module/PCM) calibration has been
revised. These improvements include:
Reduced downshift lag when accelerating at speeds from 10 to 20 mph.
Less gear hunting when driving on/off accelerator pedal at 20 to 30 mph
(for example: during heavy rush±hour traffic).
Improved response rate during heavy acceleration from a stop.
NOTE:
Version 12.01a or later Diagnostic Tester software is required to perform
this procedure.
Before proceeding, verify the ECM (PCM) calibration has NOT been updated by
checking for the Authorized Modifications Label (shown in step 1 of the
Repair Procedure).
Harsh ATM shifting may result if any Repair Procedure steps are omitted
(specifically steps 2 and 4 of ªFlash Reprogram ECMº on page 6).
2002 ± 2003 model year ES 300 vehicles.
2004 ± 2005 model year ES 330 vehicles.
OP CODEDESCRIPTIONTIMEOFPT1T2
EG5017Recalibrate ECM Engine & Transmission0.9
89666±3325#
89666±3344#
89661±33B3#
89661±33A4#
2699
Applicable Warranty*:
This repair is covered under the Lexus Federal Emissions Warranty. This warranty is
in effect for 96 months or 80,000 miles, whichever occurs first, from the vehicle's
in-service date.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
TRANSMISSION & CLUTCH
Introduction
Applicable
Vehicles
Warranty
Information

ECM CALIBRATION: SHIFTING ENHANCEMENT ± TC004-03 Revised August 4, 2003
Page 2 of 6
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAMEQTY
N/A00451±00001±LBLAuthorized Modifications Label1
NOTE:
Authorized Modification Labels may be ordered in packages of 25 from the Materials
Distribution Center (MDC) through Dealer Daily Dealer Support Materials System or by
calling the MDC at 1±800±622±2033.
SPECIAL SERVICE TOOLS (SSTs)PART NUMBERQTYDRW**
CAN Interface Module Kit*0100274418
Lexus Diagnostic Tester Kit*0100127018
12 Megabyte Diagnostic Tester Program Card
with version 12.01a Software (or later)*01002593-005
(Component of 01001270)1
* Essential SSTs.
** Refers to drawer number in SST Storage System.
NOTE:
Additional Diagnostic Tester Kits, CAN Interface Modules, Program Cards, or other
SSTs may be ordered by calling SPX/OTC at 1-800-933-8335. Parts
Information
Required
SSTs

ECM CALIBRATION: SHIFTING ENHANCEMENT ± TC004-03 Revised August 4, 2003
Page 3 of 6
MODELECM (CPU)PREVIOUS CALIBRATION IDNEW CALIBRATION ID
2002 ± 2003
Main
33323000
33323100
33323200
33341000
33341100
33341200
33341300
33341400
33387000
2002 2003
ES 300
Sub
53314000
53314100
53314200
53328000
53328100
53328200
53328300
53328400
53343000
2004 ± 2005
ES 330Main
33350000
33350100
33360000
33360100
33360200
ES 330
Sub53334000
5334000053340100
NOTE:
2004 model year ES 330 vehicles, which have been flash reprogrammed using the
procedures in this TSIB, will contain upgraded 2005 model year OBD II logic and will
require VIN input. Refer to the 2005 model year ES 330 Repair Manual information on
the Technical Information System (TIS) when checking Powertrain Diagnostic Trouble
Codes (DTCs) on 2004 model year ES 330 vehicles that have been reprogrammed.
2002 model year ES 300 vehicles, which have been flash reprogrammed using the
procedures in this TSIB, will contain upgraded 2003 model year OBD II logic. Refer to
the 2003 model year ES 300 Repair Manual information on the Technical Information
System (TIS) when checking Powertrain Diagnostic Trouble Codes (DTCs) on 2002
model year ES 300 vehicles that have been reprogrammed. Calibration
Identification
Chart

ECM CALIBRATION: SHIFTING ENHANCEMENT ± TC004-03 Revised August 4, 2003
Page 4 of 6
1. Check for the Authorized Modifications Label affixed to the vehicle in the location
shown in Figure 1. Confirm if ECM (PCM) calibration has been updated. If not the
latest ECM (PCM) calibration Ð go to step 2.
THESE MODIFICATIONS HAVE BEEN APPROVED
AS APPROPRIATE BY EPA AND CARB
DATE:DEALER CODE:
CHANGE AUTHORITY:TSIB TC004±03 33387000, 5334300089666±33441
Replacement
ECM (PCM)
Part
Number
Calibration
ID(s)
TSIB NumberDate
Completed
Dealer Code
THE FOLLOWING MODIFICATIONS HAVE BEEN MADE:
Figure 1. Location of Authorized Modifications Label on 2002 and 2003 ES 300
Repair
Procedure

ECM CALIBRATION: SHIFTING ENHANCEMENT ± TC004-03 Revised August 4, 2003
Page 5 of 6
2. Connect the Diagnostic Tester to the vehicle and select CURRENT ECU CAL from
the ECU REPROGRAM MAIN MENU. Determine the vehicle's current ECU
calibration (see Figure 2).
± The sample screen prints seen below are the 12.01a software version and may
differ from subsequent software versions.
Figure 2. Determining Current ECU Calibration
ECU REPROGRAM
MAIN MENU
1: GET CAL FROM PC
2: CURRENT ECU CAL
3: UPDATE ECU CAL
4: CAL ON TESTER
5: CLEAR CAL DATA
A
CURRENT ECU CAL
B
CALIBRATION ID
33341300
53328300
NOTE:
If Calibration ID matches ªPrevious Calibration IDº as shown in Calibration
Identification Chart on page 3, proceed with flash reprogramming.
If Calibration ID matches ªNew Calibration IDº as shown in Calibration Identification
Chart, this vehicle has already been programmed. Refer to TIS for diagnostic
procedures applicable to any stored DTCs.
3. If ECU calibration ID is not the same as the ªNew Calibration IDº listed previously,
proceed to Flash Reprogram ECM (PCM).
4. Flash Reprogram ECM (PCM)
Follow the procedures outlined in Lexus TSIB No. SS001±01,
ªECU Flash
Reprogramming Process,º
and flash the ECM (PCM) with the new calibration
file update.
NOTE:
If the ªCheck Engineº light is ON when the ignition is turned back on to begin the
reprogramming process, a scan tool cable problem exists. Refer to TSIB No.
SS001±01,
ªECU Flash Reprogramming Process.º
Repair
Procedure
(Continued)

ECM CALIBRATION: SHIFTING ENHANCEMENT ± TC004-03 Revised August 4, 2003
Page 6 of 6
5.Reset the ECM (PCM) learned values using the diagnostic tester. Refer to the
procedures below.
± The sample screen prints seen below are the 12.01a software version and may
differ from subsequent software versions.
NOTE:
Failure to reset the ECM (PCM) memory will result in continued ATM shifting complaints.
DO YOU WISH TO
RESET THE ECM?
[YES] to CONTINUE
[NO] to EXIT
2: CUSTOMIZE
3: ECU REPROGRAMFUNCTION SELECT FOR
NORTH AMERICA
B
*APPLICATION SELECT*
A
1: DIAGNOSISDIAGNOSTIC MENU
ENGINE
C
DO NOT USE THIS
FUNCTION UNLESS
INSTRUCTED BY
REPAIR MANUAL.RESET MEMORY
E
RESET MEMORY
NOTICE
D
[YES]
F
1: OBD/MOBD
3: CARB OBD II
4: BREAK±OUT BOX
5: NVH
6: AUTOPROBE
7: 02 RPM CHECK
8: SNAPSHOT REVIEW
9: SETUP
0: GAS ANALYSIS2: ENHANCED OBD II1: DATA LIST
2: DTC INFO
3: ACTIVE TEST
4: SNAPSHOT
5: SYSTEM CHECK
6: RESET MEMORY
7: MONITOR STATUS
8: CHECK MODE
6: RESET MEMORY
ONLY USE AFTER
REPLACING THE ENGINE,
AUTO TRANS, OR ECM
ON CERTAIN VEHICLES.EXECUTING THIS
FUNCTION WILL RESET
THE LEARNED VALUES
IN THE ECM.RESET MEMORY
RESETTING COMPLETE
PRESS
[ENTER]
Figure 3. ECM (PCM) Learned Values Reset
6. Follow the procedures outlined in TSIB No. EG012±04, ªEntering VIN During ECM
(PCM) Replacement and/or DTC P0630,º
and write the VIN to the ECM (PCM).
7. Start the engine and warm it up to normal operating temperature before test±driving.
8. Test drive vehicle to confirm proper vehicle operation.
9. Enter the required information on the Authorized Modifications Label and affix it to the
vehicle at the location shown in Figure 1 (page 4). The Authorized Modifications
Label is available through the MDC, P/N 00451±00001±LBL.
10. Calibration update is complete.
NOTE:
Select premium unleaded gasoline with an Octane Rating of 91 (Research Octane
Number 96) or higher for optimum engine performance.
The effect of the new calibration may become more apparent after several days
of driving as the ECM (PCM) ºlearned valuesº are re±established from the
customer 's driving. Repair
Procedure
(Continued)

28009-17
R03031
F13676
Front (A) (B)
C80976
- TIRE & WHEELWHEEL AND TIRE SYSTEM
28-1
2402 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
WHEEL AND TIRE SYSTEM
INSPECTION
1. INSPECT TIRE
(a) Check the tires for wear and proper inflation pressure.
Cold tire inflation pressure:
Tire sizeFront, Rear
kPa (kgf/cm2, psi)
P215/60R16 94V200 (2.0, 29)
P215/55R17 93V210 (2.1, 30)
(b) Using a dial indicator, check the tire runout.
Tire runout: 1.0 mm (0.039 in.) or less
2. ROTATE TIRES
HINT:

Rotate tires as shown in illustration (A) if a spare tire is not
included in the rotation.

Rotate tires as shown in illuatration (B) if a spare tire is in-
cluded in the rotation.
3. INSPECT WHEEL BALANCE
(a) Check and adjust the Off-the-car balance.
(b) If necessary, check and adjust the On-the-car balance.
Imbalance after adjustment: 8.0 g (0.018 lb) or less
4. INSPECT BEARING LOOSENESS (SEE PAGE 30-2)
5. INSPECT AXLE HUB RUNOUT (SEE PAGE 30-2)
