2005 LEXUS ES300 Repair Manual

F45683
F40999
C86250
From M/C 2nd
To FL W/CFrom M/C 1st
To RR W/C
To RL W/CTo FR W/C
32-52
- BRAKEBRAKE ACTUATOR ASSY (W/VSC)(From July, 2003)
2486 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(d) Remove the 3 nuts and brake actuator with bracket.
3. REMOVE BRAKE ACTUATOR ASSY
(a) Remove the 2 nuts and brake actuator from the bracket.
4. INSTALL BRAKE ACTUATOR ASSY
(a) Install the brake actuator to the bracket with the 2 nuts.
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
5. INSTALL BRAKE ACTUATOR WITH BRACKET
(a) Install the brake actuator with the 3 nuts.
Torque: 19 NVm (194 kgfVcm, 14 ftVlbf)
(b) Connect the brake actuator connector.
(c) Using SST, connect the each brake line to the correct
position of brake actuator, as shown in the illustration.
SST 09023-00101
Torque: 15 NVm (155 kgfVcm, 11 ftVlbf)
6. FILL RESERVOIR WITH BRAKE FLUID
7. BLEED MASTER CYLINDER (SEE PAGE 32-4)
SST 09023-00101
8. BLEED BRAKE LINE (SEE PAGE 32-4)

- BRAKEBRAKE ACTUATOR ASSY (W/VSC)(From July, 2003)
32-53
2487 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
9. BLEED BRAKE ACTUATOR ASSY (W/ VSC) (SEE PAGE 32-4)
SST 09992-00242, 09992-00350
10. CHECK FLUID LEVEL IN RESERVOIR(SEE PAGE 32-4)
11. CHECK BRAKE FLUID LEAKAGE
12. CHECK OPERATION OF BRAKE ACTUATOR (SEE PAGE 32-47)

3203N-09
F41016
F41018F41017
C84803
32-54
- BRAKESPEED SENSOR FRONT LH
2488 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
SPEED SENSOR FRONT LH
REPLACEMENT
HINT:
Replace the RH side by the same procedures with LH side.
1. REMOVE FRONT WHEEL
2. REMOVE FRONT FENDER LINER LH
3. REMOVE SPEED SENSOR FRONT LH
(a) Disconnect the speed sensor connector and clamp.
(b) Remove the 2 clamp bolts holding the sensor harness
and clamp from the body and shock absorber.
(c) Remove the bolt and speed sensor FR LH.
NOTICE:
Do not stick and foreign matter on the sensor tip.

C84803
F41018F41017
A
B
F41016
- BRAKESPEED SENSOR FRONT LH
32-55
2489 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
4. INSTALL SPEED SENSOR FRONT LH
(a) Install the speed sensor FR LH with the bolt.
Torque: 8.0 NVm (82 kgfVcm, 71 in.Vlbf)
NOTICE:
Make sure the sensor tip is clean.
(b) Install the sensor harness clamps with the 2 bolts ºAº and
ºBº to the body and shock absorber.
Torque:
Bolt A: 5.0 NVm (51 kgfVcm, 44 in.Vlbf)
Bolt B: 18.8 NVm (192 kgfVcm, 14 ftVlbf)
(c) Connect the clamp to the knuckle.
(d) Connect the speed sensor connector and clamp.
5. INSTALL FRONT FENDER LINER LH
6. INSTALL FRONT WHEEL
Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)
7. CHECK ABS SPEED SENSOR SIGNAL (SEE PAGE 05-420 or 05-471)

3203O-06
F40301
C83035
32-56
- BRAKESKID CONTROL SENSOR
2490 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
SKID CONTROL SENSOR
REPLACEMENT
HINT:
Replace the RH side by the same procedure with LH side.
1. REMOVE REAR WHEEL
2. SEPARATE SKID CONTROL SENSOR WIRE
(a) Disconnect the connector from the skid control sensor.
3. REMOVE REAR DISC BRAKE CALIPER ASSY LH (SEE PAGE 32-41)
4. REMOVE REAR DISC
5. REMOVE REAR AXLE HUB & BEARING ASSY LH
(a) Remove the 4 bolts and rear axle hub & bearing assy.

F40303
SST
Bolt
SST
F40302
LHRH
F40304
SST
- BRAKESKID CONTROL SENSOR
32-57
2491 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
6. REMOVE SKID CONTROL SENSOR
(a) Mount the rear axle hub in a soft jaw vise.
NOTICE:
Replace the axle hub assembly if it is dropped or a strong
shock is given to it.
(b) Using a pin punch and hammer, drive out the 2 pins and
remove the 2 attachments from SST.
(c) Using SST and 2 bolts (Diameter: 12 mm, pitch: 1.5 mm),
remove the skid control sensor from the rear axle hub.
SST 09520- 00031 (09520- 00040), 09521- 00020,
09950-00020
NOTICE:

If a damage is inflicted to the sensor rotor, replace the
axle hub assembly.

Do not scratch the contacting surface of axle hub and
speed sensor.
7. INSTALL SKID CONTROL SENSOR
(a) Clean the contacting surface of the axle hub and a new
skid control sensor.
NOTICE:
Make sure the sensor rotor is clean.
(b) Place the speed sensor on the axle hub so that the con-
nector is positioned, as shown in the illustration.
(c) Using SST and a press, install the skid control sensor to
the axle hub.
NOTICE:

Do not tap the skid control sensor with a hammer di-
rectly.

Check that the skid control sensor detection part is
clean.

Press in the skid control sensor straight and slowly.
SST 09830- 36010, 09950- 60010 (09951- 00650),
09950-70010 (09951-07100)

C83035
32-58
- BRAKESKID CONTROL SENSOR
2492 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
8. INSTALL REAR AXLE HUB & BEARING ASSY LH
(a) Install the rear axle hub & bearing assy with the 4 bolts.
Torque: 80 NVm (816 kgfVcm, 59 ftVlbf)
9. INSTALL REAR DISC
10. INSTALL REAR DISC BRAKE CALIPER ASSY LH (SEE PAGE 32-41)
11. CONNECT SKID CONTROL SENSOR WIRE
12. INSTALL REAR WHEEL
Torque: 103 NVm (1,050 kgfVcm, 76 ftVlbf)
13. INSPECT TIRE (SEE PAGE 28-1)
14. MEASURE VEHICLE HEIGHT (SEE PAGE 27-3)
15. INSPECT SIDE SLIP (SEE PAGE 27-3)
16. INSPECT CAMBER (SEE PAGE 27-3)
17. INSPECT TOE-IN (SEE PAGE 27-3)
18. ADJUST CAMBER AND TOE-IN (SEE PAGE 27-3)
19. CHECK ABS SPEED SENSOR SIGNAL (SEE PAGE 05-420 or 05-471)

320E4-03
F45687
F45687
- BRAKEYAWRATE SENSOR (From July, 2003)
32-59
2493 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
YAWRATE SENSOR (From July, 2003)
REPLACEMENT
NOTICE:
Do not separate the sensor from the bracket.
1. REMOVE CONSOLE PANEL UPPER REAR (SEE PAGE 71-1 1)
2. REMOVE RR CONSOLE BOX (SEE PAGE71-1 1 )
3. REMOVE YAWRATE SENSOR
(a) Disconnect the yawrate sensor connector.
(b) Remove the 2 bolts and yawrate sensor.
4. INSTALL YAWRATE SENSOR
(a) Install the yawrate sensor with the 2 bolts.
Torque: 12.5 NVm (127 kgfVcm, 9 ftVlbf)
(b) Connect the yawrate sensor connector.
5. INSTALL RR CONSOLE BOX (SEE PAGE 71-1 1)
6. INSTALL CONSOLE PANEL UPPER REAR (SEE PAGE 71-1 1)
7. PERFORM YAWRATE SENSOR ZERO POINT CALIBRATION (SEE PAGE 05-471)
