A05052
A52840
A78327
Turn
Approximately 60
A78702
(5)
(6) (1)(4) (2)(3)
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
14-81
2173 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(3) Check that the timing marks of the camshaft timing
pulleys and the timing belt No. 3 cover are aligned.
If not, turn the crankshaft by 1 revolution (360).
(4) Remove the crankshaft pulley bolt.
(b) If reusing the timing belt, check that there are 3 installa-
tion marks on the timing belt as shown in the illustration.
(1) If the installation marks have disappeared, put new
installation marks on the timing belt before remov-
ing.
(c) Set the No. 1 cylinder to approximately 60 BTDC/com-
pression.
(1) Turn the crankshaft counterclockwise by approxi-
mately 60.
NOTICE:
If the timing belt is disengaged, having the crankshaft
pulley set at the wrong angle can cause contact of the pis-
ton head with the valve head when removing the camshaft
timing pulley and camshaft, which causes damage. So al-
ways set the crankshaft pulley at the correct angle.
(d) Remove the timing belt tensioner.
NOTICE:
Do not reinstall the tensioner with its plunger extended.
(e) Remove the timing belt in this order.
1stNo. 1 idler pulley
2ndRH camshaft timing pulley
3rdNo. 2 idler pulley
4thLH camshaft timing pulley
5thWater pump pulley
6thCrankshaft timing pulley

EM3336
14-82
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
2174 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
14. INSPECT TIMING BELT
NOTICE:

Do not bend, twist or turn the timing belt inside out.

Do not allow contact of the timing belt with oil, water
or steam.

Do not use the timing belt tension when installing or
removing the mounting bolt of the camshaft timing
pulley.
Check the belt for any defects as shown in the illustrations.
Also, check these points below.
(a) If the belt tears in a short time:

Check if the belt is installed properly.

Check if the timing cover gasket is damaged and if
it is installed properly.
(b) If the belt teeth are cracked or damaged, check if either
camshaft is locked.
(c) If there is noticeable wear or cracks on the belt face,
check if there are nicks on the side of the idler pulley lock
and water pump.
(d) If there is wear or damage on only one side of the belt,
check the belt guide and alignment of each pulley.
(e) If there is noticeable wear on the belt teeth:

Check the timing cover for damage.

Check that the gasket has been installed correctly.

Check for foreign objects on the pulley teeth.
If there is any doubt about the belt condition, replace the timing
belt.
15. INSTALL TIMING BELT
(a) Remove any oil or water on the pulleys, then keep them
clean.
NOTICE:

If there is a trace of water and/or oil on the timing belt,
repair the leakage and install a new timing belt.

Only wipe the pulleys; do not use any cleaning agent.
(b) Check the idler pulleys.
(1) Check that the idler pulley turns smoothly.
(2) Visually check the seal portion of the idler pulley for
oil leakage.
(c) Check the water pump.
(1) Turn the pulley, then check that water pump bearing
moves smoothly and does not make a noise.
(2) Visually check the drain hole for coolant leakage.
(d) Temporarily install the crankshaft pulley bolt and washer
to the crankshaft.

A82349
Turn
Approximately 60
A78751
SST
A05062
A52840
A78702(1) (2)
(3) (4)
(5)
(6)
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
14-83
2175 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(e) Turn the crankshaft counterclockwise by approximately
60.
NOTICE:
To prevent contact of the piston head with the valve head,
set the crankshaft pulley at the 60 BTDC/compression
position.
(f) Using SST, turn the timing pulleys, then align the timing
marks of the timing pulleys with the timing belt No. 3 cover.
SST 09960-10010 (09962-01000, 09963-01000)
(g) Turn the crankshaft, then align the timing mark of the
crankshaft timing pulley with the oil pump body.
(h) Align the front mark on the timing belt so it faces forward.
(i) Align the installation mark on the timing belt with the tim-
ing mark of the crankshaft timing pulley.
(j) Align the installation marks on the timing belt with the tim-
ing marks of the camshaft timing pulleys.
(k) Install the timing belt in this order.
1stCrankshaft timing pulley
2ndWater pump pulley
3rdLH camshaft timing pulley
4thNo. 2 idler pulley
5thRH camshaft timing pulley
6thNo. 1 idler pulley

A36238
A78326
Turn
A05052
A36239
14-84
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
2176 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
16. INSTALL TIMING BELT TENSIONER ASSY
(a) Set the timing belt tensioner upright on the press.
(b) Slowly press in the push rod.
NOTICE:
Do not apply pressure more than 9.8 kN (1,000 kgf, 2,205
lbf) to the rod.
(c) Align the holes of the push rod and housing, then pass a
1.5 mm hexagon wrench through the holes to keep the
setting position of the push rod.
(d) Release the press.
(e) Temporarily install the tensioner with the 2 bolts. Alter-
nately tighten the 2 bolts.
Torque: 27 NVm (280 kgfVcm, 20 ftVlbf)
NOTICE:
Be sure to tighten the bolts uniformly. Installing the ten-
sioner at an angle may cause failure of its proper operation.
(f) Remove the 1.5 mm hexagon wrench from the tensioner.
(g) Turn the crankshaft 2 revolutions slowly, then align the
timing mark of the crankshaft timing pulley with the oil
pump body.
NOTICE:
Always turn the crankshaft clockwise.
(h) Check that the timing marks of the RH and LH timing pul-
leys are aligned with the timing marks of the timing belt
No. 3 cover as shown in the illustration.
If the marks are not aligned, remove the timing belt and reinstall
it.
(i) Remove the crankshaft pulley bolt.
17. INSTALL TIMING BELT GUIDE NO.2
(a) Install the timing belt guide with the cup side facing the en-
gine front.

P18814
A78760
SST
A52344
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
14-85
2177 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
18. INSTALL ENGINE MOUNTING BRACKET RH
(a) Install the engine mounting bracket RH with the 2 bolts
and nut.
Torque: 28 NVm (286 kgfVcm, 21 ftVlbf)
19. INSTALL TIMING BELT NO.2 COVER
(a) Visually check for cracks and breaks on the gasket of the timing belt cover.
If there is a trace of water intrusion when checking visually, replace the timing belt cover.
(b) Install the timing belt cover.
Torque: 8.5 NVm (87 kgfVcm, 75 in.Vlbf)
20. INSTALL TIMING BELT NO.1 COVER
(a) Visually check for cracks and breaks on the gasket of the timing belt cover.
If there is a trace of water intrusion when checking visually, replace the timing belt cover.
(b) Install the timing belt cover.
Torque: 8.5 NVm (87 kgfVcm, 75 in.Vlbf)
(c) Install the 2 engine wire protector clamps to the timing belt No. 3 cover.
21. INSTALL CRANKSHAFT PULLEY
(a) Align the keyway of the pulley with the key located on the
crankshaft, then slide the pulley into place.
(b) Using SST, install the pulley bolt.
SST 09213-54015 (91651-60855), 09330-00021
Torque: 220 NVm (2250 kgfVcm, 162 ftVlbf)
22. INSTALL GENERATOR BRACKET NO.2
Torque: 28 NVm (286 kgfVcm, 21 ftVlbf)
23. INSTALL ENGINE MOUNTING STAY NO.2 RH
(a) Install the engine mounting stay No. 2 and engine mount-
ing bracket No. 2 with the bolt.
Torque: 64 NVm (653 kgfVcm, 47 ftVlbf)

A78546
A
B
A
A 14-86
- ENGINE MECHANICALTIMING BELT (3MZ-FE)
2178 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
24. INSTALL ENGINE MOVING CONTROL ROD
(a) Install the engine moving control rod and bracket with the
4 bolts.
Torque:
64 NVm (653 kgfVcm, 47 ftVlbf) for bolt A
23 NVm (235 kgfVcm, 17 ftVlbf) for bolt B
25. INSTALL VANE PUMP V BELT (See page 14-5)
26. INSTALL V (COOLER COMPRESSOR TO CRANKSHAFT PULLEY) BELT NO.1
(See page 14-5)
27. INSPECT DRIVE BELT DEFLECTION AND TENSION (See page 14-1)
28. INSTALL FRONT WHEEL RH (See page 14-5)

141JC-01
A86358N´m (kgf´cm, ft´lbf) : Specified torque
7.9 (81, 70 in.Vlbf)x3
V-bank Cover Sub-assy
Mass Air Flow
Meter Connector Fuel Vapor Feed Hose
Assy
Vacuum Hose
Air Cleaner Cap
Sub-assy
Air Cleaner Filter
Element Sub-assy
5.0 (51, 44 in.Vlbf)
W/O TEMS:
Front Suspension Upper Brace Center
80 (816, 59)
Spacer
x2
Vacuum Hose
80 (816, 59)x2
Spacer
- ENGINE MECHANICALCAMSHAFT (RH BANK) (3MZ-FE)
14-87
2179 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
CAMSHAFT (RH BANK) (3MZ-FE)
COMPONENTS

A86260
Non-reusable part
: Specified torque VSV Connector
8.0 (82, 71 in.Vlbf)x2
Emission
Control Valve Set
Emission Control Valve Bracket
Intake Air Surge Tank

Air Surge Tank
to Intake Manifold
Gasket
Throttle Motor Connector
Water By-pass Hose No. 3
Water By-pass Hose No. 2
N´m (kgf´cm, ft´lbf)
Union to Check Valve Hose
Fuel Vapor Feed Hose
x2 x3
Engine Hunger No. 1Surge Tank Stay
No. 1
Surge Tank Stay
No. 2
20 (199, 14)
20 (199, 14)
20 (199, 14)
7.8 (80, 69 in.Vlbf)
x2
x2 Pressure Feed
Tube Assy
28 (286, 21)
x2
x2
Bond Cable No. 1
Connector
28 (286, 21)
