PRE±DELIVERY SERVICE (PDS) INFORMATION FOR ES 330 ± PD002-03 August 26, 2003
Page 4 of 9
FRONT LICENSE PLATE MOUNTING BRACKET INSTALLATION
The front license plate bracket and two self tapping screws are included in the
luggage compartment.
1. Aligning the holes ªAº of the mounting
bracket with the dimples on the front
bumper cover, mark the location of the
holes ªBº on the front bumper cover.
NOTE:
Holes ªAº are used for installation
of the mounting bracket to the
bumper cover.
Holes ªBº are used for installation
of the front license plate to the
mounting bracket.
2. Drill two relief holes with a diameter of
12 mm (0.47 in.) at the marks on the
front bumper cover to prevent the
license plate retaining bolt end from
contacting the cover.
NOTE:
Do not drill the dimples on the front
bumper cover.
3. Install the mounting bracket to the
front bumper cover using the two self
tapping screws.
Install the front license plate to the
mounting bracket using bolts of the
following dimensions:
Length: less than 25 mm (0.98 in.)
Diameter: 6.0 mm (0.24 in.)
Pitch: 1.0 mm (0.04 in.) ITEM NO. 3:
Introduction
Installation
Procedure
Mark And Drill Holes
Dimples
Mounting Bracket
AA B B
Tapping Screws
FRONT LICENSE PLATE MOUNTING BRACKET INSTALLATION ± PD036-05 August 25, 2005
Page 2 of 2
3. Install the mounting bracket to the
front bumper cover using the two
self-tapping screws.
4. Install the front license plate to the
mounting bracket using bolts of the
following dimensions:
Length: Less than 25 mm (0.98 in.)
Diameter: 6.0 mm (0.24 in.)
Pitch: 1.0 mm (0.04 in.) Installation
Procedure
(Continued)
Tapping Screws
