2005 LEXUS ES300 Repair Manual

FRONT LICENSE PLATE MOUNTING BRACKET INSTALLATION ± PD036-05 August 25, 2005
Page 2 of 2
3. Install the mounting bracket to the
front bumper cover using the two
self-tapping screws.
4. Install the front license plate to the
mounting bracket using bolts of the
following dimensions:
Length: Less than 25 mm (0.98 in.)
Diameter: 6.0 mm (0.24 in.)
Pitch: 1.0 mm (0.04 in.) Installation
Procedure
(Continued)
Tapping Screws

Lexus Supports ASE CertificationPage 1 of 2
Title:
FRONT EMERGENCY TOWING EYELET &
EYELET HOLE COVER
Models:
'05 ± '06 ES 330
Technical Service
Information Bulletin
August 26, 2005
PD037-05
The 2005 ± 2006 model year ES 330 is shipped with a front emergency towing eyelet.
Follow the procedure below to remove the eyelet and save for customer use.
2005 ± 2006 model year ES 330 vehicles.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
1. Remove the emergency towing
eyelet from the front bumper by
turning counterclockwise.
NOTE:
If it is hard to loosen the emergency
towing eyelet, use a steel bar.
PRE-DELIVERY SERVICE
Introduction
Applicable
Vehicles
Warranty
Information
Emergency Towing Eyelet
Installation
Procedure

FRONT EMERGENCY TOWING EYELET & EYELET HOLE COVER ± PD037-05 August 26, 2005
Page 2 of 2
2. Place the emergency towing
eyelet in the tool tray in the
luggage compartment.
3. Install the front towing eyelet hole
cover, which is stored in the glove
box, onto the front bumper as shown
in the illustration.Installation
Procedure
(Continued)

Lexus Supports ASE CertificationPage 1 of 1
Title:
VOLUME 4 INFORMATION
Models:
All Models
Technical Service
Information Bulletin
January 1, 1999
PG001±99
Lexus Technical Service Information Bulletins (TSIBs) continue to be one of the most
current sources of technical information available. To ensure complete access to this
reference source, use the following steps:
Volume Four will begin with 1999 Technical Service Information Bulletins.
Place this bulletin along with all 1999 TSIBs into the new binders received with this
bulletin.
Label this new binder ªVolume Fourª using the labels provided with the binder.
Additional copies of 1994 through 1999 TSIBs are available to all Lexus Dealerships
through the Non±Parts System (MDC NPM System) by using the following Part
Number designation:
00216EG00199
TSB Part Number Prefix
TSB Chapter Code
Chapter Code Sequence Number
Year
±±
MATERIAL DESCRIPTIONPART NUMBER
1999 TSIB Binder complete with all bulletins issued to dateVOL4
New TSIB Binder and tabs only00216±00001
PRODUCT GENERAL INFORMATION
Introduction
Related TSIB
Part Numbers

Lexus Supports ASE CertificationPage 1 of 2
Title:
REPLACEMENT CERTIFICATION LABELS
Models:
All Models
Technical Service
Information Bulletin
January 18, 2002
PG002-02
TSB UPDATE NOTICE:
The information contained in this TSIB updates PG015±01 dated May 4, 2001.
Revised text is red
and underlined. The changes will take place February 1, 2002.
Replacement Certification Labels (vinyl label affixed to driver's door or door post)
may be available from Lexus providing the request meets one of the criteria
listed below.
MFD.BY:TOYOTA MOTOR CORPORATION DATE 10/01
GVWR: 2247KG (3040LB)
GAWR: FRT 1379KG (3040LB) WITH P225/70R16 TIRES
16X6 1/2JJ RIMS AT 210 KPA (30PSI) COLD
RR 1153KG (2540LB) WITH P225/70R16 TIRES.
16X6 1/2JJ RIMS AT 210 KPA (30PSI) COLD
THIS VEHICLE CONFORMS TO ALL APPLICABLE
FEDERAL MOTOR VEHICLE SAFETY, BUMPER, AND
THEFT PREVENTION STANDARDS IN EFFECT ON
THE DATE OF MANUFACTURE SHOWN ABOVE.
JT0XX00X0X0000000 MPV MCU10L±AWPGKA
C/TR 8P4/LB00
A/TM ±01A/
U140E
MADE IN JAPAN
NO. 736
Certification Label Location
All Lexus vehicles.
1. The vehicle is in an accident and the label is damaged or is attached to a part that will
be replaced during the repair.
NOTE:
Processing a new label
will be delayed significantly if the original certification label
is not available.
A replacement label MAY NOT be available if the vehicle is more than 5 years old
and the old label does not accompany this request.
2. The label is stolen.
To request a replacement label, complete a copy of the form on the back of this bulletin.
Your dealer parts account will be billed $25.00
for each replacement of a damaged or
stolen label.
NOTE:
All replacement labels for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Certification
Label Criteria
Procurement
Procedure
Warranty
Information

DEALER CODE:
DEALER NAME:
ADDRESS:STREET
ADDRESS
CITY,
STATE,
ZIP
CODE
TELEPHONE:AREA
CODE,
TELEPHONE
NUMBER
CONTACT:FIRST
NAME,
LAST
NAME
REASON FOR REPLACEMENT
ACCIDENT DAMAGE
STOLEN
OTHER
REASON/EXPLANATION
PLEASE PROVIDE CORRECT VIN
APPLICATION FOR REPLACEMENT CERTIFICATION LABEL
ATTACH ORIGINAL LABEL HERE
DEALER INFORMATION
NOTE:
Original label MUST accompany this application or order will be significantly delayed.
MAIL (DO NOT FA X) THE COMPLETED REQUEST FORM WITH THE OLD LABEL TO:
TOYOTA MOTOR SALES, U.S.A. INC.
TECHNICAL COMPLIANCE DEPARTMENT, S207
19001 S. WESTERN AVENUE
TORRANCE, CA 90509±2991
( )
MFD.BY:TOYOTA MOTOR CORPORATION DATE 10/01
GVWR: 2247KG (3040LB)
GAWR: FRT 1379KG (3040LB) WITH P225/70R16 TIRES
16X6 1/2JJ RIMS AT 210 KPA (30PSI) COLD
RR 1153KG (2540LB) WITH P225/70R16 TIRES.
16X6 1/2JJ RIMS AT 210 KPA (30PSI) COLD
THIS VEHICLE CONFORMS TO ALL APPLICABLE
FEDERAL MOTOR VEHICLE SAFETY, BUMPER, AND
THEFT PREVENTION STANDARDS IN EFFECT ON
THE DATE OF MANUFACTURE SHOWN ABOVE.
JT0XX00X0X0000000 MPV MCU10L±AWPGKA
C/TR 8P4/LB00
A/TM ±01A/
U140E
MADE IN JAPAN
NO. 736

Lexus Supports ASE CertificationPage 1 of 1
Title:
TIRE POSITIONING BEFORE NEW
VEHICLE DELIVERY
Models:
'05 ± '06 All Lexus
Technical Service
Information Bulletin
March 2, 2005
PG002-05
During the manufacturing process, tire characteristics are measured. Tires are then
mounted on the vehicle as matched sets to help reduce conditions such as pulling or
drifting. If the wheels are replaced or refinished before vehicle delivery, it is important
that the tires remain on the vehicle in the same location and in the same direction
of rotation.
Please refer to the following procedure to ensure that the original tires stay in the same
location on the vehicle.
All 2005 ± 2006 model year Lexus vehicles.
1. Mark the tire installation position on the inward facing tire sidewall.
Example: Front Right = FR, Front Left = FL, Rear Right = RR, Rear Left = RL
2. Install the original tires on the new or refinished wheels with the marked side
facing inwards.
3. Place the tire/wheel assemblies on the vehicle in the marked positions.
NOTE:
Torque the wheel nuts to the proper torque value in sequence.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Installation
Procedure
Warranty
Information

Lexus Supports ASE CertificationPage 1 of 2
Title:
REPLACEMENT VIN PLATES
Models:
All Models
Technical Service
Information Bulletin
January 18, 2002
PG003-02
TSB UPDATE NOTICE:
The information contained in this TSIB updates PG016±01 dated May 4, 2001.
Revised text is red
and underlined. The changes will take place February 1, 2002.
Replacement VIN plates (metal plates riveted to dashboard) may be available from
Lexus providing the request meets the criteria listed below.
VIN Plate Location
All Lexus vehicles.
The vehicle is in an accident and the plate is damaged.
NOTE:
The original plate to be replaced MUST accompany the request.
NOTE:
If a plate is stolen, be sure to contact the State Police or your State's Department of
Motor Vehicles (DMV). In most cases the State DMV will issue a unique number so that
the original number can be included on stolen vehicle listings. If this is the case, a
replacement plate is NOT available from Lexus. However, the original VIN, NOT the
state issued VIN, must be used on all warranty claims.
To request a replacement plate, complete a copy of the form on the back of this page.
Note that the damaged VIN plate MUST accompany the request form. Your dealer parts
account will be billed $25.00
for each replacement of a damaged plate.
NOTE:
All replacement plates for damaged and/or stolen vehicles are subject to approval by
the Technical Compliance Department. If you have any specific questions, contact
(310) 468±3390.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Replacement
VIN Plate
Criteria
Procurement
Procedure
Warranty
Information
