2005 LEXUS ES300 Repair Manual

M.I.L. ªONº DTC P0346 ± EG006-05 March 15, 2005
Page 4 of 4
2. Connect the Diagnostic Tester to the vehicle and select CURRENT ECU CAL from
the ECU REPROGRAM MAIN MENU. Determine the vehicle's current ECU
calibration (see Figure 2).
± The sample screen prints seen below are the 12.01a software version and may
differ from subsequent software versions.
Figure 2. Determining Current ECU Calibration
ECU REPROGRAM
MAIN MENU
1: GET CAL FROM PC
2: CURRENT ECU CAL
3: UPDATE ECU CAL
4: CAL ON TESTER
5: CLEAR CAL DATA
A
CURRENT ECU CAL
B
CALIBRATION ID
33350000
53334000
NOTE:
If Calibration ID matches ªPrevious Calibration IDº as shown in Calibration
Identification Chart on page 2, proceed with flash reprogramming.
If Calibration ID matches ªNew Calibration IDº as shown in Calibration
Identification Chart, this vehicle has already been programmed.
Refer to TIS for diagnostic procedures applicable to any stored DTCs.
3. If ECU calibration ID is not the same as the ªNew Calibration IDº listed previously,
proceed to Flash Reprogram ECM (PCM).
4. Flash Reprogram ECM (PCM)
A. Follow the procedures outlined in TSIB No. SS001±01,
ªECU Flash
Reprogramming Process,º
and flash the ECM (PCM) with the new calibration
file update.
B. Enter the required information on the Authorized Modifications Label and affix it
to the vehicle at the location shown in Figure 1 (page 3). The Authorized
Modifications Label is available through the MDC, P/N 00451±00001±LBL.
5. Follow the procedures outlined in TSIB No. EG012±04,
ªEntering VIN During ECM
(PCM) Replacement and/or DTC P0630,º
and write the VIN to the ECM (PCM).
6. The repair is complete. Test drive vehicle to confirm normal operation.
Repair
Procedure
(Continued)

Lexus Supports ASE CertificationPage 1 of 7
Title:
RADIATOR CAP INSPECTION
Models:
All Models
Technical Service
Information Bulletin
March 28, 2005
EG007-05
The procedure for inspecting the radiator cap has been revised. Please refer to the
following procedures when inspecting the radiator cap on all Lexus models.
All Lexus models.
MANUFACTUREREQUIPMENTQTY
Snap±On/Sun
SVTS262A
(or equivalent)Cooling System Tester
(Radiator Cap Tester)1
NOTE:
Additional Lexus Approved Dealer Equipment may be ordered by calling Lexus
Approved Dealer Equipment at 1±800±368±6787.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
ENGINE
Introduction
Applicable
Vehicles
Required
Equipment
Warranty
Information

RADIATOR CAP INSPECTION ± EG007-05 March 28, 2005
Page 2 of 7
ITEM
NO.SPECIAL SERVICE TOOLS (SSTs)PART NUMBERQTYDRW**
1Radiator Cap Test Set*09230±00030±0217
2Radiator Cap Test Set (Small)*09230±00020±0217
* Essential SSTs.
** Refers to drawer number in SST Storage System.
NOTE:
Additional SSTs may be ordered by calling SPX/OTC at 1-800-933-8335.
1. Use the illustration below to identify the vehicle's radiator cap type and kPa rating.
2. Proceed to the required inspection procedure for the radiator cap and kPa rating.
kPa Rating
Radiator Cap Identification
Compact Cap N±CapPlastic Cap
Required
SSTs
Radiator Cap
Identification
Procedure

RADIATOR CAP INSPECTION ± EG007-05 March 28, 2005
Page 3 of 7
Type: N±cap, 88 kPa
1. Remove coolant and any foreign
material on rubber points ªA,º ªB,º
and ªC.º
2. Check that points ªA,º ªB,º and ªCº
are not deformed, cracked,
or swollen.
3. Check that points ªCº and ªDº are not
stuck together.
4. Apply engine coolant to points ªBº
and ªCº before using the radiator
cap tester.
Radiator Cap Tester:
Snap±On/Sun P/N SVTS262A
(or equivalent)
5. Before installing the radiator cap
tester, use the applicable radiator cap
adaptor provided in the following SST
kits in conjunction with the radiator
cap tester:
SST P/N 09230±00030±02
(09231±10080±01) or
09230±00020±02 (09231±10060±01)
6. When using the radiator cap tester,
tilt it more than 30 degrees.
7. Pump the radiator cap tester
several times, and check the
maximum pressure.
Pumping speed: 1 pump/second
HINT:
Stop pumping when the valve opens
and read the gauge. The gauge must
be within the standard values listed
below when the pressure valve opens.
The cap is considered OK when the
pressure holds steady or falls very
slowly, but holds within the standard
values listed below for one minute.
Specification:
VALVE OPENING PRESSURESPECIFIED CONDITION
Standard value
(for brand±new cap)74.0 to 103.0 kPa
(0.75 to 1.05 kgf/cm2, 10.7 to 14.9 psi)
Minimum standard value
(for in±service cap)59 kPa (0.60 kgf/cm2, 8.53 psi)
If the maximum pressure is less than the minimum standard value, replace the radiator
cap sub±assembly.
Radiator Cap
Inspection
Procedure
A
C BD N±Cap: 88 kPa
Radiator Cap
Tester
Radiator
Cap305 or more

RADIATOR CAP INSPECTION ± EG007-05 March 28, 2005
Page 4 of 7
Type: N±cap, 108 kPa
1. Remove coolant and any foreign
material on rubber points ªA,º ªB,º
and ªC.º
2. Check that points ªA,º ªB,º and ªCº
are not deformed, cracked,
or swollen.
3. Check that points ªCº and ªDº are not
stuck together.
4. Apply engine coolant to points ªBº
and ªCº before using the radiator
cap tester.
Radiator Cap Tester:
Snap±On/Sun P/N SVTS262A
(or equivalent)
5. Before installing the radiator cap
tester, use the applicable radiator cap
adaptor provided in the following SST
kits in conjunction with the radiator
cap tester:
SST P/N 09230±00030±02
(09231±10080±01) or
09230±00020±02 (09231±10060±01)
6. When using the radiator cap tester,
tilt it more than 30 degrees.
7. Pump the radiator cap tester
several times, and check the
maximum pressure.
Pumping speed: 1 pump/second
HINT:
Stop pumping when the valve opens
and read the gauge. The gauge must
be within the standard values listed
below when the pressure valve opens.
The cap is considered OK when the
pressure holds steady or falls very
slowly, but holds within the standard
values listed below for one minute.
Specification:
VALVE OPENING PRESSURESPECIFIED CONDITION
Standard value
(for brand±new cap)93.3 to 122.7 kPa
(0.95 to 1.25 kgf/cm2, 13.5 to 17.8 psi)
Minimum standard value
(for in±service cap)78.5 kPa (0.80 kgf/cm2, 11.38 psi)
If the maximum pressure is less than the minimum standard value, replace the radiator
cap sub±assembly.
Radiator Cap
Inspection
Procedure
(Continued)
A
C BD N±Cap: 108 kPa
Radiator Cap
Tester
305 or more
Radiator
Cap

RADIATOR CAP INSPECTION ± EG007-05 March 28, 2005
Page 5 of 7
Type: Compact Cap, 88 kPa
1. Remove coolant and any foreign
material on rubber points ªA,º ªB,º
and ªC.º
2. Check that points ªAº and ªBº
are not deformed, cracked,
or swollen.
3. Check that points ªBº and ªCº are not
stuck together.
4. Apply engine coolant to point ªBº
before using the radiator
cap tester.
Radiator Cap Tester:
Snap±On/Sun P/N SVTS262A
(or equivalent)
5. Before installing the radiator cap
tester, use the applicable radiator cap
adaptor provided in the following SST
kits in conjunction with the radiator
cap tester:
SST P/N 09230±00030±02
(09231±10080±01) or
09230±00020±02 (09231±10060±01)
6. When using the radiator cap tester,
tilt it more than 30 degrees.
7. Pump the radiator cap tester
several times, and check the
maximum pressure.
Pumping speed: 1 pump/second
HINT:
Stop pumping when the valve opens
and read the gauge. The gauge must
be within the standard values listed
below when the pressure valve opens.
The cap is considered OK when the
pressure holds steady or falls very
slowly, but holds within the standard
values listed below for one minute.
Specification:
VALVE OPENING PRESSURESPECIFIED CONDITION
Standard value
(for brand±new cap)74.0 to 103.0 kPa
(0.75 to 1.05 kgf/cm2, 10.7 to 14.9 psi)
Minimum standard value
(for in±service cap)59 kPa (0.60 kgf/cm2, 8.53 psi)
If the maximum pressure is less than the minimum standard value, replace the radiator
cap sub±assembly.
Radiator Cap
Inspection
Procedure
(Continued)
A
C B Compact Cap: 88 kPa
Radiator Cap
Tester
305 or more
Radiator
Cap

RADIATOR CAP INSPECTION ± EG007-05 March 28, 2005
Page 6 of 7
Type: Compact Cap, 108 kPa
1. Remove coolant and any foreign
material on rubber points ªA,º ªB,º
and ªC.º
2. Check that points ªAº and ªBº
are not deformed, cracked,
or swollen.
3. Check that points ªBº and ªCº are not
stuck together.
4. Apply engine coolant to point ªBº
before using the radiator
cap tester.
Radiator Cap Tester:
Snap±On/Sun P/N SVTS262A
(or equivalent)
5. Before installing the radiator cap
tester, use the applicable radiator cap
adaptor provided in the following SST
kits in conjunction with the radiator
cap tester:
SST P/N 09230±00030±02
(09231±10080±01) or
09230±00020±02 (09231±10060±01)
6. When using the radiator cap tester,
tilt it more than 30 degrees.
7. Pump the radiator cap tester
several times, and check the
maximum pressure.
Pumping speed: 1 pump/second
HINT:
Stop pumping when the valve opens
and read the gauge. The gauge must
be within the standard values listed
below when the pressure valve opens.
The cap is considered OK when the
pressure holds steady or falls very
slowly, but holds within the standard
values listed below for one minute.
Specification:
VALVE OPENING PRESSURESPECIFIED CONDITION
Standard value
(for brand±new cap)93.3 to 122.7 kPa
(0.95 to 1.25 kgf/cm2, 13.5 to 17.8 psi)
Minimum standard value
(for in±service cap)78.5 kPa (0.80 kgf/cm2, 11.38 psi)
If the maximum pressure is less than the minimum standard value, replace the radiator
cap sub±assembly.
Radiator Cap
Inspection
Procedure
(Continued)
A
C B Compact Cap: 108 kPa
Radiator Cap
Tester
305 or more
Radiator
Cap

RADIATOR CAP INSPECTION ± EG007-05 March 28, 2005
Page 7 of 7
Type: Plastic Cap, 108 kPa
1. Remove coolant and any foreign
material on O±ring ªA.º
2. Check that O±ring ªAº is not
deformed, cracked, or swollen.
3. Apply engine coolant to O±ring ªAº
and rubber point ªBº before using the
radiator cap tester.
Radiator Cap Tester:
Snap±On/Sun P/N SVTS262A
(or equivalent)
4. Before installing the radiator cap
tester, use the applicable radiator cap
adaptor provided in the following SST
kits in conjunction with the radiator
cap tester:
SST P/N 09230±00030±02
(09231±10080±01) or
09230±00020±02 (09231±10060±01)
5. When using the radiator cap tester,
tilt it more than 30 degrees.
6. Pump the radiator cap tester
several times, and check the
maximum pressure.
Pumping speed: 1 pump/second
HINT:
Stop pumping when the valve opens
and read the gauge. The gauge must
be within the standard values listed
below when the pressure valve opens.
The cap is considered OK when the
pressure holds steady or falls very
slowly, but holds within the standard
values listed below for one minute.
Specification:
VALVE OPENING PRESSURESPECIFIED CONDITION
Standard value
(for brand±new cap)93.3 to 122.7 kPa
(0.95 to 1.25 kgf/cm2, 13.5 to 17.8 psi)
Minimum standard value
(for in±service cap)78.5 kPa (0.80 kgf/cm2, 11.38 psi)
If the maximum pressure is less than the minimum standard value, replace the radiator
cap sub±assembly.
Radiator Cap
Inspection
Procedure
(Continued)
A
B Plastic Cap: 108 kPa
Radiator Cap
Tester
305 or more
Radiator
Cap
