- ENGINE CONTROL SYSTEMKNOCK SENSOR (3MZ-FE)
2025 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
26. INSTALL FRONT SUSPENSION UPPER BRACE CENTER (W/O TEMS) (See page 10-1 1)
27. SYSTEM INITIALIZATION (See page 19-15)

100J8-01
A86338
(a)
(b)
(b)
- ENGINE CONTROL SYSTEMACCELERATOR PEDAL ASSY (3MZ-FE (NORMAL
PEDAL))10-21
2026 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
ACCELERATOR PEDAL ASSY (3MZ-FE (NORMAL PEDAL))
REPLACEMENT
1. DISCONNECT ENGINE WIRE NO. 3 (BATTERY NEGATIVE TERMINAL)
2. REMOVE ACCELERATOR PEDAL ASSY
(a) Disconnect the accelerator position sensor connector.
(b) Remove the 2 bolts, then remove the accelerator pedal
rod.
3. INSTALL ACCELERATOR PEDAL ASSY
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
4. CONNECT ENGINE WIRE NO. 3 (BATTERY NEGATIVE TERMINAL)
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
5. SYSTEM INITIALIZATION (See page 19-15)

100J9-02
A86255
(a)
(b)
(a)
(b)(a)
A86256
(b)
(a)
(b)
(b)
(b)
(b)
(c)
(c)
A86257
(a)
(a)
A86258
(a)
(a) 10-22
- ENGINE CONTROL SYSTEMECM (3MZ-FE)
2027 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
ECM (3MZ-FE)
REPLACEMENT
1. DISCONNECT ENGINE WIRE NO. 3 (BATTERY NEGATIVE TERMINAL)
2. REMOVE FRONT DOOR SCUFF PLATE RH (See page 71-1 1)
3. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1 (See page 71-1 1)
4. REMOVE INSTRUMENT PANEL SUB-ASSY LOWER (See page 71-1 1)
5. REMOVE STEREO COMPONENT AMPLIFIER ASSY
(a) Disconnect the 3 stereo component amplifier connectors.
(b) Remove the 2 nuts, then remove the stereo component
amplifier.
6. REMOVE ECM
(a) Remove the wire harness clamp.
(b) Disconnect the 5 ECM connectors.
(c) Remove the 2 nuts, then remove the ECM.
7. REMOVE ECM BRACKET
(a) Remove the 2 screws, then remove the ECM bracket.
8. REMOVE ECM BRACKET NO.2
(a) Remove the 2 screws, then remove the ECM bracket No.
2.

A86259
(a)
(a)
- ENGINE CONTROL SYSTEMECM (3MZ-FE)
10-23
2028 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
9. REMOVE ECM BRACKET NO.3
(a) Remove the 2 screws, then remove the ECM bracket No
3.
10. INSTALL ECM BRACKET NO.3
11. INSTALL ECM BRACKET NO.2
12. INSTALL ECM BRACKET
13. INSTALL ECM
Torque: 5.5 NVm (56 kgfVcm, 49 in.Vlbf)
14. INSTALL STEREO COMPONENT AMPLIFIER ASSY
Torque: 5.5 NVm (56 kgfVcm, 49 in.Vlbf)
15. INSTALL INSTRUMENT PANEL SUB-ASSY LOWER
16. INSTALL INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1
17. INSTALL FRONT DOOR SCUFF PLATE RH
18. CONNECT ENGINE WIRE NO. 3 (BATTERY NEGATIVE TERMINAL)
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
19. RESET MEMORY (See page 05-604)
20. SYSTEM INITIALIZATION (See page 19-15)

110XR-01
A62391
Circuit Opening Relay
- FUELFUEL SYSTEM (3MZ-FE)
11-1
2029 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
FUEL SYSTEM (3MZ-FE)
PRECAUTION
1. PRECAUTION
(a) Before working on the fuel system, disconnect the engine wire No. 3 (battery negative terminal) from
battery.
(b) Do not smoke or work near open flame when working on the fuel system.
(c) Keep gasoline away from the rubber or leather parts.
2. DISCHARGE FUEL SYSTEM PRESSURE
CAUTION:

Do not disconnect any parts of the fuel system pres-
sure until you have discharging the fuel system pres-
sure.

Even after discharge the fuel pressure, place a shop
rag over fittings as you separate them in order to re-
duce risk of fuel spray on yourself or in the engine
compartment.
(a) Disconnect the engine wire No. 3 (battery negative termi-
nal).
(b) Remove the circuit opening relay from the engine room
relay block.
(c) Connect the engine wire No. 3 (battery negative terminal).
Torque: 5.4 NVm (55 kgfVcm, 48 in.Vlbf)
(d) Start the engine. After the engine has stopped on its own,
turn the ignition switch OFF.
HINT:
There is a case that DTC P0171 (system to lean) is output.
(e) Check that the engine does not start.
(f) Remove the fuel tank cap, then let the air out of the fuel
tank.
(g) Disconnect battery negative terminal.
(h) Reinstall the circuit opening relay.
3. FUEL SYSTEM
(a) When disconnecting the high fuel pressure line, a large
amount of gasoline will spill out. So observe these proce-
dures.
(1) Work in order to prevent gasoline from spilling out.
(2) Disconnect the fuel pump tube (see page 11-20).
(3) Drain the fuel remaining inside the fuel pump tube.

B00679
B00347
New O-ring
Delivery Pipe
InjectorCORRECT
WRONG
Grommet
FI6372
A62371
Delivery Pipe
Spacer
InsulatorO-ring
Grommet
A60083
Fuel Pipe
Clamp
11-2
- FUELFUEL SYSTEM (3MZ-FE)
2030 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(4) In order to prevent the disconnected fuel pump tube
from being damaged and foreign objects from being
introduced, cover the disconnected fuel pump tube
with a vinyl or plastic bag.
(5) Place a tray under the vehicle or point of disconnec-
tion to catch any fuel that may spill.
(6) Put a container under the connection.
(b) Take the following precautions when removing and instal-
ling the fuel injectors.
NOTICE:
Never reuse the O-ring.
(1) When installing a new O-ring on the fuel injector, be
careful not to damage it.
(2) Coat a new O-ring with spindle oil or gasoline be-
fore installing. Never use engine oil, gear oil or
brake oil.
(c) Install the fuel injector to the fuel delivery pipe and intake
manifold as shown in the illustration. Before installing the
fuel injector, be sure to apply spindle oil or gasoline to the
place where the fuel delivery pipe or intake manifold
touches the O-ring of the fuel injector.
(d) Take the following precautions when disconnecting the
quick connector.
(1) Remove the fuel pipe clamp.
(2) Check the pipe and around the quick connector for
dirt or mud before disconnecting them. Remove the
dirt if necessary.

A
A
B12941
B12944
Vinyl Bag
A52581
A71366
Push
A71366
Pull
- FUELFUEL SYSTEM (3MZ-FE)
11-3
2031 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(3) Disconnect the quick connector from the pipe while
pinching portion A with your fingers as shown in the
illustration.
(4) If the quick connector and pipe are stuck, pinch the
pipe, then push and pull the quick connector to re-
lease and pull it out.
NOTICE:
Do not use any tools.
(5) If there is dirt or any other substances on the sealing
surface that might interfere with the seal, clean the
area thoroughly before assembling.
(6) In order to prevent the disconnected pipe and quick
connector from damage or dirt, cover them with a vi-
nyl or plastic bag.
(e) Take the following precautions when connecting the quick
connector.
(1) Check the connected part of the pipe for damage or
foreign objects.
(2) Align the axis of the quick connector with the axis of
the pipe, then push into the quick connector until the
quick connector makes a ºclickº sound. In case that
the connection is tight, apply a little amount of fresh
engine oil to the tip of the pipe.
(3) After connecting, check if the pipe and quick con-
nector are securely connected by pulling on them.
(4) Install the fuel pipe clamp.
(5) Check if there is any leakage.

11-4
- FUELFUEL SYSTEM (3MZ-FE)
2032 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
4. CHECK FOR FUEL LEAKS
(a) Check that there are no fuel leaks after doing maintenance anywhere on the fuel system (see page
11-5).
