(c) Remove the 5 bolts and 7 shift solenoid valves.
7. INSTALL TRANSMISSION VALVE BODY ASSY
(a) Install the spring and check ball body.
(b) Install the 7 shift solenoid valves with the 5 bolts.
Torque:
Bolt A, B: 11 N´m (110 kgf´cm, 8 ft.Vlbf)
Bolt C, D: 6.6 N´m (67 kgf´cm, 58 in. lbf)
Bolt length:
Bolt A: 16 mm (0.63 in.)
Bolt B: 57 mm (2.2 in.)
Bolt C: 23 mm (0.9 in.)
Bolt D: 12 mm (0.47 in.)

C91933
A
B
CB
B
B
A
CCC




C
B
C91932
C91931
C91927
- AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
40-27
2542 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(c) Align the groove of the manual valve with the pin of lever.
(d) Install the 17 bolts.
Torque: 11 NVm (110 kgfVcm, 8 ftVlbf)
NOTICE:
Push the valve body against the accumulator piston
spring and the check ball body to install it.
Temporarily tighten those bolts marked by
in the il-
lustration first because they are positioning bolts.
Bolt length:
Bolt A: 25 mm (0.984 in.)
Bolt B: 57 mm (2.244 in.)
Bolt C: 41 mm (1.614 in.)
8. INSTALL VALVE BODY OIL STRAINER ASSY
(a) Coat a new O-ring with ATF.
(b) Install the O-ring to the oil strainer.
(c) Install the oil strainer with the 3 bolts.
Torque: 11 NVm (110 kgfVcm, 8 ftVlbf)
9. INSTALL TRANSMISSION WIRE
(a) Coat a O-ring with ATF.
(b) Install the ATF temperature sensor with the lock plate and
bolt.
Torque: 6.6 NVm (67 kgfVcm, 58 in.Vlbf)
(c) Connect the 7 shift solenoid valve connectors.

D30865
C91925
40-28
- AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
2543 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
10. I N S TA L L A U TO M AT I C T R A N S A X L E O I L PA N
SUB-ASSY
(a) Install the 2 magnets in the oil pan.
(b) Apply seal packing to 18 bolts.
Seal packing:
THREE BOND 2430 or equivalent
(c) Install a new gasket, oil pan and 18 bolts to the transaxle
case.
Torque: 7.8 NVm (80 kgfVcm, 69 in.Vlbf)
NOTICE:
Since the bolts should be seal bolts, apply seal packing to
the bolts and tighten them within 10 minutes after applying.
11. ADD AUTOMATIC TRANSAXLE FLUID
12. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PAGE 40-1)
13. INSTALL ENGINE UNDER COVER NO.1
14. RESET MEMORY (SEE PAGE 05-604)

4010X-04
D25831
SST
D25832
SST
D25833
SST
- AUTOMATIC TRANSMISSION / TRANSFRONT DIFFERENTIAL OIL SEAL (U151E)
40-29
2544 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
FRONT DIFFERENTIAL OIL SEAL (U151E)
REPLACEMENT
1. REMOVE FRONT WHEELS
2. REMOVE ENGINE UNDER COVER NO.1
3. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug, gasket and drain ATF.
(b) Install a new gasket and drain plug.
Torque: 49 NVm (500 kgfVcm, 36 ftVlbf)
4. REMOVE FRONT DRIVE SHAFT ASSY RH (SEE PAGE 30-8)
5. REMOVE FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30-8)
6. REMOVE TRANSAXLE HOUSING OIL SEAL
(a) Using SST, pull out the oil seal.
SST 09308-00010
7. REMOVE DIFFERENTIAL SIDE BEARING RETAINER
OIL SEAL
(a) Using SST, pull out the oil seal.
SST 09308-00010
8. INSTALL DIFFERENTIAL SIDE BEARING RETAINER
OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal.
SST 09316-6001 1 (09316-00011)
Oil seal drive in depth:
0
0.5 mm (0
0.020 in.)
(b) Coat the lip of the oil seal with MP grease.
SST 09316-6001 1 (09316-00011)

D25834
SST 40-30
- AUTOMATIC TRANSMISSION / TRANSFRONT DIFFERENTIAL OIL SEAL (U151E)
2545 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
9. INSTALL TRANSAXLE HOUSING OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal.
SST 09223-15020, 09950-70010 (09951-07150)
Oil seal drive in depth:
0
0.5 mm (0
0.020 in.)
(b) Coat the lip of the oil seal with MP grease.
10. INSTALL FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30-8)
11. INSTALL FRONT DRIVE SHAFT ASSY RH (SEE PAGE 30-8)
12. INSTALL FRONT WHEELS
13. ADD AUTOMATIC TRANSAXLE FLUID
14. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PAGE 40-1)
15. CHECK ABS SPEED SENSOR SIGNAL
w/ VSC (SEE PAGE 05-471)
w/o VSC (SEE PAGE 05-420 )

40067-09
C63995IG
E STP
- AUTOMATIC TRANSMISSION / TRANSSHIFT LOCK SYSTEM
40-31
2546 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
SHIFT LOCK SYSTEM
ON-VEHICLE INSPECTION
1. CHECK SHIFT LOCK OPERATION
(a) Shift the shift lever to P position.
(b) Turn the ignition switch to LOCK.
(c) Check that the shift lever cannot be shifted to any other positions other than P.
(d) Turn the ignition switch to ON, depress the brake pedal and check that the shift lever can be shifted
to any other positions.
2. CHECK SHIFT LOCK RELEASE BUTTON OPERATION
(a) Using a small screwdriver, remove the shift lock release cover.
(b) When operating the shift lever with the shift lock release button pressed, check that the lever can be
shifted to any position other than P.
3. CHECK KEY INTERLOCK OPERATION
(a) Turn the ignition switch to ON.
(b) Depress the brake pedal and shift the shift lever to any other position other than P.
(c) Check that the ignition key cannot be turned to LOCK.
(d) Shift the shift lever to P position, turn the ignition key to LOCK and check that the ignition key can be
removed.
4. INSPECT SHIFT LOCK CONTROL UNIT ASSEMBLY
(a) Using a voltmeter, measure the voltage at each terminal.
HINT:
Do not disconnect the shift lock control unit assembly connec-
tor.
TerminalMeasuring ConditionVoltage (V)
3 (STP) - 1 (E)Depress brake pedal10 - 14
3 (STP) - 1 (E)Release brake pedal0
5 (IG) - (E)Ignition switch ON10 - 14
5 (IG) - (E)Ignition switch OFF0

C93272E
40-32
- AUTOMATIC TRANSMISSION / TRANSSHIFT LOCK SYSTEM
2547 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
(b) Using an ohmmeter, measure the resistance at terminal
E (1) and body ground.
HINT:
Do not disconnect the shift lock control unit assembly connec-
tor.
TerminalMeasuring ConditionSpecified Value
1 (E) - Body groundAlwaysContinuity

400FU-02
C93015
C92370
- AUTOMATIC TRANSMISSION / TRANSFLOOR SHIFT ASSY
40-33
2548 Author
: Date
:
2005 LEXUS ES330 REPAIR MANUAL (RM1124U)
FLOOR SHIFT ASSY
OVERHAUL
1. REMOVE FRONT DOOR SCUFF PLATE LH (SEE PAGE 71-1 1)
2. REMOVE FRONT DOOR SCUFF PLATE RH (SEE PAGE 71-1 1)
3. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1 (SEE PAGE 71-1 1)
4. REMOVE INSTRUMENT PANEL SUB-ASSY LOWER (SEE PAGE 71-1 1)
5. REMOVE INSTRUMENT PANEL SUB-ASSY UPPER (SEE PAGE 71-1 1)
6. REMOVE INSTRUMENT PANEL INSERT SUB-ASSY LOWER LH (SEE PAGE 71-1 1)
7. REMOVE CONSOLE BOX ASSY (SEE PAGE 71-1 1)
8. REMOVE CONSOLE BOX CARPET
9. REMOVE CONSOLE BOX ASSY (SEE PAGE 71-1 1)
10. REMOVE INSTRUMENT PANEL FINISH PANEL END RH (SEE PAGE 71-1 1)
11. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (SEE PAGE 71-1 1)
12. REMOVE AIR DUCT REAR NO.1 (SEE PAGE 55-17)
13. REMOVE AIR DUCT REAR NO.2 (SEE PAGE 55-17)
14. REMOVE CONSOLE BOX DUCT NO.1 (SEE PAGE 55-17)
15. DISCONNECT FLOOR SHIFT PARKING LOCK CABLE
ASSY
(a) Disconnect the parking lock cable end from the lever pin
of the floor shift assembly.
(b) Using a screwdriver, disconnect the parking lock cable
from the floor shift assembly and clamp.
(c) Disconnect the cable clamp.
