(n) Install the PS pressure tube with the 2 nuts.
(o) Connect the throttle position sensor connector.
(p) Connect the IAC valve connector.
(q) Connect the No.1 VSV connector for the ACIS.
(r) Connect the No.2 VSV connector for the ACIS.
(s) Connect the VSV connecter for the EVAP.
(t) Connect the DLC1 to the bracket on the intake air control
valve.
(u) Connect the throttle cable.
(v) Connect the accelerator cable.
29. INSTALL AIR CLEANER CAP HOSE WITH RESONA-
TOR
30. INSTALL V-BANK COVER
(a) Using a 5 mm hexagon wrench, install the V-bank cover
with the 3 cap nuts.
(b) Press down the V-bank cover fastener.
31. INSTALL FRONT EXHAUST PIPE (See page EM-77)
32. INSTALL PS PUMP (See page SR-35)
33. INSTALL GENERATOR DRIVE BELT
(See page CH-16)
34. FILL WITH ENGINE COOLANT
35. START ENGINE AND CHECK FOR LEAKS
36. VEHICLE ROAD TEST
Check for abnormal noise, shock, slippage, correct shift points
and smoothly operation.
37. RECHECK ENGINE COOLANT LEVEL

EM0ZI-02
P1151110 - 15 mm (0.39 - 0.59 in.)Adhesive
P12572
Protrusion
P12869
Flush
A05418
EM-56
- ENGINE MECHANICALCYLINDER HEAD
1040 Author
: Date
:
2001 AVALON (RM808U)
REASSEMBLY
HINT:

Thoroughly clean all parts to be assembled.

Before installing the parts, apply new engine oil to all slid-
ing and rotating surfaces.

Replace all gaskets and oil seals with new ones.
1. INSTALL SPARK PLUG TUBES
HINT:
When using a new cylinder head, spark plug tubes must be
installed.
(a) Apply adhesive to the end of the spark plug tube.
Adhesive: Part No. 08833-00070, THREE BOND 1324
or equivalent
(b) Using a press, press in a new spark plug tube until there
is 42.4 - 43.4 mm (1.669 - 1.709 in.) protruding from the
camshaft bearing cap installation surface of the cylinder
head.
NOTICE:
Avoid pressing a new spark plug tube in too far by measur-
ing the amount of the protrusion while pressing.
2. INSTALL PCV PIPES
HINT:
When using a new cylinder head, PCV pipe must be installed.
Using a wooden block and hammer, tap in a new PCV pipe until
its top side is flush with the cylinder head edge.
NOTICE:
Be careful not to damage the cylinder head edge.
3. INSTALL OIL CONTROL VALVE FILTER
(a) Assemble the valve filter and plug.
(b) Install the plug with new gasket.
Torque: 45 N´m (460 kgf´cm, 33 ft´lbf)

A05276
P12719
SST
Z19062
Intake ExhaustMark
ºNOKº or
ºFN , INº
Light Brown SurfaceGray Surface
P12668
(4)
(3)
(2)
(1)
A05224
SST
- ENGINE MECHANICALCYLINDER HEAD
EM-57
1041 Author
: Date
:
2001 AVALON (RM808U)
4. INSTALL CYLINDER HEAD REAR COVER
Install the rear cover and gasket with the 6 bolts.
Torque: 10 N´m (100 kgf´cm, 7.3 ft´lbf)
5. INSTALL VALVES
(a) Using SST, push in a new oil seal.
SST 09201-41020
HINT:
The intake valve oil seal is light brown and the exhaust valve oil
seal is gray.
NOTICE:
Pay much attention when assembling the oil seal for intake
and exhaust. Assembling the wrong one may cause a fail-
ure.
(b) Install the valve (1), spring seat (2), valve spring (3) and
spring retainer (4).
(c) Using SST, compress the valve spring and place the 2
keepers around the valve stem.
SST 09202-70020 (09202-00010)

A05246
EM-58
- ENGINE MECHANICALCYLINDER HEAD
1042 Author
: Date
:
2001 AVALON (RM808U)
(d) Using a plastic-faced hammer and the valve stem (not in
use) tip wound with vinyl tape, lightly tap the valve stem
tip to assure proper fit.
NOTICE:
Be careful not do damage the valve stem tip.
6. INSTALL VALVE LIFTERS AND SHIMS
(a) Install the valve lifter and shim.
(b) Check that the valve lifter rotates smoothly by hand.

EM0ZE-02
A10518
5 mm
Hexagon
Wrench
A06658
(j)
(k) (l)
- ENGINE MECHANICALCYLINDER HEAD
EM-31
1015 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
NOTICE:
Do not remove or install the camshaft timing gear (VVT-i)
beside changing VVT-i or the camshaft.
1. DRAIN ENGINE COOLANT
2. REMOVE RH FENDER APRON SEAL
3. REMOVE GENERATOR DRIVE BELT
(See page CH-6)
4. REMOVE PS PUMP (See page SR-27)
5. REMOVE FRONT EXHAUST PIPE (See page EM-72)
6. REMOVE V-BANK COVER
(a) Using a 5 mm hexagon wrench, remove the 3 cap nuts.
(b) Loosen the V-bank cover fastener counterclockwise.
(c) Remove the V-bank cover.
7. REMOVE AIR CLEANER HOSE WITH RESONATOR
8. REMOVE AIR INTAKE CHAMBER ASSEMBLY
(a) Disconnect the accelerator cable.
(b) Disconnect the throttle cable.
(c) Disconnect the throttle position sensor connector.
(d) Disconnect the IAC valve connector.
(e) Disconnect the No.1 VSV connector for the ACIS.
(f) Disconnect the No.2 VSV connector for the ACIS.
(g) Disconnect the VSV connector for the EVAP.
(h) Disconnect the DLC1 from the bracket on the intake air
control valve.
(i) Remove the 2 nuts, and disconnect the PS pressure tube
from the No.1 engine hanger.
(j) Disconnect the PCV hose from the PCV valve on the RH
cylinder head.
(k) Disconnect the ground strap and cable from the intake air
control valve for the ACIS.
(l) Disconnect the ground cable from the air intake chamber.

A07505
(p)
(q)
(r)(o)
(n)
(m)
(n)
A09695
Throttle Body
Bracket
Engine
Hanger
A09699
8 mm Hexagon Wrench
A05074(b) (c)
EM-32
- ENGINE MECHANICALCYLINDER HEAD
1016 Author
: Date
:
2001 AVALON (RM808U)
(m) Disconnect the brake booster vacuum hose from the
throttle body.
(n) Disconnect the 2 water bypass hoses from the throttle
body.
(o) Disconnect the air assist hose from the throttle body.
(p) Disconnect the purge hose from the pipe on the emission
control valve set.
(q) Disconnect the 2 vacuum hoses from the vacuum tank for
the ACIS.
(r) Disconnect the engine wire clamp from the emission con-
trol valve set.
(s) Remove the 2 bolts and No.1 engine hanger.
(t) Remove the 2 bolts and throttle body bracket.
(u) Using an 8 mm hexagon wrench, remove the 2 bolts, 2
nuts, the air intake chamber assembly and gasket.
9. REMOVE INTAKE MANIFOLD ASSEMBLY
(a) Disconnect the 6 injector connectors.
(b) Disconnect the fuel inlet hose from the fuel filter.
CAUTION:
Perform connecting operations of the fuel tube connector
(quick type) after observing the precautions.
(See page SF-1)
(c) Disconnect the heater hose from the intake manifold.

A07428
P20049Gasket
A05077
Clamp
Clamp
Clamp
A10531
- ENGINE MECHANICALCYLINDER HEAD
EM-33
1017 Author
: Date
:
2001 AVALON (RM808U)
(d) Remove the 9 bolts, 2 nuts, 2 plate washers, the intake
manifold, delivery pipes and injectors assembly.
NOTICE:

Be careful not to drop the injectors when removing
the delivery pipes.

Pay attention to put any hung load on the injector to
and from the side direction.
10. REMOVE WATER OUTLET
(a) Disconnect the ECT sender gauge connector.
(b) Disconnect the ECT sensor connector.
(c) Disconnect the ground strap connector.
(d) Disconnect the upper radiator hose.
(e) Disconnect the engine coolant reservoir hose.
(f) Remove the 2 bolts, 2 nuts and 2 plate washers.
(g) Disconnect the water bypass hose, and remove the water
outlet.
(h) Remove the 2 gaskets.
11. REMOVE IGNITION COILS
12. REMOVE SPARK PLUGS
13. REMOVE TIMING BELT (See page EM-15)
14. REMOVE CAMSHAFT TIMING PULLEYS
(See page EM-15)
15. REMOVE NO.2 IDLER PULLEY (See page EM-15)
16. REMOVE NO.3 TIMING BELT COVER
(a) Disconnect the 3 engine wire clamps from the timing belt
cover.
(b) Remove the 6 bolts and timing belt cover.
17. REMOVE CAMSHAFT POSITION SENSORS
18. REMOVE CAMSHAFT TIMING OIL CONTROL VALVES
19. DISCONNECT ENGINE WIRE PROTECTOR FROM
REAR SIDE
Remove the nut, and disconnect the engine wire protector from
the RH cylinder head.

A10519
A05205
A07596
Rear
Plate
Inlet Pipe
A05189
A06661
Manifold
Stay
EM-34
- ENGINE MECHANICALCYLINDER HEAD
1018 Author
: Date
:
2001 AVALON (RM808U)
20. DISCONNECT ENGINE WIRE AND PROTECTOR
FROM RH SIDE
Remove the 5 nuts, and disconnect the engine wire and protec-
tor from the RH cylinder head cover.
21. DISCONNECT ENGINE WIRE PROTECTOR FROM LH
SIDE
Remove the 2 bolts, and disconnect the engine wire protector
from the LH cylinder head cover.
22. DISCONNECT CYLINDER HEAD REAR PLATE FROM
LH CYLINDER HEAD
Remove the 2 bolts, and disconnect the rear plate.
23. DISCONNECT WATER INLET PIPE FROM LH CYL-
INDER HEAD AND WATER INLET
(a) Remove the bolt, and disconnect the inlet pipe from the
water inlet.
(b) Remove the O-ring from the inlet pipe.
24. REMOVE PS PUMP BRACKET
Remove the 3 bolts and pump bracket.
25. REMOVE RH EXHAUST MANIFOLD
(a) Disconnect the A/F sensor connector.
(b) Remove the bolt, nut and exhaust manifold stay.
(c) Remove the 6 nuts, exhaust manifold and gasket.
