2001 TOYOTA AVALON Service Repair Manual

- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-99
1703 Author
: Date
:
2001 AVALON (RM808U)
Within
3 secs.
Turn the ignition switch from ON to LOCK at approx. 1 sec. interval 1 to 5 times to select the mode.
Pull out the key plate from the ignition key cylinder.
When add mode or rewrite mode
is selected.When confirmation
mode is selected.
ON
ONON
LOCK
LOCKLOCK
Approx.
1 sec.Approx.
1 sec. Approx. 1 sec.Approx.
1 sec.Approx.
1 sec.
Add mode
Rewrite modeConfirmation mode
ON - LOCK change occurs 1 time
ON - LOCK change occurs 2 timesON - LOCK change occurs 3 times
MPX body ECU automatically performs
the LOCK-UNLOCK operation once
or twice at 1 sec, interval to inform the
operator that either the add mode or
rewrite mode has been selected.
LOCK-UNLOCK occurs once
LOCK-UNLOCK occurs twice
Indicates that add mode has been selected.
Indicates that rewrite mode has been
selected.
1 sec.
LOCK
1 sec.1 sec.
LOCK
UNLOCK
UNLOCK
LOCK
2 secs.2 secs.
UNLOCK MPX body ECU automatically performs the
LOCK-UNLOCK operation 1 to 4 times at
2 sec. interval to inform the operator of
the number of the registered codes.
HINT:
When the number of the registered code
is 0, the operation is automatically
performed 5 times.
Example:
When the operation is performed twice, it
directs that 2 type of recognition code
have been registered.
1st time 2nd time
Registration of recognition code (Confirmation
mode and probation mode) is completed.
ON
LOCK
Approx.
1 sec.Approx.
1 sec.
Prohibition mode
ON - LOCK change occurs 5 times
When prohibition
mode is selected.

BE-100
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
1704 Author
: Date
:
2001 AVALON (RM808U)
MPX body performs operates LOCK-UNLOCK operation 5 times at a 1 sec.
interval to inform the operator that prohibition mode has been selected.
Press again either of switches on the transmitter.
MPX body ECU automatically performs LOCK-UNLOCK operation once or
twice at a 1 sec. interval to inform the operator that it has received the signal
from the transmitter.
LOCK-UNLOCK occurs once
LOCK-UNLOCK occurs twice Registration of recognition code is completed
Registration of recognition code has not been completed.

Recognition code received first time and second time did not match.
Proceed to continue registration
If even one of the following conditions is satisfied, registration of recognition
codes in completed.

40 secs. elapses since the MPX body ECU response.

The driver's door is closed.

The key plate is inserted in the ignition key cylinder.

4 types recognition codes are registration at one time.
Registration of recognition codes (add mode or rewrite mode) is completed.
Within
3 secs. Within
40 secs.
ON
LOCK
Approx.
1 sec.Approx.
1 sec.
When prohibition
mode is selected.
Press the lock and unlock switches on the transmitter simultaneously within 1.5 sec.
If they are not performed, the mode returns to the normal mode, then start with
ºStart registration of recognition codeº.
Proceed to finish registration
Within 40 secs.
Within 3 secs.

BO0Y6-03
H12136
Front Door Outside MouldingRear Door Outside Moulding
- BODYBODY OUTSIDE MOULDING
BO-43
1828 Author
: Date
:
2001 AVALON (RM808U)
BODY OUTSIDE MOULDING
COMPONENTS

BO0Y8-03
H12138
Adhesive Tape
Adhesive TapeAdhesive Tape
Adhesive Tape
- BODYBODY OUTSIDE MOULDING
BO-45
1830 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
1. CLEAN BODY MOUNTING SURFACE
(a) Using a heat light, heat the body mounting surface to 40
- 60 °C (104 - 140 °F).
NOTICE:
Do not heat the body excessively.
(b) Remove the adhesive tape from the body.
(c) Wipe off stains with cleaner.
2. CLEAN MOULDING
If reusing moulding:
(a) Using a heat light, heat the moulding to 20 - 30 °C (68 -
86 °F).
NOTICE:
Do not heat the moulding excessively.
(b) Remove the adhesive tape from the moulding.
(c) Wipe off stains with cleaner.
(d) Apply a new adhesive tape to the moulding as shown in
the illustration.
3. INSTALL MOULDING
(a) Using a heat light, heat the body and moulding.
Body: 40 - 60 °C (104 - 140 °F)
Moulding: 20 - 30 °C (68 - 86 °F)
NOTICE:
Do not heat the moulding excessively.
(b) Lift the moulding release sheet from the face of moulding.
NOTICE:
When the moulding release sheet is removed, make sure
that no dirt or dust can get onto the coated area.

BO5229
BO-46
- BODYBODY OUTSIDE MOULDING
1831 Author
: Date
:
2001 AVALON (RM808U)
(c) Align the bosess with their corresponding holes in the
body, and press firmly on the moulding.
NOTICE:
Do not apply excessive force onto the moulding, but steady
pressure with your thumbs.

BO0Y7-03
H00792Protective Tape
BO-44
- BODYBODY OUTSIDE MOULDING
1829 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. HEAT MOULDING
Using a heat light, heat the moulding to 40 - 60 °C (104 - 140
°F).
NOTICE:
Do not heat moulding excessively.
2. REMOVE OUTSIDE MOULDING
(a) Tie both piano wire ends to wooden blocks or similar ob-
jects.
(b) Cut the adhesive tape by pulling the piano wire as shown.
NOTICE:

If reusing the moulding, take care not to damage the
moulding.

Do not damage the body.
(c) Remove the moulding.

BO2PK-01
H12166
w/ Rear personal light:
Rear Personal Light
RH Roof Side
Inner Garnish

Back Window
Moulding
Back Window Glass
w/ Speaker:
High-mounted
Stop Light
LH Roof Side Inner Garnish
Package Tray Trim
Upper Back Silencer
Rear Seatback
Rear Seat
Outer Belt RH
Rear Seat Inner
with Center Belt Rear Seat Cushion Roof Headlining
Rear Door
Opening Trim
No. 1 Stopper

No. 2 Stopper

No. 1 Stopper

No. 2 Stopper
: Specified torque
N´m (kgf´cm, ft´lbf)

Non-reusable partw/o Speaker:
High-mounted Stop Light
Rear Seat Inner Belt
41 (420, 30)
41 (420, 30)41 (420, 30)
18 (185, 13)
18 (185, 13)
Rear Seat Outer Belt LH
- BODYBACK WINDOW GLASS
BO-69
1854 Author
: Date
:
2001 AVALON (RM808U)
BACK WINDOW GLASS
COMPONENTS

BO2PM-01
BO4420
Adhesive
BO5231
H10503
H12165
Stopper A
- BODYBACK WINDOW GLASS
BO-73
1858 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
1. CLEAN AND SHAPE CONTACT SURFACE OF BODY
(a) Using a knife, cut away any rough areas on the body.
HINT:
Leave of the adhesive on the body as much as possible.
(b) Clean the cut surface of the adhesive with a shop rag sat-
urated in cleaner.
HINT:
Even if all the adhesive has been removed, clean the body.
2. CLEAN REMOVED GLASS
(a) Remove the damaged No. 2 stoppers.
(b) Using a scraper, remove the adhesive sticking to the
glass.
(c) Clean the glass with cleaner.
NOTICE:

Be careful not to damage the glass.

Do not touch the glass face after cleaning it.
3. REPLACE NO. 1 STOPPERS
(a) Remove the damaged stoppers.
(b) Cut off the old adhesive around the stopper installation
area.
NOTICE:
Be careful not to damage the body.
(c) Clean the installation area.
(d) Attach new stoppers to the body so that the notches on
the body will align with the stoppers as shown in the il-
lustration.
HINT:
Make sure that the stoppers are installed facing the correct
direction.
4. INSTALL NEW NO. 2 STOPPERS
Attach new stoppers to the glass so that the ceramic notches
on the glass will align with the stoppers as shown in the illustra-
tion.
A: 12 mm (0.47 in.)
